Owner's Manual & Safety Instructions
Save This Manual
operating, inspection, maintenance and cleaning procedures. Write the product's serial number in the
back of the manual near the assembly diagram (or month and year of purchase if product has no number).
Keep this manual and the receipt in a safe and dry place for future reference.
Email our technical support at: productsupport@harborfreight.com
When unpacking, make sure that the product is intact
and undamaged. If any parts are missing or broken,
please call 1-888-866-5797 as soon as possible.
©
Copyright
2019 by Harbor Freight Tools
No portion of this manual or any artwork contained herein may be reproduced in
any shape or form without the express written consent of Harbor Freight Tools.
Diagrams within this manual may not be drawn proportionally. Due to continuing
improvements, actual product may differ slightly from the product described herein.
Tools required for assembly and service may not be included.
Keep this manual for the safety warnings and precautions, assembly,
Visit our website at: http://www.harborfreight.com
®
. All rights reserved.
Read this material before using this product.
Failure to do so can result in serious injury.
SAVE THIS MANUAL.
20a
Advertisement
Table of Contents
Related Manuals for Harbor Freight Tools 56814
Summary of Contents for Harbor Freight Tools 56814
- Page 1 No portion of this manual or any artwork contained herein may be reproduced in Failure to do so can result in serious injury. any shape or form without the express written consent of Harbor Freight Tools. Diagrams within this manual may not be drawn proportionally. Due to continuing SAVE THIS MANUAL.
-
Page 2: Important Safety Information
Contains Lithium-Polymer battery. If unreadable or missing, contact Battery must be recycled or disposed Harbor Freight Tools for a replacement. of properly. Do not open, crush, heat above 140° F or incinerate. Page 2 For technical questions, please call 1-888-866-5797. -
Page 3: Personal Safety
Do not wear loose clothing or jewelry. Keep hair and clothing away from moving parts. Loose clothes, jewelry, or long hair can be caught in moving parts. Item 56814 For technical questions, please call 1-888-866-5797. Page 3... -
Page 4: Specifications
Drone FCC ID: 2AKPPHELICUTE Remote Control FCC ID: 2AKPPHLTH816 The responsible party in the United States for compliance of the equipment is: Harbor Freight Tools, 26541 Agoura Road, Calabasas, CA 91302 1-888-866-5797 • http://www.harborfreight.com Page 4 For technical questions, please call 1-888-866-5797. -
Page 5: Charging Battery
Cable into the USB port of a computer or any other USB power source. When charging is complete, disconnect Charging Cable from Drone and power source. Charge Charge Plug Plug Charging Cable Plug Item 56814 For technical questions, please call 1-888-866-5797. Page 5... -
Page 6: Remote Control
AAA batteries (sold separately) alkaline, carbon-zinc or rechargeable in the indicated polarity. batteries together. Position batteries in proper polarity. Do not use swollen or leaking batteries. Battery Cover Battery Compartment Page 6 For technical questions, please call 1-888-866-5797. Item 56814... - Page 7 Directional Joystick Down HEADLESS MODE Headless Mode Button TURN LEFT Throttle Joystick Left ONE KEY RETURN One Key Return Button TURN RIGHT Throttle Joystick Right TRIM ADJUSTMENT Refer to page 10 Item 56814 For technical questions, please call 1-888-866-5797. Page 7...
-
Page 8: Speed Control
Throttle Joystick down again — t he Remote will beep three times indicating speed is set. To return to slow speed press the Throttle Joystick once — t he Remote will beep once indicating speed is reset to slow. Page 8 For technical questions, please call 1-888-866-5797. Item 56814... -
Page 9: Basic Operation
Turn Left To move the Drone left or right from side to side, push the Directional Joystick to the left or right. Left Side Right Side Item 56814 For technical questions, please call 1-888-866-5797. Page 9... - Page 10 Trim Backward FORWARD TRIM Forward Trim LEFT SIDE TRIM Left Side Trim RIGHT SIDE TRIM Right Side Trim LEFT TURN TRIM Left Turn Trim RIGHT TURN TRIM Right Turn Trim Page 10 For technical questions, please call 1-888-866-5797. Item 56814...
- Page 11 Left/Right: Practice moving to the left and right in the following 4 positions: a. Tail facing you. b. Left side facing you. c. Nose facing you. d. Right side facing you. Item 56814 For technical questions, please call 1-888-866-5797. Page 11...
-
Page 12: 360 Degree Flips
For a right flip, push the Directional Joystick to the right. For a forward flip, push the Directional Joystick up. For a backward flip, pull the Directional Joystick down. Page 12 For technical questions, please call 1-888-866-5797. Item 56814... -
Page 13: Headless Mode
Find the helicute FPV WIFI network and connect. Enter setting menu on your mobile device and turn on WIFI. Open the helicute FPV software and click on the play icon. HELICUTE FPV Item 56814 For technical questions, please call 1-888-866-5797. Page 13... -
Page 14: Inspection And Maintenance
Lift Rotor and screw off Shaft. Place new Rotor and screw on Shaft and tighten screw securely. CAUTION! Guards near rotors must Rotor Positions stay in place and be undamaged. Page 14 For technical questions, please call 1-888-866-5797. Item 56814... -
Page 15: Parts List
Note: If product has no serial number, record month and year of purchase instead. Note: Some parts are listed and shown for illustration purposes only, and are not available individually as replacement parts. Item 56814 For technical questions, please call 1-888-866-5797. Page 15... - Page 16 Limited 90 Day Warranty Harbor Freight Tools Co. makes every effort to assure that its products meet high quality and durability standards, and warrants to the original purchaser that this product is free from defects in materials and workmanship for the period of 90 days from the date of purchase.
