  • Page 1 YZ125T1 (1C31) YZ125 (1C32) EUROPE YZ125 (1C33) JAPAN YZ125T1 (1C34) CANADA,U.S.A.,SOUTH AFRICA OCEANIA 1D1C3-100E1 2D1C3-100E1...
  • Page 2 YZ125T1/YZ125 PARTS CATALOGUE ©2004 by Yamaha Motor Co., Ltd. 1st edition, June 2004 All rights reserved. Any reprinting or unauthorized use without the written permission of Yamaha Motor Co., Ltd. is expressly prohibited. Printed in Japan.
  • Page 4 This Parts Catalogue is related to the parts for the model(s) on the cover page. When you are ordering replacement parts, please refer to this Parts Catalogue and quote both part numbers and part names correctly. 1. Modifications or additions which have been made after the issue of the Parts Catalogue will be announced in the Parts News.
  • Page 5 FOREWORD 7. Applicable Serial No. Engine Serial No. Frame Serial No. 8. Applicable Colour Code (The (*) mark shows Model colour.) Abbreviation Colour Name Colour Code DPBSE(*) DEEP PURPLISH BLUE SOLID E 0583...
  • Page 6 (1) A label called “Model Label” is affixed in the location as indicated in (3) below. When using this parts catalogue, please be sure to cross–reference the “model code – production code No.” in the catalogue with the “model code – production code No.” indi- cated on the Model Label affixed onto the product concerned.

  • Page 7: Table Of Contents

    CONTENTS ENGINE INDEX CYLINDER HEAD ... B2 GOVERNOR ... B4 NUMERICAL INDEX ... M1 CRANKSHAFT & PISTON ... B5 WATER PUMP ... B6 RADIATOR & HOSE ... B7 INTAKE ... B8 CARBURETOR ... B9 EXHAUST ... B12 CRANKCASE ... B13 CRANKCASE COVER 1 ...
  • Page 8 FIG. 1 CYLINDER HEAD REF. PART NO. DESCRIPTION 1 1C3–11111–00 HEAD, CYLINDER 1 2 90116–08394 BOLT, STUD 3 90176–08026 NUT, CROWN 4 90201–080L8 WASHER, PLATE 5 93210–63442 O-RING 6 93210–90785 O-RING 7 1C3–11311–00 CYLINDER 1 8 1C3–11351–00 GASKET, CYLINDER 9 90116–08318 BOLT, STUD 10 90116–08388 BOLT, STUD...
  • Page 9 FIG. 1 CYLINDER HEAD REF. PART NO. DESCRIPTION 27 90508–16134 SPRING, TORSION 28 90387–08785 COLLAR 29 1C3–11992–00 HOUSING 2 30 1C3–11993–00 GASKET 31 97007–05016 BOLT 32 92907–05600 WASHER, PLATE 33 1C3–11995–00 SEAL, HOUSING REMARKS...

  • Page 10: Governor

    FIG. 2 GOVERNOR REF. PART NO. DESCRIPTION 1 4JY–11915–01 PLATE, THRUST 1 2 98507–05012 SCREW, PAN HEAD 3 1C3–11990–00 PUSH ROD ASSY 4 90387–085E1 COLLAR 5 90201–057H5 WASHER, PLATE 6 97007–05012 BOLT 7 93104–08040 OIL SEAL 8 3JE–11922–01 FORK, GOVERNOR 9 91317–04006 BOLT 10 93300–60801...
  • Page 11 FIG. 3 CRANKSHAFT & PISTON REF. PART NO. DESCRIPTION 1 1C3–11400–00 CRANKSHAFT ASSY 2 1C3–11410–00 .CRANKSHAFT 3 1C3–11420–00 .CRANKSHAFT 4 1C3–11651–00 .ROD, CONNECTING 5 3JD–11681–10 .PIN, CRANK 1 6 90209–22326 .WASHER 7 93310–52238 .BEARING 8 1C3–11631–00–A0 PISTON (STD) 1C3–11631–00–B0 PISTON (STD) 1C3–11631–00–C0 PISTON (STD) 1C3–11631–00–D0...

