Owner's Manual & Safety Instructions
Save This Manual
operating, inspection, maintenance and cleaning procedures. Write the product's serial number in the
back of the manual near the assembly diagram (or month and year of purchase if product has no number).
Keep this manual and the receipt in a safe and dry place for future reference.
Email our technical support at: predator@harborfreight.com
When unpacking, make sure that the product is intact
and undamaged. If any parts are missing or broken,
please call 1-888-866-5797 as soon as possible.
©
Copyright
2019 by Harbor Freight Tools
No portion of this manual or any artwork contained herein may be reproduced in
any shape or form without the express written consent of Harbor Freight Tools.
Diagrams within this manual may not be drawn proportionally. Due to continuing
improvements, actual product may differ slightly from the product described herein.
Tools required for assembly and service may not be included.
Keep this manual for the safety warnings and precautions, assembly,
WARNING! TO PREVENT SERIOUS
INJURY: Do not start or operate any internal
combustion engine inside or near Shed.
Visit our website at: http://www.harborfreight.com
®
. All rights reserved.
Read this material before using this product.
Failure to do so can result in serious injury.
SAVE THIS MANUAL.
20f
Advertisement
Summary of Contents for Harbor Freight Tools CoverPro 63297
- Page 1 No portion of this manual or any artwork contained herein may be reproduced in Failure to do so can result in serious injury. any shape or form without the express written consent of Harbor Freight Tools. Diagrams within this manual may not be drawn proportionally. Due to continuing SAVE THIS MANUAL.
- Page 2 Table of Contents Safety ............3 Maintenance ..........10 Specifications ..........4 Parts List............ 11 Assembly ............ 4 Warranty ............ 12 Page 2 For technical questions, please call 1-888-866-5797. 63297...
- Page 3 Do not use grill, heater, These carry important safety information. or ignition sources inside or near cover. If unreadable or missing, contact Harbor Freight Tools for a replacement. SAVE THESE INSTRUCTIONS. 63297 For technical questions, please call 1-888-866-5797.
- Page 4 Specifications Overall Dimensions 10′ W x 10′ L Side Height 6′ 3″ Center Height 8′ 1″ Assembly Instructions Read the ENTIRE IMPORTANT SAFETY INFORMATION section at the beginning of this manual including all text under subheadings therein before set up or use of this product. TO PREVENT SERIOUS INJURY: Do not leave this product partially assembled.
- Page 5 NOTICE: To prevent damage to the material, make sure all hardware is installed with Bolt head towards the cover and Nuts facing inside, away from cover. 2. Connect four Rafters (1) to two 3-Way Rail 4. Connect two Top Rails (2) to tie the 4-Way Connectors (3) using four Bolts (13) and Nuts (14).
- Page 6 3. Attach one Leg and Corner Foot assembly to 4. Attach one Leg and Center Foot assembly to each of the four 3-Way Corner Connectors. each of the two 4-Way Center Connectors. 3-Way 4-Way Corner Center Connector Connector Leg & Leg &...
- Page 7 Square up the Frame TO PREVENT SERIOUS INJURY: Contact local utility companies to ensure that the installation area is free of pipes, cables, and other hazards BEFORE choosing installation area or installing anchors. 1. Position the frame in the desired location, 3.
- Page 8 Attach Roof 1. Stretch Top Cover (19) over the frame, 3. Insert the Rails into the pockets at the making sure it is centered. bottom of the Shed wall and then reinsert the Bottom Rails back into the Clamps. 2. From the inside, on one side of the Shed, remove the Bottom Rails (9) from the Clamps.
- Page 9 Attach Front and Back Covers 1. Position Front Cover (20) so that its zipper pulls are facing toward the outside. Make sure zippers are closed. 2. From inside, wrap the hook and loop straps around the Rails. Make sure to connect all straps.
- Page 10 Maintenance Procedures not specifically explained in this manual must be performed only by a qualified technician. TO PREVENT SERIOUS INJURY FROM PRODUCT FAILURE: Do not use damaged products. If damage is noted, have the problem corrected before further use. Inspection MONTHLY, inspect the general condition of the Portable Shed.
- Page 11 Parts List Note: Individual part illustrations not to scale. Part Description Illustration Part Description Illustration Rafter Bolt M6 x 40 Top Rail/Leg Bolt M6 x 50 3-Way Rail Nut M6 Connector 4-Way Rail Ratchet Tie Down Connector 3-Way Corner Anchor Connector 4-Way Center Wire Rope...
- Page 12 Limited 90 Day Warranty Harbor Freight Tools Co. makes every effort to assure that its products meet high quality and durability standards, and warrants to the original purchaser that this product is free from defects in materials and workmanship for the period of 90 days from the date of purchase.
