MODEL: GT780
SPECIFICATIONS
Maximum power output (2 Ohms): 250W x 4ch
RMS power Output: 100W x 4ch
Bridged Power Output: 500W x 2ch
Frequency response: 9Hz - 50KHz
S/N Ratio: 103dB
Low Pass Crossover (Variable) 45Hz - 90Hz
High Pass Crossover (Fixed) 150Hz
Bass Boost (Variable) 0 - +18dB
Power Source Voltage: 14.4V
Ground: Negative
External dimensions: 236(W)x55(H)x310(D)mm
Advertisement
Table of Contents
Related Manuals for Boss Audio Systems GT780
Summary of Contents for Boss Audio Systems GT780
-
Page 1: Specifications
Service Manual MODEL: GT780 SPECIFICATIONS Maximum power output (2 Ohms): 250W x 4ch RMS power Output: 100W x 4ch Bridged Power Output: 500W x 2ch Frequency response: 9Hz - 50KHz S/N Ratio: 103dB Low Pass Crossover (Variable) 45Hz - 90Hz... - Page 2 To engineers in charge of repair or inspection of our products. Before repair or inspection, make sure to follow the instructions so that customers and Engineers in charge of repair or inspection can avoid suffering any risk or injury. 1. Use specified parts. The system uses parts with special safety features against fire and voltage.
-
Page 3: Exploded View
EXPLODED VIEW - 3 -... -
Page 4: Printed Circuit Board
PRINTED CIRCUIT BOARD - 1 - 4 -... -
Page 5: Circuit Diagram
CIRCUIT DIAGRAM 1 - 5 -... - Page 6 CIRCUIT DIAGRAM 2 - 6 -...
-
Page 7: Parts List
PARTS LIST - 1 - 7 -... - Page 8 PARTS LIST - 2 - 8 -...
- Page 9 PARTS LIST - 3 - 9 -...