  • Page 12: Water Pump

    FIG. 4 WATER PUMP REF. PART NO. DESCRIPTION 1 1C3–12450–00 IMPELLER SHAFT ASSY 2 1C3–12453–01 GEAR 3 93603–12007 PIN, DOWEL 4 90201–08512 WASHER, PLATE 5 90387–08032 COLLAR 6 93440–07182 CIRCLIP 7 93102–08004 OIL SEAL 8 93102–08307 OIL SEAL 9 93300–60801 BEARING (B0060) 93300–60814 BEARING (608M4ML01)

  • Page 13: Radiator & Hose

    FIG. 5 RADIATOR & HOSE REF. PART NO. DESCRIPTION 1 1C3–1240A–00 RADIATOR ASSY 2 1C3–12465–00 DAMPER, RADIATOR 3 91A20–05065 TUBE, FLEXIBLE VINYL 4 90467–09006 CLIP 5 1C3–12461–00 RADIATOR ASSY 6 5HD–12462–00 CAP, RADIATOR 7 1C3–12465–00 DAMPER, RADIATOR 8 1C3–12481–00 PIPE 1 9 1C3–12482–00 PIPE 2 10 1C3–12483–00...

  • Page 14: Intake

    FIG. 6 INTAKE REF. PART NO. DESCRIPTION 1 1C3–13610–00 REED VALVE ASSY 2 5UN–13613–00 .REED, VALVE 3 5MV–13616–00 .STOPPER, REED VALVE 4 98507–03006 .SCREW, PAN HEAD 5 92907–03100 .WASHER, SPRING 6 1C3–13625–00 SPACER, REED VALVE 7 1C3–13565–00 JOINT, CARBURETOR 8 95027–06020 BOLT, FLANGE 9 90450–54004 HOSE CLAMP ASSY...
  • Page 15 FIG. 7 CARBURETOR REF. PART NO. DESCRIPTION 1 1C3–14101–00 CARBURETOR ASSY 1 1C3–14101–10 CARBURETOR ASSY 1 1C3–14101–20 CARBURETOR ASSY 1 2 5HD–14261–00 .HOLDER 3 4PE–14194–00 .RING 4 3MA–14159–00 .CLIP 5 3JE–14171–00 .PLUNGER, STARTER 6 5UN–14104–00 .AIR SCREW SET 7 1FN–14565–00 .SCREW 8 5ET–14261–01 .HOLDER...
  • Page 16 FIG. 7 CARBURETOR REF. PART NO. DESCRIPTION 20 284–14116–E7 .NEEDLE (6CHY5-82) 284–14116–F3 .NEEDLE (6CHY6-78) 284–14116–F4 .NEEDLE (6CHY6-79) 284–14116–F5 .NEEDLE (6CHY6-80) 284–14116–F6 .NEEDLE (6CHY6-81) 284–14116–F7 .NEEDLE (6CHY6-82) 284–14116–G3 .NEEDLE (6CHY18-78) 284–14116–G4 .NEEDLE (6CHY18-79) 284–14116–G5 .NEEDLE (6CHY18-80) 284–14116–G6 .NEEDLE (6CHY18-81) 284–14116–G7 .NEEDLE (6CHY18-82) 21 4KM–14142–40 .JET, PILOT (# 40) 4KM–14142–30...
  • Page 17 FIG. 7 CARBURETOR REF. PART NO. DESCRIPTION 22 137–14143–88 .JET, MAIN (#440) 137–14143–90 .JET, MAIN (#450) 23 1C3–14112–40 .VALVE, THROTTLE 1 (4.0) 1C3–14112–42 .VALVE, THROTTLE 1 (4.25) 24 5ET–1416A–00 .O-RING 25 5ET–14147–00 .O-RING 26 51R–14146–00 .PLATE 27 98502–05014 .SCREW, PAN HEAD 28 2HH–14197–00 .PIPE 29 87M–14137–00...

  • Page 18: Exhaust

    FIG. 8 EXHAUST REF. PART NO. DESCRIPTION 1 1C3–14610–00 EXHAUST PIPE ASSY 1 2 5MV–14642–00 SEAL, EXHAUST 3 90506–20012 SPRING, TENSION 4 565–14771–00 STAY, MUFFLER 1 5 95027–06012 BOLT, FLANGE 6 1C3–14763–00 SPACER 7 90201–06060 WASHER, PLATE 8 95027–06025 BOLT, FLANGE 9 5CU–14771–01 STAY, MUFFLER 1 10 90480–16561...

