INSTALLATION &
OPERATION MANUAL
Power
Alert
!
JAUTPS/JAUTP
JACUZZI
POOL ONLY & POOL/
SPA COMBINATION
AUTOMATION SYSTEM
WARNING
FOR YOUR SAFETY - This product must be installed and serviced by a contractor who is licensed and qualified in pool
equipment by the jurisdiction in which the product will be installed where such state or local requirements exist. The main-
tainer must be a professional with sufficient experience in pool equipment installation and maintenance so that all of the
instructions in this manual can be followed exactly. Before installing this product, read and follow all warning notices and
instructions that accompany this product. Failure to follow warning notices and instructions may result in property damage,
personal injury, or death. Improper installation and/or operation will void the warranty.
Improper installation and/or operation can create unwanted electrical hazard which can cause serious injury, property
damage, or death.
ATTENTION INSTALLER - This manual contains important information about the installation, operation and safe use of this
product. This information should be given to the owner/operator of this equipment.
Advertisement
Table of Contents
Summary of Contents for Jacuzzi JAUTPS
- Page 1 INSTALLATION & OPERATION MANUAL Power Alert JAUTPS/JAUTP JACUZZI POOL ONLY & POOL/ SPA COMBINATION AUTOMATION SYSTEM WARNING FOR YOUR SAFETY - This product must be installed and serviced by a contractor who is licensed and qualified in pool equipment by the jurisdiction in which the product will be installed where such state or local requirements exist. The main- tainer must be a professional with sufficient experience in pool equipment installation and maintenance so that all of the instructions in this manual can be followed exactly.
-
Page 2: Table Of Contents
Programming and Testing ....11 Basic Navigation ..............11 Set the Clock ............... 12 Schedules ..... 12 Define Equipment ON/OFF Test the JAUTPS/JAUTP ............ 13 Section 7. Install Settings ........14 Freeze Protect ..............14 Units ..................15 Languages................15 Clear Memory .............. -
Page 3: Important Safety Instructions
INSTALLATION MANUAL SECTION 1. IMPORTANT SAFETY INSTRUCTIONS READ AND FOLLOW ALL INSTRUCTIONS All electrical work must be performed by a licensed electrician and conform to all national, state, and local codes. When installing and using this electrical equipment, basic safety precautions should always be followed, including the following: DANGER To reduce the risk of severe injury or death, do not remove the suction fittings of your spa or hot tub. - Page 4 JAUTP / JAUTPS CONTROLLER WARNING To avoid injury ensure that you use this control system to control only packaged pool/spa heaters which have built-in operating and high limit controls to limit water temperature for pool/spa applications. This device should not be relied upon as a safety limit control.
-
Page 5: System Overview
Water Temperature Sensor Kit • Mounting Hardware • Mounting bracket • Mounting Bracket for remotely installing UI • Installation Manual/ Owner’s Manual JAUTPS • Four Function Controller with removeable User Interface (UI) • Jandy Valve Actuators (2) ® • Water Temperature Sensor Kit •... -
Page 6: Materials And Tools
JAUTP / JAUTPS CONTROLLER MATERIALS AND TOOLS Installation Materials Furnished • Screw Set (includes Plastic Anchors) • Metal Mounting Bracket Tools Needed for Installation • Power Drill • 3/16” Drill Bit - Hammer Drill Bit (only necessary to drill into brick or concrete) •... -
Page 7: High Voltage Wiring
Turn off power fastening hole under the ground bar. Drill a 3/16" hole at the main circuit feeding the JAUTPS / JAUTP controller through the plastic enclosure. to disconnect the power center from the system. - Page 8 JAUTP / JAUTPS CONTROLLER Power Controller Board Relay Sockets Green Terminal Bar JVA Sockets (24 VDC output) RS485 Network (24 VAC output) (Red Terminal Bar) 24 VAC power plug from transformer connects into a User Interface Connector 3-pin terminal on the back of the...
-
Page 9: Ground Fault Circuit Interrupter
INSTALLATION MANUAL GROUND FAULT CIRCUIT times. The conductive surface shall be located where it is not exposed to physical damage or dislodgement INTERRUPTER during usual pool activities, and it shall be bonded in accordance with the bonding requirements of NEC WARNING Article 680. -
Page 10: Low Voltage Wiring
(pins 7,8). The water temperature JAUTPS/JAUTP DEVICE sensor and necessary installation hardware is included. Mount the iAquaLink JAUTPS/JAUTP at least 6 feet off 5.1.1 INSTALL THE WATER the ground and at least 8 feet from motors, such as a TEMPERATURE SENSOR blower. -
Page 11: Install Jandy Valve ® Actuators (Jvas) (If Applicable)
Arrows Back Select (IF APPLICABLE) Back Button Select Button You may wire up to three JVAs on the JAUTPS/JAUTP. Power Alert Two (2) JVAs are included in JAUTPS (Pool/Spa combo). Alert Light Power Light An additional JVA may be required on a pool/spa... -
Page 12: Basic Navigation
