12V AUXILIARY
POWER SOCKET
Owner's Manual
Disclaimer
This product has been tested to the relevant Australian design rules. Toyota is not responsible
for any direct or indirect damage or injury caused by the intentional misuse of this product.
This product must be installed in accordance with supplied fitting instructions. The Toyota 12V
Auxiliary Power Socket must not be altered in any way.
The 12V Auxiliary Power Socket includes Smart Circuitry that is designed to isolate any
connected devices before the vehicle's battery state of charge is reduced to a level which may
compromise vehicle restart. We recommend users limit the number of times they discharge the
vehicle's battery to the point of isolation cut off, as repeated discharging may reduce the life of
the vehicle battery. External factors which may influence the cut off include (but not limited to):
-
Poor vehicle battery health. This includes batteries which have been damaged from previous
flattening or the age of the vehicle battery. Vehicle batteries in this condition hold reduced
charge.
-
Extreme temperatures.
-
Other uncontrolled accessories connected directly to the vehicle battery (not monitored
through the 12V Auxiliary Power Socket).
If any of the above circumstances are present, we recommend caution when running any
connected device into battery protection mode.
Important
Do not use a high pressure spray to clean the 12V
Auxiliary Power Socket.
ISSUE 1 09/07/20
No part of this publication may be copied, reproduced or
© 2020 Toyota Motor Corporation Australia Ltd
distributed without consent of Toyota Australia.
PZQ85-75295

Advertisement

loading

Summary of Contents for Toyota 12V AUXILIARY POWER SOCKET

  • Page 1 Owner's Manual Disclaimer This product has been tested to the relevant Australian design rules. Toyota is not responsible for any direct or indirect damage or injury caused by the intentional misuse of this product. This product must be installed in accordance with supplied fitting instructions. The Toyota 12V Auxiliary Power Socket must not be altered in any way.

  • Page 2: Table Of Contents

    Thank you for purchasing the Toyota 12V Auxiliary Power Socket. Before using the Toyota 12V Auxiliary Power Socket, thoroughly read this manual and follow instructions for use. Contents Introduction Features Specifications Troubleshooting Information Notes 9-11 ISSUE 1 09/07/20 PZQ85-75295...

  • Page 3: Introduction

    Introduction The 12V Auxiliary Power Socket is a system comprised of twin 12V, 15A power sockets controlled by a smart controller that will allow the sockets to remain powered up even after the vehicle has been turned off. The smart controller allows the 12V, 15A Auxiliary Power to remain active until the estimated vehicle battery state of charge reaches the minimum level required to restart the engine.

  • Page 4: Features

    3 - Correct supply voltage. In all cases the Smart Circuit has the ability to turn off the 12V Auxiliary Power Socket in order to protect the vehicle and also the devices being powered.
  • Page 5 Switch Cargo Illumination The Toyota 12V Auxiliary Power Socket features a LED lamp which contains two high intensity white LEDs for cargo area illumination purposes. The LED lamp is activated / de- activated using the capacitive touch switch located on the side of the socket enclosure.
  • Page 6 Features Continued.. Status LED's Toyota 12V Auxiliary Power Socket has 2 status LED's which illuminate during operation according to the following situations. Green LED will flash slowly for 20 seconds on start up to indicate the system is operating correctly.

  • Page 7: Specifications

    Standby Mode To limit power consumption, the smart circuit will enter standby mode if the Toyota 12V Auxiliary Power Socket and the vehicle have not been used for 96 hours. In standby mode, power to the sockets and cargo illumination is disabled. To restore operation from standby mode, start the vehicle engine.

  • Page 8: Troubleshooting Information

    The details below will determine whether your system has a malfunction. If the system fails to operate after you have completed any of the required actions, you will need to consult the nearest Toyota dealer for support. 1. There are GREEN and/or RED light flashing/staying on. What does this mean? Refer to the Status LED table on Page 6.

  • Page 9: Notes

    Notes ISSUE 1 09/07/20 PZQ85-75295...
  • Page 10 Notes ISSUE 1 09/07/20 PZQ85-75295...
  • Page 11 Notes ISSUE 1 09/07/20 PZQ85-75295...
  • Page 12 Refer to your Toyota Dealer for further information. Toyota Australia uses its best endeavours to ensure material is accurate at the time of publishing. All information must be confirmed with your Toyota dealer at the time of ordering, as specifications, applicability and availability may change over time. Toyota Australia reserves the right to change and/or discontinue, without notice, models, prices, colours, materials, equipment, specifications.