  • Page 19: Crankcase 1

    FIG. 9 CRANKCASE REF. PART NO. DESCRIPTION 1 1C3–15111–00 CRANKCASE 1 2 1C3–15121–00 CRANKCASE 2 3 353–13115–01 CONNECTOR, SUCTION PIPE 4 90445–08605 HOSE 5 99530–10116 PIN, DOWEL 6 95027–10016 BOLT, FLANGE 7 90430–10188 GASKET 8 91317–06045 BOLT 9 91317–06055 BOLT 10 91317–06065 BOLT 11 91317–06075...

  • Page 20: Crankcase Cover 1

    FIG. 10 CRANKCASE COVER 1 REF. PART NO. DESCRIPTION 1 1C3–15411–00 COVER, CRANKCASE 1 2 1C3–15451–00 GASKET, CRANKCASE COVER 1 3 98507–06030 SCREW, PAN HEAD 4 92907–06600 WASHER, PLATE 5 1C3–15421–00 COVER, CRANKCASE 2 6 1C3–17466–00 GUIDE, CHAIN 7 98507–06030 SCREW, PAN HEAD 8 1C3–15431–00 COVER, CRANKCASE 3...

  • Page 21: Starter

    FIG. 11 STARTER REF. PART NO. DESCRIPTION 1 1C3–15651–00 GEAR, KICK IDLE 2 90201–175F6 WASHER, PLATE 3 99009–17400 CIRCLIP 4 1C3–15660–00 KICK AXLE ASSY 5 1C3–15641–00 GEAR, KICK 6 90468–26048 CLIP 7 90508–26450 SPRING, TORSION 8 90201–171G4 WASHER, PLATE 9 1C3–15666–00 SPACER 10 93102–17263 OIL SEAL...

  • Page 22: Clutch

    FIG. 12 CLUTCH REF. PART NO. DESCRIPTION 1 1C3–16111–00 GEAR, PRIMARY DRIVE 2 90387–172K2 COLLAR 3 90105–08071 BOLT, FLANGE 4 1C3–16150–00 PRIMARY DRIVEN GEAR COMP. 5 5NY–16371–00 BOSS, CLUTCH 6 3XJ–16324–01 PLATE, CLUTCH 1 7 3XJ–16321–00 PLATE, FRICTION 8 5HD–16351–00 PLATE, PRESSURE 1 9 90501–23598 SPRING, COMPRESSION...

  • Page 23: Transmission

    FIG. 13 TRANSMISSION REF. PART NO. DESCRIPTION 1 93306–00442 BEARING 2 4JT–15381–01 PLATE, BEARING COVER 3 90149–06326 SCREW 4 1C3–17411–10 AXLE, MAIN (13T) 5 1C3–17161–10 GEAR, 6TH PINION (21T) 6 90201–22555 WASHER, PLATE 7 93410–22039 CIRCLIP 8 1C3–17131–10 GEAR, 3RD PINION (17T/17T) 9 90209–18135 WASHER 10 1C3–17151–10...
  • Page 24 FIG. 13 TRANSMISSION REF. PART NO. DESCRIPTION 28 93102–28012 OIL SEAL 29 90387–22004 COLLAR 30 9383B–13218 SPROCKET, DRIVE (13T) 31 90215–20003 WASHER, LOCK 32 90179–18001 REMARKS...

  • Page 25: Shift Cam & Fork

    FIG. 14 SHIFT CAM & FORK REF. PART NO. DESCRIPTION 1 1C3–18541–00 CAM, SHIFT 2 93306–90408 BEARING 3 90105–06553 BOLT, FLANGE 4 1C3–18562–00 PLATE, STOPPER 2 5 1C3–18140–00 STOPPER LEVER ASSY 6 90508–261B7 SPRING, TORSION 7 90109–063F8 BOLT 8 1C3–18511–00 FORK, SHIFT 1 9 1C3–18512–00 FORK, SHIFT 2...

  • Page 26: Shift Shaft

    FIG. 15 SHIFT SHAFT REF. PART NO. DESCRIPTION 1 1C3–18185–00 SEGMENT 2 1C3–18101–00 SHIFT SHAFT ASSY 3 5LP–18122–01 LEVER, SHIFT 2 4 90508–29020 SPRING, TORSION 5 90560–12280 SPACER 6 90201–12020 WASHER, PLATE 7 93104–12003 OIL SEAL 8 93608–33002 PIN, DOWEL 9 1C3–18110–00 SHIFT PEDAL ASSY 10 95027–06020...

