NAPCO Networx ArchiTech User Manual

NAPCO Networx ArchiTech User Manual

Wireless network access control system with proximity access with keypad / proxreader
Hide thumbs Also See for Networx ArchiTech:
Table of Contents

Advertisement

Quick Links

Download this manual
ArchiTech
by Networx
™
™
with Keypad / ProxReader
USER'S GUIDE
© NAPCO Security Technologies, Inc. 2018
OI410LF 8/18
RR-4BKEYFOB
WIRELESS REMOTE
RELEASE
PROXIMITY
CARD
iLock
™
SMARTPHONE
APP
K
/P
R
EYPAD
ROX
EADER
RR-1BUTTON
WIRELESS REMOTE
RELEASE
™
DL-WINDOWS
PROGRAMMING SOFTWARE
AL-PRE PROXIMITY CREDENTIAL
READER / ENROLLER
™
™
ArchiTech
by Networx
Wireless Network Access
Control System with Proximity Access
1

Advertisement

Table of Contents
loading

Related Manuals for NAPCO Networx ArchiTech

Summary of Contents for NAPCO Networx ArchiTech

  • Page 1 ArchiTech by Networx ™ ™ with Keypad / ProxReader USER'S GUIDE © NAPCO Security Technologies, Inc. 2018 OI410LF 8/18 RR-4BKEYFOB WIRELESS REMOTE RELEASE PROXIMITY CARD iLock ™ SMARTPHONE EYPAD EADER RR-1BUTTON WIRELESS REMOTE RELEASE ™ DL-WINDOWS PROGRAMMING SOFTWARE AL-PRE PROXIMITY CREDENTIAL READER / ENROLLER ™...

  • Page 2: Table Of Contents

    ArchiTech by Networx Wireless Locks ™ ™ RCHI ECH BY ETWORX IRELESS CCESS ONTROL YSTEM IS A TATE ICROPROCESSOR ASED OMPUTER ETWORK ROGRAMMABLE ROXIMITY ECURITY Ideal for small businesses with multiple users and multiple credential types (PIN, Prox, Bluetooth app)! ™...

  • Page 3: Architech Features

    ™ ArchiTech Features Three Ways to Program Adding keypad buttons to the proximity reader allows for additional programming options:  "Program Card Programming": For " stand-alone" operation, without enrollment into a Networx (DL-Windows) sys- tem. Create special proximity "Program Cards" at the lock's Proximity Reader, then use these "Program Cards" to create new proximity credentials for distribution.

  • Page 4: Supported Products And Applications

    Supported Products & Applications AL-IM2 SERIES Gateway Modules The ArchiTech series door lock contains a radio that transmits and receives data (via a private wireless signal) to an intermediate device called a "Gateway" interface module. In turn, this module is connected (either wirelessly or wired) to a computer network such as a LAN or corporate Intranet.

  • Page 5: Terminology Used In This Manual

    Terminology Used in this Manual Before reading this section, you may wish to first read the day). See next page for the definition of "Group". "ArchiTech Series Design Overview" on page 8 to deter- In DL-Windows, use the "Schedule - TimeZone" screen to mine the manner in which you will be using your ArchiTech first create an individual block of time called a "TimeZone"...
  • Page 6 Terminology Used in this Manual (cont'd) Remote releases, activating "DL-Windows Mode" ("Networx User 297: Quick Enable User 300 Mode"), and they also allow access (they can unlock the lock, The credential assigned to User Number 297 possesses the but we do not recommend they be used as "everyday" access unique ability to enable the credential assigned to User cards).

  • Page 7: Architech User Number Definitions

    ArchiTech User Number Definitions Adding Extra "Admin" Credentials Some of the terminology in this table was originally defined in the DL-Windows User Guide OI382. Please refer to this manual for specific definitions. For more information, see Terminology on page 5 and page 6, and also see OI383.

  • Page 8: Architech Series Design Overview

    ArchiTech Series Design Overview Parts Overview (not to scale) MORTISED SURFACE-MOUNTED DOOR KEYPAD / PROXREADER DOOR CONTACT NETWORX CONTROL NETWORX MAGNET CONTACT UNIT CONTROL UNIT (TWO TYPES) SENSOR Why Use Proximity Credentials? of the door (open or closed). The Door Contact Sensor is shown above at right;...

