PORTABLE AIR CONDITIONER
Operator's manual
Customer Service / Service à la clientèle:
Our Customer service staff is available to help you. For any problem with your purchase, or to receive further
information about this product, please call our toll-free number.
SAVE THIS MANUAL
Keep this manual and the original sales invoice in a safe, dry place for future reference.
Notre personnel du service à la clientèle est disponible pour vous aider. En cas de problème avec votre achat, ou pour
obtenir plus d'informations à propos de ce produit, veuillez composer notre numéro sans frais.
CONSERVEZ CE GUIDE
Conservez ce manuel avec la facture d'origine dans un endroit sûr et sec pour référence future.
Model/modèle : 87795054
MPPD-12CRN1-BI0
1-866-206-0888
Advertisement
Table of Contents
Related Manuals for Arctic King MPPD-12CRN1-BI0
Summary of Contents for Arctic King MPPD-12CRN1-BI0
- Page 1 Model/modèle : 87795054 MPPD-12CRN1-BI0 PORTABLE AIR CONDITIONER Operator's manual 1-866-206-0888 Customer Service / Service à la clientèle: Our Customer service staff is available to help you. For any problem with your purchase, or to receive further information about this product, please call our toll-free number.
-
Page 2: Table Of Contents
Contents Preparation.............................2 Safety Precautions..........................3 Cautions..............................4 Installation..............................5 Operation..............................9 Maintenance............................14 Faults Diagnosis..........................15 Design and Compliance Notes......................16 Sociable Remarks ..........................17 Remote Controller Illustration......................18 Air Conditioner Limited Warranty......................31... -
Page 3: Preparation
Preparation Control panel Horizontal louver blade (swing automatically) Handle (both sides) Caster Front Upper air filter (behind the grille) Upper air intake Drain outlet Air outlet Lower air filter /lower air intake Drain outlet (only for pump heating mode) Power cord outlet Power cord buckle Power plug socket Bottom tray... -
Page 4: Safety Precautions
Safety Precautions Please read through these instructions before you start the installation process. Improper installation can cause damage to the unit, your personal property, and also poses a personal safety hazard. -Installation must be performed according to the installation instructions. Improper installation can cause water leakage, electrical shock, or fire. -
Page 5: Cautions
Cautions -This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory, or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning the use of the appliance in a safe way and understand the hazards involved. -
Page 6: Installation
Installation Choosing the Right Location Your installation location should meet the following requirements: -Make sure that you install your unit on an even surface to minimize noise and vibration. -The unit must be installed near a grounded plug and the collection tray drain (on the back of the unit) must be accessible. - Page 7 Installation Tools Needed -Medium Philips screwdriver; -Tape measure or ruler; -Knife or scissors; -Saw (optional to shorten the window adaptor for narrow windows). Accessories Your window installation kit fits windows from 67.5-123 cm(26.5-48”) and can be shortened for smaller windows. Part Description Quantity...
- Page 8 Installation Step 3: Preparing the Adjustable Window Slider Bolt Bolt 1. Depending on the size of your window, adjust the size of the window slider. 2. If the length of the window requires two Window slider A Window slider B Window slider C window sliders, use the bolt to fasten the window sliders once they are adjusted to...
- Page 9 Installation Type 2: Sliding Window Installation Foam seal B Foam seal C (shorter adhesive type) (non-adhesive type) Window slider B (if required) Foam seal A (adhesive type) Window slider A Cut the adhesive foam seal Insert the window slider Cut the non-adhesive foam A and B strips to the proper assembly into the window seal C strip to match the...
-
Page 10: Operation
Operation Up (+) and Down (-) Buttons Swing Button (Optional) Used to initiate the auto-swing Used to adjust (increasing/decreasing) feature(for models with the auto temperature settings in 1°C/1°F swing feature only). When the increments in a range of 17°C/62°F to unit is ON, pressing the SWING 30°C/86°F or the TIMER setting in a button can stop the louver at the... - Page 11 Operation LED Display Shows the set temperature in °C or °F and the "Auto timer" settings. While on DRY and FAN modes, it shows the room temperature. Shows error and protection codes : E1-Room temperature sensor error. E2-Evaporator temperature sensor error. E3-Condenser temperature sensor error (on some models).
- Page 12 Operation AUTO Operation -When setting the air conditioner in AUTO mode, it will automatically select cooling, heating (for models without cooling only), or fan only operation depending on the selected temperature and room temperature. -The air conditioner automatically will control the room temperature a round the temperature point that you set.
- Page 13 Operation Other Features FOLLOW ME/TEMP SENSING Feature (Optional) NOTE: This feature can be activated from the remote controller ONLY. The remote controller serves as a remote thermostat allowing for precise temperature control at its location.To activate the "Follow Me/Temp Sensing" feature, point the remote controller towards the unit and press the "Follow Me/Temp Sensing"...
- Page 14 Operation -Under heating pump mode, remove the lower drain plug from the back of the unit and install the drain connector (5/8" universal female mender) with a 3/4" hose (locally purchased). For models without a drain connector, simply attach the drain hose to the hole. Place the open end of the hose adaptor directly over the drain area in your basement floor.