  • Page 27: Frame

    FIG. 16 FRAME REF. PART NO. DESCRIPTION 1 1C3–21101–00 FRONT FRAME COMP. 2 1C3–21190–00 REAR FRAME COMP. 3 5GJ–21717–00 DAMPER 4 90105–08057 BOLT, FLANGE 5 90105–08120 BOLT, FLANGE 6 30X–22178–00 TENSIONER 7 4V4–22184–00 BUSH 8 90201–08039 WASHER, PLATE 9 90387–08027 COLLAR 10 95027–08040 BOLT, FLANGE...
  • Page 28 FIG. 16 FRAME REF. PART NO. DESCRIPTION REMARKS 28 5ET–28166–00 WRENCH, HEXAGON...

  • Page 29: Fender

    REF. PART NO. DESCRIPTION 1 5HD–21511–00 FENDER, FRONT 2 90387–06090 COLLAR 3 90119–06096 BOLT, WITH WASHER 4 4ES–2153E–01 EMBLEM, YAMAHA 5 5XE–21610–00 REAR FENDER COMP. 6 5XE–21635–00 .NUT, REAR FENDER 7 90105–06045 BOLT, FLANGE 8 90201–062A8 WASHER, PLATE 9 90105–06046 BOLT, FLANGE 10 90201–06071...

  • Page 30: Side Cover

    FIG. 18 SIDE COVER REF. PART NO. DESCRIPTION 1 5NY–21711–00 COVER, SIDE 1 2 95827–06016 BOLT, FLANGE 3 90119–08238 BOLT, WITH WASHER 4 5NY–21721–00 COVER, SIDE 2 5 95827–06016 BOLT, FLANGE 6 90119–08238 BOLT, WITH WASHER 7 5XE–21730–00 SIDE COVER ASSY 3 8 1C3–2173E–00 GRAPHIC 1 9 90105–06055...

  • Page 31: Rear Arm

    FIG. 19 REAR ARM REF. PART NO. DESCRIPTION 1 1C3–22110–00 REAR ARM COMP. 2 90151–04001 SCREW, COUNTERSUNK 3 1C3–22355–00 PATCH 4 93317–22262 BEARING 5 93342–22217 BEARING 6 93106–22019 OIL SEAL (DC 22-28-8) 7 93109–28043 OIL SEAL 8 90387–18008 COLLAR 9 90387–18009 COLLAR 10 1C3–22151–00 SEAL, GUARD...
  • Page 32 FIG. 19 REAR ARM REF. PART NO. DESCRIPTION 28 93109–21001 OIL SEAL 29 90387–14005 COLLAR 30 1C3–22121–00 SHAFT 1 31 1C3–22122–00 SHAFT 2 32 90201–14740 WASHER, PLATE 33 90185–14007 NUT, SELF-LOCKING 34 1C3–2135F–00 COVER 35 1C3–2139R–00 COVER 2 36 5UN–2153A–00 EMBLEM, YAMAHA REMARKS...

  • Page 33: Rear Suspension

    FIG. 20 REAR SUSPENSION REF. PART NO. DESCRIPTION 1 1C3–22210–00 SHOCK ABSORBER ASSY, REAR 1C3–22210–30 SHOCK ABSORBER ASSY, REAR 1C3–22210–40 SHOCK ABSORBER ASSY, REAR 1C3–22210–10 SHOCK ABSORBER ASSY, REAR 1C3–22210–20 SHOCK ABSORBER ASSY, REAR 2 1C3–22201–00 .DAMPER SUB ASSY 1C3–22201–30 .DAMPER SUB ASSY 1C3–22201–40 .DAMPER SUB ASSY...
  • Page 34 FIG. 20 REAR SUSPENSION REF. PART NO. DESCRIPTION 20 92907–10200 WASHER, PLAIN 21 5NY–22241–00 BOLT 1 22 90185–10060 NUT, SELF-LOCKING REMARKS...

  • Page 35: Steering

    FIG. 21 STEERING REF. PART NO. DESCRIPTION 1 93332–00068 BEARING 2 4EW–23416–00 COVER, BALL RACE 2 3 90179–28003 4 90201–286K9 WASHER, PLATE 5 5XE–23435–20 CROWN, HANDLE 6 5TA–23357–00 7 90201–247L2 WASHER, PLATE 8 5TJ–2319U–00 9 5XE–23441–00 HOLDER, HANDLE UPPER 10 95027–08035 BOLT, FLANGE 11 95027–08040 BOLT, FLANGE...