  • Page 9: Overview: Three Ways To Program

    Overview: Three Ways to Program To maintain maximum flexibility, your ArchiTech series lock can be programmed in three ways, each can be thought of as a separate programming "environment". Each are available to suit your installation requirements: "Program Card Programming" Also known as "Stand-Alone Mode"...

  • Page 10: Power Up And Secure The Door

    Power Up and Secure the Door Remember: The default state before and after power up is in passage (" unlocked" ). If you need to secure the door ("lock the lock"), perform the "POWER UP" and the "SECURING THE DOOR" procedures, below. POWER UP After physically installing your lock, you must perform the following "POWER UP"...

  • Page 11: Select "Program Card Programming" Operation

    Select "Program Card Programming" Operation Also known as "Stand-Alone Mode" when used with other ArchiTech lock models without a keypad, "Program Card Pro- gramming" permits all programming (for example adding or deleting proximity cards) to be performed using special prox- imity "Program Cards"...
  • Page 12 Select "Program Card Programming" Operation (cont'd) ADD A CREDENTIAL To manually add additional proximity credentials, you MUST first create / enroll two "Program LOCATION OF THE "PROGRAM / PASSAGE" BUTTON Cards"; if you have not done so, stop here and perform the PROGRAM CARD CREATION / EN- ROLLMENT detailed above.

  • Page 13: Keypad Programming": Overview Of Functions

    "Keypad Programming": Overview of Functions Function 1 Change Master Code See page 14 Function 48 Enable Passage Mode See page 20 Function 49 Disable Passage Mode See page 20 Function 2 Add/Delete/Change User Codes See page 14 Return Lock to Normal Passage Function 50 See page 20 Function 3...

  • Page 14: Keypad Programming" Conventions

    "Keypad Programming" Conventions Enabling/Disabling Users (By User Number) Minimum Required Program Level User Number must be between 2 and 5000. Program Levels are abbreviated as follows: NOTE: Will Enable/Disable users even if the user is associated with an enabled group. Function M = Master Description...
  • Page 15 "Keypad Programming" Functions (cont'd) USERS (Continued) User Enable/Disable (By User Number)  User Number must be between 2 and 5000. NOTE: Will Enable/Disable Users even if the User is associated with an enabled Group. Use Function 3 to disable a specific User Number and their associated User Code.
  • Page 16 "Keypad Programming" Functions (cont'd) CLEAR FUNCTIONS 12. Clear All Schedules and Timeout Functions ; 1 2 ; 0 0 0 : Function 12 clears all programmed Schedules and all Timeout Functions. (To clear All Timeout Functions only, see Function 13 below). Function 12 will clear all of the following: All Schedule Functions 72 through 93, Timeout Functions 5, 25 through 34 and Function 47.
  • Page 17 "Keypad Programming" Functions (cont'd) 25 - 34. Reserved GROUPS NOTE: Clear All Timeout Functions by entering Function 13. ; 3 5 [ _ _ _ ] [ _ _ _ _ ] 35. Group Add/Delete Association (User Number) (Groups) As per the chart on page 7, the lock's default programming from the factory associates certain User Numbers with certain Groups.
  • Page 18 "Keypad Programming" Functions (cont'd) CLOCK SETTINGS ; 3 8 38. Set Date [ _ _ _ _ _ _ ] (Date)  Use Month Day Year format - MMDDYY - Single digit months and days are entered with a preceding zero. ...
  • Page 19 "Keypad Programming" Functions (cont'd) CLOCK ADJUST Clock Adjust Number of seconds to adjust (speed up/slow down) the clock each day must be be- tween 0-55 seconds. Note: Repeated use of these Functions are not "cumulative" (this means, for exam- ple, if the clock has already been set to speed up 10 seconds per day, and then is found to need an additional 10 seconds, then program 20 seconds using Function 43).
  • Page 20 "Keypad Programming" Functions (cont'd) PERMANENT PASSAGE MODE Passage Mode Enable/Disable - Schedule will not Override  Function 48 allows passage through the door without the need for a credential. Re-Lock using Function 49.  Programmed Schedules will not override the state of the lock using functions 48 and 49. If it is required that programmed schedules override Passage Mode, Enable/Disable Passage Mode using Functions 45/46.
  • Page 21 "Keypad Programming" Functions (cont'd) SMART PASS ; 5 5 : 55. Enable 30 Second Smart Pass Smart Pass Enabling this feature overrides the existing Pass Time and sets the duration to 30 sec- onds. Therefore, after a valid credential has been presented, the ArchiTech series lock will remain unlocked for 30 seconds OR until the door opens or closes.
  • Page 22 "Keypad Programming" Function 67 ; 6 7 [ _ _ ] 67. Program System Features (Feature Number)  Use Function 67 to program one or more system features. For example, program ; 6 7 ; 2 5 : to disable the sounder. ...
  • Page 23 "Keypad Programming" Function 67 (cont'd) ; 6 7 [ _ _ ] 67. Program System Features (cont'd) (Feature Number) 38. Lock Responds to "Global" Emergency Commands. (Default = OFF, thus default = Lock responds to " Local" Emergency Commands only). Allows lock to respond to lock down requests initiated by Networx server running DL- Windows or another lock (as opposed to directly from a Wireless Remote Release).
  • Page 24 "Keypad Programming" Function 67-68 (cont'd) ; 6 7 [ _ _ ] 67. Program System Features (cont'd) (Feature Number) above, when feature 56 is enabled, and whenever the deadbolt extends, the ArchiTech lock will always change to a "locked" state. Enabling feature 57 allows the user to press the "Program / Passage" button before exiting to allow the ArchiTech lock to remain in an "unlocked"...
  • Page 25 "Keypad Programming" Functions (cont'd) Enter Key  When this Function is enabled, the User must press after any valid User Code entry. Therefore, this Function allows User Codes to be subsets of other User Codes. Examples: 1 2 3 : can be a valid user code; 1 2 3 4 : can be a valid user code within the same lock.

