Installation

The oven must be installed according to
the instructions supplied.
Technical Data
DIMENSIONS Height
OF RECESS Width
Depth
DIMENSIONS Height
OF THE Width
OVEN CAVITY Depth
Oven capacity 53.2 litres

Electrical Connection

The oven is designed to be connected to 230-240V
(50Hz) electricity supply.
The oven has an easily accessible terminal block which
is marked as follows:
Letter L - Live terminal
Letter N - Neutral terminal
- Earth terminal
THIS OVEN MUST BE EARTHED
This oven is provided with a a type H05RR-F connection
cable with section 3x1,5 mm
It is necessary that you install a double pole switch
between the oven and the electricity supply (mains),
with a minimum gap of 3mm between the switch contacts
and of a type suitable for the required load in compliance
with the current rules.
The switch must not break the yellow and green earth
cable at any point.
20
580 mm.
560-570 mm.
550 mm.
320 mm.
420 mm.
390 mm.
2
.
This oven must be installed by qualified
personnel to the relevant British Standards.
Heating elements rating
Oven element
Top element
Bottom element
Convection element
Grill element
Double Grill element
Convection Fan
Oven Light
Cooling Fan
Total Rating (230-240 V)
Important
After installation and connecting, the cable must be
placed so that it cannot at any point reach a temperature
of more than 60 C above the ambient temperature.
Before the oven is connected, check that the main fuse
and the domestic installation can support the load; and
that the power supply is properly earthed.
The manufacturer disclaims any
responsibility should these safety
measures not be carried out.
1.8 kW
0.8 kW
1.0 kW
2.0 kW
1.75 kW
2.55 kW
30 W
25 W
25 W
2.6 kW