  • Page 36: Front Fork

    FIG. 22 FRONT FORK REF. PART NO. DESCRIPTION 1 1C3–23102–00 FRONT FORK ASSY (L.H) 1C3–23102–10 FRONT FORK ASSY (L.H) 2 1C3–23136–L0 .TUBE, OUTER 3 1C3–23120–L0 .INNER TUBE COMP.2 4 5XE–23171–L0 .PISTON, FRONT FORK 5 5XE–23125–L0 .METAL, SLIDE 1 6 5XE–23146–L0 .WASHER, OIL SEAL 7 1C3–23145–L0 .OIL SEAL...
  • Page 37 FIG. 22 FRONT FORK REF. PART NO. DESCRIPTION 24 1C3–23103–00 FRONT FORK ASSY (R.H) 1C3–23103–10 FRONT FORK ASSY (R.H) 25 1C3–23136–L0 .TUBE, OUTER 26 1C3–23110–L0 .INNER TUBE COMP.1 27 5XE–23171–L0 .PISTON, FRONT FORK 28 5XE–23125–L0 .METAL, SLIDE 1 29 5XE–23146–L0 .WASHER, OIL SEAL 30 1C3–23145–L0 .OIL SEAL...
  • Page 38 48 5NY–23346–L0 BOLT 1 49 93332–00081 BEARING 50 5XE–23389–00 GUIDE, CABLE 51 95027–06020 BOLT, FLANGE 52 5XE–23113–00 COLLAR 53 1C3–2314J–00 PROTECTER COMP., 2 54 4XL–2153A–10 .EMBLEM, YAMAHA 55 1C3–2314H–00 PROTECTER COMP., 1 56 4XL–2153A–10 .EMBLEM, YAMAHA 57 3SP–23356–L0 BOLT 2 REMARKS...

  • Page 39: Fuel Tank

    FIG. 23 FUEL TANK REF. PART NO. DESCRIPTION 1 1C3–24110–00 FUEL TANK COMP. 2 5NY–24610–00 CAP ASSY 3 90445–09220 HOSE (L30) 4 3XJ–24380–00 PIPE JOINT ASSY 5 90445–09025 HOSE 6 5XE–24144–00 HOLDER, DAMPER 7 90480–18549 GROMMET 8 95027–06016 BOLT, FLANGE 9 5XE–24176–00 BOLT 1 10 5NY–24186–00...
  • Page 40 FIG. 23 FUEL TANK REF. PART NO. DESCRIPTION REMARKS 28 1C3–24184–00 DAMPER, LOCATING 4...

  • Page 41: Seat

    FIG. 24 SEAT REF. PART NO. DESCRIPTION 1 5XE–24770–00 SEMI-DOUBLE SEAT ASSY 2 5XE–2470F–00 .SEAT COVER COMP. 3 5NY–24728–00 .BRACKET, SEAT 4 97307–06012 .BOLT 5 92907–06100 .WASHER, SPRING REMARKS...

  • Page 42: Front Wheel

    FIG. 25 FRONT WHEEL REF. PART NO. DESCRIPTION 1 5NY–25111–00 HUB, FRONT 2 93306–90403 BEARING 3 5NY–25117–00 SPACER, BEARING 4 93102–26468 OIL SEAL 5 94416–21003 RIM (1.60-21) 6 5NY–25104–00 SPOKE SET, FRONT 7 94108–2112Y TIRE (80/100-21 51M D755F) 94108–21015 TIRE (80/100-21 51M D739FA) 94108–21012 TIRE(80/100-21 51M M601) 8 94227–21101...

