Table Of Contents - Husqvarna AY 27 Operator's Manual

Introduction..................................................................... 2
Safety..............................................................................2
Operation........................................................................ 5
Maintenance................................................................... 6
Product description
The product is a concrete vibrator. The product has a
pneumatically operated motor that only contains 2
moving parts. Compressed air is supplied to the product
through the air valve.
An automatic lubricator can be installed on the models
AY 27, AY 37, AY 47, AY 57, AY 67, AY 77, AY 87 as
an optional equipment. The automatic lubricator is
supplied by the manufacturer of the air compressor.
Intended use
The product is for professional operation only. The
product removes air bubbles from wet concrete. Do not
use the product for other tasks.
Product overview
3
2
1
7
8
9
1. End cap
2. Front flange
3. Tube
4. Rotor
5. Lamella
6. Rating plate
Safety definitions
Warnings, cautions and notes are used to point out
specially important parts of the manual.
2
Introduction
4
5
6
10
Contents
Troubleshooting.............................................................. 9
Storage and disposal.................................................... 10
Technical data.............................................................. 11
EC Declaration of Conformity....................................... 13
7. Inner hose
8. Rear connector
9. Rear flange
10. Operator's manual
Rating plate
1
2
1. Product type
2. Serial number
3. Speed, rpm
4. Manufacturer
Product liability
As referred to in the product liability laws, we are not
liable for damages that our product causes if:
• the product is incorrectly repaired.
• the product is repaired with parts that are not from
the manufacturer or not approved by the
manufacturer.
• the product has an accessory that is not from the
manufacturer or not approved by the manufacturer.
• the product is not repaired at an approved service
center or by an approved authority.
Safety
WARNING: Used if there is a risk of injury or
death for the operator or bystanders if the
instructions in the manual are not obeyed.
3
1162 - 001 - 26.03.2020
