- Page 1 MODEL NO.s 405-10-BLA 405-10-CHR 405-10-COP 405-10-GRY 405-10-RED 405-10-SSB 405-10-WHI 405-20-SSH 405-20-WHI...
- Page 2 Alpine Industries will not be liable for any damages caused by fail- ure to comply with the installation and operating instructions outlined in this manual or damages caused by improper use.
- Page 3 Specifications (cont.) Weight: 9.5 lbs Product Type: High Speed Sensor Activated Material: 304 Stainless Steel Dry Time: – 8 sec. Decibel Rating: 80dB Blower Rotation Rate: – 25,000rpm Air Speed: *100-200 mph Size: 12-5/16” x 11-13/32” x 6-11/16” Parts List 1 –...
- Page 4 Components List Cover Hex Screws Base Plate Blower Motor Speed Adjuster IR Sensor Knock Out Plate HEPA Filter Cover Tabs Filter Tabs Blower Outlet Mount Holes Slot www.AlpineIndustries.com WILLOW HAND DRYER 3...
- Page 5 BEFORE INSTALLATION Caution: Make sure that no electrical wiring or pipe runs are located in the wall cavity behind where this dryer is to be installed. If installing with the hard-wire option, de-energize all electrical lines before installation begins. Hard-wire installation should only be attempted by a licensed electrician.
-
Page 6: Wiring Diagram
INSTALLATION (cont.) 9. Attach base plate to the wall at the 4 points previously marked using the installation map. 10. Attach cover to the base plate (push bottom in first) and replace screws previously removed from cover using hex wrench. 11. -
Page 7: Back Plate Dimensions
BACK PLATE DIMENSIONS WILLOW HAND DRYER 6 www.AlpineIndustries.com... - Page 8 BACK PLATE DIMENSIONS (cont.) WILLOW HAND DRYER 7 www.AlpineIndustries.com...
- Page 9 Maintaining the Dryer Filter Examining and changing a HEPA filter regularly keeps hand dryers working efficiently. The service life of your HEPA filter depends on the frequency of use and the environment your hand dryer is in. High traffic/high usage/ environments high in dust or debris will need more frequent inspection and replacement of the HEPA filter.
- Page 10 Trouble Shooting The procedures in these instructions are intended for use only by a certified electrician. Lay persons should not attempt to trouble shoot the dryer and should contact their local electric service technician. Dryer does not turn on 1.Check power to the unit and connections. Verify if dryer is receiving the correct voltage at the Terminal Block.
-
Page 11: What Is Not Covered
This limited warranty gives you specific legal rights, and you may have other warranty rights that vary from state-to-state. Any other warranties relating t o your Alpine hand dryer, includ- ing, but not limited to, warranty of merchantability, are limited to the duration of this 5 year warranty.