  • Page 43: Front Brake Caliper

    FIG. 26 FRONT BRAKE CALIPER REF. PART NO. DESCRIPTION 1 1C3–23466–00 CLAMP 2 1C3–23467–00 CLAMP 3 95707–06500 NUT, FLANGE 4 5MV–2581T–00 DISK BRAKE ASSY 5 90149–06327 SCREW 6 1C3–2580T–00 CALIPER ASSY (LEFT) 7 5UN–W0057–00 .PISTON ASSY, CALIPER 8 3JD–W0047–00 ..CALIPER SEAL KIT 9 5DH–25919–00 .SUPPORT, PAD 10 1UY–W0048–50...
  • Page 44 FIG. 27 REAR WHEEL REF. PART NO. DESCRIPTION 1 5ET–25311–00 HUB, REAR 2 5ET–25317–00 SPACER, BEARING 3 93306–27205 BEARING 4 93306–07202 BEARING 5 93106–30044 OIL SEAL 6 93106–30045 OIL SEAL 7 99009–45500 CIRCLIP 8 94418–19601 RIM (1.85-19) 9 5HD–25304–00 SPOKE SET, REAR 10 94110–1913B TIRE (100/90-19 57M D755) 94110–19011...

  • Page 45: Rear Wheel

    FIG. 27 REAR WHEEL REF. PART NO. DESCRIPTION 19 90480–08608 GROMMET 20 5UN–25383–00 COLLAR, WHEEL 21 5ET–25367–00 COVER, HUB DUST 22 1C3–25388–00 PULLER, CHAIN 1 23 1C3–25389–00 PULLER, CHAIN 2 24 90101–08777 BOLT 25 90179–08299 26 1C3–25381–00 AXLE, WHEEL 27 90185–20168 NUT, SELF-LOCKING 28 90201–203U1 WASHER, PLATE...

  • Page 46: Rear Brake Caliper

    FIG. 28 REAR BRAKE CALIPER REF. PART NO. DESCRIPTION 1 5NY–2582W–00 DISK, REAR BRAKE 2 2 90109–065G4 BOLT 3 1C3–2580W–00 CALIPER ASSY, REAR 2 4 5UN–W0057–50 .PISTON ASSY, CALIPER 5 5UN–W0047–50 ..CALIPER SEAL KIT 6 5DH–25919–50 .SUPPORT, PAD 7 1UY–W0048–50 .BLEED SCREW KIT 8 1C3–W0046–00 .BRAKE PAD KIT 2...

  • Page 47: Steering Handle & Cable

    FIG. 29 STEERING HANDLE & CABLE REF. PART NO. DESCRIPTION 1 1C3–26111–00 HANDLEBAR 2 4GY–26241–00 GRIP 3 4XM–26240–00 GRIP ASSY 4 4GY–26242–00 .GRIP (RIGHT) 5 4XM–26243–00 .TUBE, THROTTLE GUIDE 6 4SS–26281–00 CAP, GRIP UPPER 7 4SS–26282–10 CAP, GRIP LOWER 8 4SS–2628H–00 CAP, WIRE 9 95027–06025 BOLT, FLANGE...

  • Page 48: Front Master Cylinder

    FIG. 30 FRONT MASTER CYLINDER REF. PART NO. DESCRIPTION 1 1C3–25872–00 HOSE, BRAKE 1 2 90201–10118 WASHER, PLATE 3 90401–10172 BOLT, UNION 4 5XE–W2587–00 MASTER CYLINDER SUB ASSY 5 5NY–W0041–00 .CYLINDER KIT, MASTER 6 5NY–25868–00 .BOOT, MASTER CYLINDER 7 5XE–25854–00 .DIAPHRAGM, RESERVOIR 8 5MV–25852–01 .CAP, RESERVOIR...

  • Page 49: Stand & Footrest

    FIG. 31 STAND & FOOTREST REF. PART NO. DESCRIPTION 1 1C3–27200–00 PEDAL, BRAKE 2 1C3–27217–00 BOLT 3 93210–11073 O-RING 4 91401–20012 PIN, COTTER 5 90506–16500 SPRING, TENSION 6 90240–08120 PIN, CLEVIS 7 90201–08089 WASHER, PLATE 8 90468–16099 CLIP 9 5XE–27411–01 FOOTREST 1 10 5XE–27421–01 FOOTREST 2...

  • Page 50: Rear Master Cylinder

    FIG. 32 REAR MASTER CYLINDER REF. PART NO. DESCRIPTION 1 1C3–2583V–00 RR. MASTER CYLINDER ASSY. 2 5UN–W0042–50 .CYLINDER KIT, MASTER 3 5UN–27218–00 .NUT 4 5UN–27222–00 .JOINT 5 5UN–25852–50 .CAP, RESERVOIR 6 5UN–2585B–00 .PLATE, DIAPHRAGM 7 5UN–25854–00 .DIAPHRAGM, RESERVOIR 8 5UN–27217–00 .BOLT 9 5CG–25715–00 .SEPARATOR ASSY...