-
Page 15: Maintenance
Maintenance Safety Precautions -Always unplug the unit before cleaning or servicing. -DO NOT use flammable liquids or chemicals to clean the unit. -DO NOT wash the unit under running water. This may cause an electrical danger. -DO NOT operate the machine if the power supply was damaged during cleaning. A damaged power cord must be replaced with a new cord from the manufacturer. -
Page 16: Faults Diagnosis
Faults Diagnosis Please check the unit using the following form before asking for maintenance: Problem Possible Cause Troubleshooting The water collection tray is full.Turn off P1 error code. the unit, drain the water from the water The unit does not collection tray, and restart the unit. -
Page 17: Design And Compliance Notes
Design and Compliance Notes Design Notice In order to ensure the optimal performance of our products, the design specifications of the unit and remote controller are subject to change without prior notice. Energy Rating Information The energy rating for this unit is based on an installation using an un-extended exhaust duct without adapters A or B (as shown in the Installation section of this manual). -
Page 18: Sociable Remarks
Environmental Remarks When using this dehumidifier in European countries, the following instructions must be followed: DISPOSAL: Do not dispose of this product as unsorted municipal waste. It must be collected for special treatment. It is prohibited to dispose of this appliance in domestic household waste. For disposal, there are several possibilities: A) The municipality has established collection systems, where electronic waste can be disposed of free of charge for the user. -
Page 19: Remote Controller Illustration
Remote Controller Illustration Remote Control Specifications RG57H(B)/BG(C)E; RG57H1(B)/BG(C)E; RG57H2(B)/BG(C)EF; Model RG57H3(B)/BG(C)EF;RG57H1(B)/BG(C)E-M;RG57H(B)/BG(C)EU1 3.0 V (dry batteries R03/LR03×2) Rated voltage Signal receiving range Environment -5 C~60 C (23 F~140 F) - Page 20 Remote Controller Illustration Function Buttons Before using your new air conditioner, make sure to familiarize yourself with the remote controller. The following is a brief introduction to the remote controller. For instructions on how to operate your air conditioner, refer to the "How to Use the Basic Functions" section of this manual. SHORT CUT ON/OFF Sets and activates your...
- Page 21 Remote Controller Illustration Handling the Remote Controller TIPS FOR USING THE REMOTE CONTROLLER The remote controller must be used within 8 UNSURE ABOUT A FUNCTION meters of the unit. Refer to the "How to Use Basic Functions" and "How to Use Advanced Functions" sections The unit will beep when the remote signal is of this manual for a detailed description of received.
- Page 22 Remote Controller Illustration Remote LED Screen Indicators Transmission indicator Lights up when the remote sends asignal to the unit. ON/OFF display MODE display Appears when the unit is turned on Displays the current and disappears when it is turned off. mode, including: TIMER OFF display TIMER ON display...
- Page 23 Remote Controller Illustration How to Use the Basic Functions SETTING THE TEMPERATURE The operating temperature range for units is 17-30 C (62 F-86 F). You can increase or decrease the set tem perature in 1 C (1 F) increments. AUTO Operation In Auto mode, the unit will automatically select the COOL, FAN, HEAT, or DRY mode based on the set temperature.
- Page 24 Remote Controller Illustration How to Use the Basic Functions DRY Operation (dehumidifying) 1. Press the MODE button to select the DRY mode. 2. Set your desired temperature using the Temp or Temp button. 3. Press the ON/OFF button to start the unit. NOTE: FAN SPEED cannot be changed in DRY mode.
- Page 25 Remote Controller Illustration How to Use the Basic Functions HEAT Operation 1. Press the MODE button to select the HEAT mode. 2. Set your desired temperature using the Temp or Temp button. 3. Press the FAN button to select the fan speed: AUTO, LOW, MED,or HIGH.
- Page 26 Remote Controller Illustration Setting the TIMER Function Your air conditioning unit has two timer-related functions: TIMER ON- sets the amount of time after which the unit will automatically turn on. TIMER ON TIMER ON TIMER OFF- sets the amount of time after which the unit will automatically turn off.
- Page 27 Remote Controller Illustration TIMER OFF Function The TIMER OFF function allows you to NOTE: When setting the TIMER ON or set a period of time after which the unit TIMER OFF functions up to 10 hours, will automatically turn off for instance when the time will increase in 30-minute you wake up.
- Page 28 Remote Controller Illustration Setting TIMER ON and TIMER OFF at the Same Time Keep in mind that the time periods you set for both functions refer to hours after the current time. For example, if the current time is 1:00 PM and you want the unit to turn on automatically at 7 PM, operate for 2 hours, and automa-tically turn off at 9 PM, do the following: TIMER ON...
- Page 29 Remote Controller Illustration Example: Setting the unit to turn on after 6 hours, operate for 2 hours, then turn off (see the figure below). Your remote display Timer on Timer is set to turn ON 6 hours from the current time Timer off Timer is set to turn OFF 8 hours from the current time...
- Page 30 Remote Controller Illustration How to Use the Advanced Functions SLEEP Function The SLEEP function is used to decrease energy use while sleeping the same temperature settings to stay comfortable are not necessary). This function can only be activated with the remote controller.
- Page 31 Remote Controller Illustration NOTE: -Buttons design is based on a typical model and may be slightly different from the actual unit you purchased. In such case, actual unit buttons shall prevail. -All the functions described are accomplished by the unit. Inoperative features on the unit.
-
Page 32: Air Conditioner Limited Warranty
Air Conditioner Limited Warranty These products have been made to quality standards and are guaranteed for domestic use against manufacturing faults for a period of 5 years from the date of purchase. One (1) year full warranty from original purchase date and limited 2nd through 5th year sealed system warranty if used for normal trade purposes.
