Toshiba 26HLV66 Service Manual

Lcd color television
Hide thumbs Also See for 26HLV66:

Advertisement

Quick Links

Download this manual
SERVICE MANUAL
For Technical Bulletins, Technical Tips, or other information regarding the
service of this model, visit the Toshiba America Consumer Products National
Service Division website at:
This model is classified as a
This Service Manual describes replacement parts for the green product. When repairing this
green product, use the part(s) described in this manual and
For (*1) and (*2), refer to
SOLDER.
© TOSHIBA CORPORATION 2009
LCD Color Television
26HLV66
www7.toshiba.com
green product
(*1), as indicated by the underlined serial number.
GREEN PRODUCT PROCUREMENT
Rev.1
lead-free solder
(*2).
and
LEAD-FREE

Advertisement

loading

Related Manuals for Toshiba 26HLV66

Summary of Contents for Toshiba 26HLV66

  • Page 1 SERVICE MANUAL LCD Color Television 26HLV66 Rev.1 For Technical Bulletins, Technical Tips, or other information regarding the service of this model, visit the Toshiba America Consumer Products National Service Division website at: www7.toshiba.com This model is classified as a green product (*1), as indicated by the underlined serial number.

  • Page 2: Important Notice

    EXPRESS OR IMPLIED WARRANTY OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. Toshiba shall not be liable for any damages, losses, expenses or costs, if any, incurred in connection with or as a result of use of any information or data provided herein.
  • Page 3 that have these same characteristics. Use only the specified parts when the mark is indicated in the circuit diagram or parts list. Part mounting and wire routing should be the same as that used originally. For safety purposes, insulating materials such as isolation tubes or tape are sometimes used and printed circuit boards are sometimes mounted floating.
  • Page 4 fluid should contact the skin or clothing, wipe off with alcohol, etc., and rinse thoroughly with water. If the fluid should enter the eyes, immediately rinse the eyes thoroughly with running water. When attaching the LCD module to the LCD cover, position it appropriately and fasten at the position where the display can be viewed most conveniently.
  • Page 5 CMOS-LSI circuitry is used in the LCD module, so avoid damage due to static electricity. When handling the module, use a wrist ground or anchor ground. Do not expose the LCD module to direct sunlight or strong ultraviolet rays for extended periods. Do not store the LCD module below the temperature conditions described in the specifications.
  • Page 6 Entering Service Mode Set VOLUME to minimum and press MUTE button twice on the remote control. Press MUTE button again and hold button down. Service Mode display While holding the MUTE button, press MENU button on TV set. Selecting the Adjusting Item Every pressing of CH button in the service mode changes the adjustment items.

  • Page 7: Led Status Indications

    LED STATUS INDICATIONS ______________________________________________________________________________ 2007 Toshiba America Consumer Products, LLC. Page 12 of 13 SMART2006002_Version1.1...
  • Page 8 Terminal PCB CN90A P812A Replace Seine/ Replace Low B P804 CN90A Digital PCB P803B LowB PCB Power PCB CN61 P811B AV Terminal PCB TP12 CN49A CN81 D-Tuner Seine PCB ______________________________________________________________________________ 2007 Toshiba America Consumer Products, LLC. Page 5 of 13 SMART2006002_Version1.1...
  • Page 9 See Page 2 of 6 for Connector and Plug Locations ______________________________________________________________________________ 2007 Toshiba America Consumer Products, LLC. Page 6 of 13 SMART2006002_Version1.1...
  • Page 10 Replace AV/ HDMI OK? Supply OK? Main Power PCB Terminal PCB Replace Low B Replace Seine/ Digital PCB See Page 2 of 6 for Connector and Plug Locations ______________________________________________________________________________ 2007 Toshiba America Consumer Products, LLC. Page 7 of 13 SMART2006002_Version1.1...
  • Page 11 ______________________________________________________________________________ 2007 Toshiba America Consumer Products, LLC. Page 8 of 13 SMART2006002_Version1.1...
  • Page 12 ______________________________________________________________________________ 2007 Toshiba America Consumer Products, LLC. Page 9 of 13 SMART2006002_Version1.1...

  • Page 18: Replacement Parts List

    Replacement Parts List Location Part No. Description A201 75002662 CESE/COVER/LID FRONT BEZEL ASSY A320 75002330 PIECE FRONT AV ASSY A340 75001920 PIECE BUTTON 7 KEY A401 75002661 CESE/COVER/LID BACK COVER ASSY A420 75002331 LEG STAND ASSY A541 75002663 PANEL DVD PANEL ASSY A545 75002660 CESE/COVER/LID CASE DVD BOTTOM B001...
  • Page 19 Replacement Parts List Location Part No. Description CE40 76073180 ELECTROLYTIC, 35V 33UF M CE41 76073139 ELECTROLYTIC, 10V 470UF M 3A CE42 76073137 ELECTROLYTIC, 10V 100UF M CE43 76567104 PLASTIC FILM, 50V 0.1UF J CE44 76092726 CERAMIC CHIP, 10V B 2.2UF K CE52 76092179 CERAMIC CHIP, 25V B 0.22UF K CE53...
  • Page 20 Replacement Parts List Location Part No. Description DE14 23357512 DIODE, AL01Z DE15 23357892 DIODE, ZENER, MTZJ27B DE16 23357880 DIODE, ZENER, MTZJ20B DE17 23357512 DIODE, AL01Z DE19 23357854 DIODE, ZENER, MTZJ10B DE51 23357842 DIODE, ZENER, MTZJ6.8B DE52 23357703 DIODE, 1SS355 DE53 23357842 DIODE, ZENER, MTZJ6.8B DE54 23357703 DIODE, 1SS355...
  • Page 21 Replacement Parts List Location Part No. Description LE53 23289049 COIL, PEAKING, TRF4330AU LE72 23248417 COIL, CHOKE, TLN3481AH LE73 23248417 COIL, CHOKE, TLN3481AH LE74 23248417 COIL, CHOKE, TLN3481AH LE76 23248417 COIL, CHOKE, TLN3481AH P800 23713702 PLUG, 2P 11.88MM W VT P801 23372264 POWER CORD, U/C 125V10A HSV 5 CMC 02P 11111 P803B 23713819 SOCKET, TWG P23X A1...
  • Page 22 Replacement Parts List Location Part No. Description R807 76366153 CARBON FILM, 1/6W 15K OHM J R808 76552221 OXIDE METAL FILM, 1/2W 220 OHM J R809 76321689 OXIDE METAL FILM, 1/2W 6.8 OHM J R812 76552681 OXIDE METAL FILM, 1/2W 680 OHM J R813 76366120 CARBON FILM, 1/6W 12 OHM J R814...
  • Page 23 Replacement Parts List Location Part No. Description RE59 76011334 CHIP, 1/20W 330K OHM J RE60 76011184 CHIP, 1/20W 180K OHM J RE61 76000605 CHIP, 1/16W 6.8K OHM F RE63 76000445 CHIP JUMPER, 1608TYPE RE64 76366151 CARBON FILM, 1/6W 150 OHM J RE64A 23965241 TAPE, CC #12 10MM L30M RE67...
  • Page 24 TOSHIBA CORPORATION 1-1, SHIBAURA 1-CHOME, MINATO-KU, TOKYO 105-8001, JAPAN...