  • Page 51: Generator

    FIG. 33 GENERATOR REF. PART NO. DESCRIPTION 1 1C3–85560–00 BASE ASSY 2 1C3–85550–00 ROTOR ASSY 3 90149–06011 SCREW 4 90179–12248 5 90201–127E1 WASHER, PLATE REMARKS...

  • Page 52: Handle Switch & Lever

    FIG. 34 HANDLE SWITCH & LEVER REF. PART NO. DESCRIPTION 1 1C3–26124–00 PROTECTOR, HANDLEBAR 2 5XE–82911–00 HOLDER, LEVER 1 3 5TG–82913–00 HOLDER, LEVER LOWER 1 4 5MV–83912–00 LEVER 1 5 90109–06034 BOLT 6 5LP–84126–10 NUT, LENS FITTING 7 90101–05033 BOLT 8 5HD–26337–00 BOLT, ADJUSTING 9 5HD–83951–00...

  • Page 53: Electrical 1

    FIG. 35 ELECTRICAL 1 REF. PART NO. DESCRIPTION 1 1C3–85540–00 C.D.I. UNIT ASSY 2 1C3–82320–00 IGNITION COIL ASSY 3 90105–06060 BOLT, FLANGE 4 1C3–8231U–00 CORE, SIDE 5 1C3–85546–00 BAND 6 90465–13275 CLAMP 7 1C3–82509–00 WIRE, SUB LEAD 8 1C3–2139X–00 DAMPER REMARKS...

  • Page 54: Alternate For Chassis

    FIG. 36 ALTERNATE FOR CHASSIS REF. PART NO. DESCRIPTION 1 5UN–22212–00 SPRING (K=42N/MM) 5UN–22212–10 SPRING (K=44N/MM) 5UN–22212–30 SPRING (K=48N/MM) 5UN–22212–40 SPRING (K=50N/MM) 5UN–22212–50 SPRING (K=52N/MM) 5UN–22212–60 SPRING (K=54N/MM) 5UN–22212–70 SPRING (K=56N/MM) 5UN–22212–A0 SPRING (K=APPROX.44N/MM) 5UN–22212–B0 SPRING (K=APPROX.46N/MM) 5UN–22212–C0 SPRING (K=APPROX.48N/MM) 5UN–22212–D0 SPRING (K=APPROX.50N/MM) 5UN–22212–E0...

  • Page 55: Optional Parts 1

    FIG. 37 OPTIONAL PARTS 1 REF. PART NO. DESCRIPTION 1 1C3–11630–00 PISTON ASSY (STD) 2 1C3–11631–00–B0 .PISTON (STD) 3 5NY–11611–00 .RING, PISTON 4 1C3–11633–00 .PIN, PISTON 5 93450–16068 .CIRCLIP 6 1C3–11650–00 CONNECTING ROD ASSY 7 1C3–11651–00 .ROD, CONNECTING 8 3JD–11681–10 .PIN, CRANK 1 9 90209–22326 .WASHER...
  • Page 56 GRID GRID PART NO. PART NO. 1C3–11111–00 B – 1C3–12481–00 B – 4JY–11166–00 B – 1C3–12482–00 B – 1C3–11311–00 B – 1C3–12483–00 B – 1C3–1131D–00 B – 1C3–12484–00 B – 4SS–1131M–01 B – 353–13115–01 B – 13 5HD–1131V–00 B – 1C3–13565–00 B –...
  • Page 57 GRID GRID PART NO. PART NO. 1C3–23141–40 E – 1C3–24183–00 D – 1C3–23141–50 E – 1C3–24184–00 D – 1C3–23141–60 E – 5NY–24186–00 D – 1C3–23141–70 E – 1C3–24240–00 D – 1C3–23141–80 E – 3XJ–24380–00 D – 1C3–23141–L0 D – 3JD–24500–02 D –...
  • Page 58 GRID GRID PART NO. PART NO. 90387–08027 C – 90506–20012 B – 12 90387–08032 B – 90508–16134 B – 90387–085E1 B – 90508–261B7 C – 90387–086N4 C – 90508–26450 B – 15 90387–08785 B – 90508–282B8 D – 15 90387–107T9 B –...
