- Page 1 ART2004 User’s Manual Beijing ART Technology Development Co., Ltd.
-
Page 2: Table Of Contents
Beijing ART Technology Development Co., Ltd. V6.12 Contents Contents ....................................2 Chapter 1 Overview ................................3 Chapter 2 Components Layout Diagram and a Brief Description ..................4 2.1 The Main Component Layout Diagram ........................4 2.2 The Function Description for the Main Component ....................4 2.2.1 Signal Input and Output Connectors ......................4... -
Page 3: Chapter 1 Overview
Beijing ART Technology Development Co., Ltd. V6.12 Chapter 1 Overview ART2004 is a card based on PC104+ bus, can be connected to the computer's PC104 interface to constitute the laboratory, product quality inspection center and other areas of data acquisition, waveform analysis and processing system. -
Page 4: Chapter 2 Components Layout Diagram And A Brief Description
Beijing ART Technology Development Co., Ltd. V6.12 Chapter 2 Components Layout Diagram and a Brief Description 2.1 The Main Component Layout Diagram The following is the ART2004 component location diagram, the switch and jumper settings are the factory standard settings. Set as follows: board base address = 280H, the analog output range is ±5V. -
Page 5: Board Base Address Selection
Beijing ART Technology Development Co., Ltd. V6.12 RP4: DA3 analog output voltage gain adjustment RP5: DA0, DA1, DA2, DA3 analog output zero-point adjustment RP6: DA4 analog output voltage gain adjustment RP7: DA5 analog output voltage gain adjustment RP8: DA6 analog output voltage gain adjustment... - Page 6 Beijing ART Technology Development Co., Ltd. V6.12 2A0H 2B0H 2C0H 2D0H 2E0H 2F0H 300H 310H 320H 330H 340H 350H 360H 370H 380H 390H 3A0H 3B0H 3C0H 3D0H 3E0H 3F0H BUY ONLINE at art-control.com/englishs or CALL+86-10-62991792-609(CN)
-
Page 7: Jumper
Beijing ART Technology Development Co., Ltd. V6.12 2.2.4 Jumper XF1~XF12: analog output range selection XF1-XF12 can be selected by the jumper. The black box represents the 1-pin, the middle black dot represents 2-pin, the rest is the 3-pin. BUY ONLINE at art-control.com/englishs or CALL+86-10-62991792-609(CN) -
Page 8: Chapter 3 Address Assignment
Beijing ART Technology Development Co., Ltd. V6.12 Chapter 3 Address Assignment 3.1 Address Assignment Table of the Board Address Assignment Table (both read and write are eight bus operation) Address Write 读 Base Address+0 DA channel Start 0-ch, 1-ch, 2-ch and 3-ch DA to convert... -
Page 9: Chapter4 Notes, Calibration And Warranty Policy
Beijing ART Technology Development Co., Ltd. V6.12 Chapter4 Notes, Calibration and Warranty Policy 4.1 The Connection of the Output Signal When output voltage, one side of the load connects with the voltage output port (VOUTx), the other side connects with the analog ground (AGND), the max current that provided to the load is10mA, the voltage output does not require an external power supply. -
Page 10: Note
Can not hot-plug the card 4.4 Warranty Policy Thank you for choosing ART. To understand your rights and enjoy all the after-sales services we offer, please read the following carefully. 1. Before using ART’s products please read the user manual and follow the instructions exactly. When sending in damaged products for repair, please attach an RMA application form which can be downloaded from: www.art-control.com. -
Page 11: Products Rapid Installation And Self-Check
At this moment, there should be installation information of the installed device in the Device Manager (when the device does not work, you can check this item.). Open "Start -> Programs -> ART Demonstration Monitoring and Control System -> Corresponding Board -> Advanced Testing Presentation System", the program is a standard testing procedure.
