- Page 1 ELECTRIC HOB ZBE 602 INSTRUCTION BOOKLET Please read this instruction booklet before using the appliance...
-
Page 2: Important Safety Information
Important Safety Information You MUST read these warnings carefully before installing or using the hob. If you need assistance, contact our Customer Care Department on 01635 521313 Installation This hob must be installed by qualified personnel, according to the manufacturer’s instructions and to the relevant British Standards. -
Page 3: Table Of Contents
For the User Description of the Hob Operation Maintenance and Cleaning Something Not Working? Service and Spare Parts Guarantee Conditions Page 10 Guide to Use the instructions The following symbols will be found in the text to guide you throughout the Instructions: Safety Instructions Step by step instructions for an operation... -
Page 4: Description Of The Hob
Description of the Hob 1. Hob Top 2. Rapid Hotplate - 2090 W/180 mm dia. 3. Rapid Hotplate - 2090 W/180 mm dia. 4. Rapid Hotplate - 1570 W/145 mm dia. 5. Rapid Hotplate - 1570 W/145 mm dia. 6. Control knob for back left hotplate 7. -
Page 5: Operation
Operation ELECTRIC HOTPLATES To switch on a hotplate, turn the relevant control knob anticlockwise to the required heat setting. The control knob is numbered 1 - 6 0 - OFF 1 - Minimum - Maximum. The hob has four rapid hotplates: The rapid hotplates are indicated by a red dot, and will heat up more quickly than a normal plate. - Page 6 Take care when frying food in hot oil or fat, as the overheated splashes could easily ignite. If the control knobs become difficult to turn, please contact your local Zanussi Service Force Centre.
-
Page 7: Maintenance And Cleaning
Maintenance and Cleaning Before any maintenance or cleaning can be carried out, you must DISCONNECT the hob from the electricity supply. The hob is best cleaned whilst it is still warm, as spillage can be removed more easily than if it is left to cool. -
Page 8: Something Not Working
The plate does not heat up. The plate is not giving satisfactory results If after all these checks, the oven still does not work, contact your local Zanussi Service Force Centre. When you contact them, they will need the following information: 1. -
Page 9: Service And Spare Parts
Customer Care Booklet. Peace of Mind for 24 Months ZANUSSI GUARANTEE CONDITIONS We, Zanussi, undertake that if, within 24 months of the date of the purchase, this Zanussi appliance or any part thereof is proved to be defective by any... -
Page 10: Technical Data
Instructions for the Installer Engineer technical data OVERALL DIMENSIONS Width: 580 mm. Depth: 510 mm. Height: 88 mm. Weight: 11 Kg. CUT OUT DIMENSIONS Width: 560 mm. Depth: 480 mm. Thickness: 30 mm. SUPPLY CONNECTIONS Electric: 230-240V 50Hz AC electrical supply. This appliance complies with the EEC Directive No 89/336, concerning suppression of radio electrical interference. -
Page 11: Installation
Installation IMPORTANT This hob must be installed by qualified personnel to the relevant British Standards. The manufacturer will not accept liability, should the above instructions or any of the other safety instructions incorporated in this book be ignored. Cut Out Size The dimensions of the cut-out are given in the diagram. -
Page 12: Building Over A Kitchen Unit With Door
Building over a kitchen unit with door Proper arrangements must be taken in designing the furniture unit, in order to avoid any contact with the bottom of the hob which can be hot when in operation. The recommended solution is shown in diagram 3. -
Page 13: Electrical Connection
Electrical connections Any electrical work required to install this hob should be carried out by a qualified electrician or competent person, in accordance with the current regulations. THIS HOB MUST BE EARTHED. The manufacturer declines any liability should these safety measures not be observed.