More JAUTP / JAUTPS CONTROLLER BASIC NAVIGATION DEFINE EQUIPMENT ON/OFF SCHEDULES Use the following buttons on the user interface to More access and select all menus and commands: MAiN > SeTTiNgS > SCHeDuLeS Define automatic ON and OFF times for equipment. -
Page 13: Test The Jautps/Jautp
Scroll down to SAVE. Press Select. • Highlight SPA PUMP and press Select to turn the spa pump ON. TEST THE JAUTPS/JAUTP After a couple of minutes, you should hear the spa pump go Perform a basic installation test to make sure the 6.4.3... -
Page 14: Install Settings
JAUTP / JAUTPS CONTROLLER SECTION 7. To access the Install Settings Menu: INSTALL SETTINGS • Press and hold Up/Down arrow keys at the same time for about 5 seconds. Install Settings is a hidden menu, mostly used for setup and reference purposes. -
Page 15: Units
INSTALLATION MANUAL Set Temperature: UNITS iNSTALL SeTTiNgS > FreeZe PrOTeCT > iNSTALL SeTTiNgS>uNiTS SeT TeMP Change the temperature units (Fahrenheit - Celcius) Set outside temperature at which freeze protect and time format (12-hour AM/PM to 24-hour clock). function is activated. Activation temperature can be adjusted between 34°F and 42°F. -
Page 16: Clear Memory
SeTTiNgS>CLeAr MeMOrY either one or two-speed, or variable speed. Clear all stored values (e.g., auxiliary labels, programs, remote settings, and thermostat settings) from the JAUTPS/JAUTP memory. All settings will be reset to CLEAR MEMORY TTINGS Select 1-Speed or 2-Speed Pump: default factory settings. -
Page 17: Color Lights
JC is displayed next to AUX if a JandyColors light iNSTALL SeTTiNgS>TeMP CALiBrATe has been assigned. Adjust temperature displayed on the JAUTPS/JAUTP up • JL is displayed next to AUX if a Jandy LED Light has or down by 4 degrees. -
Page 18: Solar Priority (If Applicable)
Allow Jandy Valve Actuators (JVAs) to be assigned to ® Hotkey 1 Hotkey 1 Hotkey 1 any auxiliary on the JAUTPS/JAUTP controller, so that Aux1 Aux1 Aux1 when you select this auxiliary, the valve turns. Assigning... -
Page 19: Ext. Swc Power
SeTTiNgS>DiAgNOSTiCS>reViSiONS equipment may be displayed: View your system firmware revision number for • AQP - AquaPure troubleshooting. • FFC - JAUTPS/JAUTP Controller • iAL - iAquaLink JAUTPS/JAUTP ® INSTALL SETTINGS DIAGNOSTICS INSTALL SETTINGS DIAGNOSTICS •... -
Page 20: Service Mode
JAUTP / JAUTPS CONTROLLER SECTION 8. SERVICE MODE MAiN>SerViCe MODe Service Mode is used for safety purposes to shut off power to all equipment during service or troubleshooting. Settings available through this menu: • Auto Indicates that equipment is turned on and running according to system programming. -
Page 21: Pool/Spa System Menu Flow Diagrams
INSTALLATION MANUAL SECTION 9. POOL/SPA SYSTEM MENU FLOW DIAGRAMS MAIN MENU MAIN MENU/STATUS Pool Mode OFF/ON Pool Heat Enabled Pool Heater OFF/ON Set to: 80°F Spa Mode OFF/ON Spa Heat Enabled Spa Heater OFF/ON Set to: 102°F AUX 1 OFF/ON AUX 2 OFF/ON Settings... -
Page 22: Install Settings Menu
JAUTP / JAUTPS CONTROLLER INSTALL SETTINGS MENU MAIN MENU/STATUS INSTALL SETTINGS VSP Model From Settings, press Temp: °F Jandy/Zodiac both Up/Down Arrow Set Temp Intelliflo VS buttons for 5 seconds Freeze Protect Pool Mode OFF/ON Filter Pump to display Install Settings Equipment Speeds <RPM>... -
Page 23: Section 10. Pool Only System Menu Flow Diagrams
INSTALLATION MANUAL SECTION 10. POOL ONLY SYSTEM MENU FLOW DIAGRAMS 10.1 MAIN MENU MAIN MENU/STATUS Pool Mode OFF/ON Pool Heat Enabled Temp 1 OFF/ON Set to: 80°F Pool Heat Enabled Temp 2 OFF/ON Set to: 85°F AUX 1 OFF/ON AUX 2 OFF/ON Settings Boost OFF/ON *... -
Page 24: Install Settings Menu
JAUTP / JAUTPS CONTROLLER 10.2 INSTALL SETTINGS MENU MAIN MENU/STATUS INSTALL SETTINGS VSP Model From Settings, press Temp: °F Jandy/Zodiac both Up/Down Arrow Set Temp Intelliflo VS buttons for 5 seconds Freeze Protect Pool Mode OFF/ON Filter Pump to display Install Settings Equipment Speeds <RPM>... -
Page 25: Section 11. Glossaries
INSTALLATION MANUAL SECTION 11. GLOSSARIES Heater “Short Cycling” Prevention When the heater is activated and the desired 11.1 GLOSSARY OF SAFETY DELAYS temperature is reached, heater will turn off and remain off for three (3) minutes, even if the temperature falls AND LOCKOUTS below the desired temperature. -
Page 26: Glossary Of Alert Messages
This message is displayed during pool/spa switching. equipment assigned to freeze protection are active (for The JAUTPS/JAUTP waits 35 seconds while the valves example, the filter pump). See Freeze Protection Menu for turn from pool position to spa position (or vice-versa) more information. - Page 27 TIMEOUT MODE TIME OUT mode is used by the pool service person to aid them in servicing the pool. The JAUTPS/JAUTP user interface will not be functional for three (3) hours, or until the switch at the Controller is turned back to AUTO mode.
- Page 28 All other brands, product names, company names, trade names and trademarks used are the property of their respective owners. Jacuzzi may add to change or remove any part of these materials at any time, without notice. Reproduction in whole or inpart without written permission is prohibited. International products may be configured differently to meet local electrical...