  • Page 26: Keypad Programming" Record Sheet

    "Keypad Programming" Record Sheet Default Values are shown in parentheses. Function Function Name Programming Number(s) 0-55 Clock Adjust 43/44 Seconds    Pass Time 52/53/54 (3 sec) 10 sec 15 sec 1-9 Attempts Set Lockout Attempts 1-60 seconds Set Lockout Time ...

  • Page 27: Keypad Programming" Schedule Record Sheet

    "Keypad Programming" Schedule Record Sheet Day(s) Up to 500 scheduled functions can be programmed. Function Number Time Function Name For the Day, enter : 1 = Sunday, 2 = Monday, 3 = Tuesday, 4 = Wednesday 5 = Thursday, 6 = Friday, 7 = Saturday, 8 = Monday through Friday, 9 = Saturday and Sunday, 0 = All days of the week Enter time of day in 24-hour format (00:00- 23:59)

  • Page 28: Dl-Windows Mode" Operation / Features

    "DL-Windows Mode" Operation / Features This section highlights the considerations when using the ArchiTech series lock in a mode integrated with the DL- Windows software (version 5.2 and up). When using the lock in "DL-Windows Mode" (also called "Networx Mode"), credentials and lock features can be sent to the lock wirelessly using a Networx Gateway.
  • Page 29 "DL-Windows Mode" Operation / Features (cont'd) ArchiTech Series Features ArchiTech series locks support most standard Networx features (e.g. Entry Delay, GP2 Toggles Passage Mode, etc.) that are available in DL-Windows. For more information regarding all of the features available with your ArchiTech series lock, see OI382 and OI383.
  • Page 30 "DL-Windows Mode" Operation / Features (cont'd) Remote Tab The ArchiTech series locks allow for two programmable remote functions: Remote Release (Momentary) and Re- mote Toggles Passage Mode. For complete information about these DL-Windows features, see OI382 and its pages detailing the Features screen. These remote release features can only be triggered by use of the RR- 1BUTTON Wireless Remote Release Button (see WI1999) and/or the RR-4BKEYFOB Wireless Remote Release Keyfob (see WI2004).

  • Page 31: Emergency Commands

    Emergency Commands Overview The ArchiTech series locks can be programmed to send and/or respond to Emergency Commands ("Emergency Lock Down", "Emergency Passage" and " Return to Normal" ). Emergency Commands can be initiated an RR- 4BKEYFOB Wireless Remote Release or initiated from the Networx server running DL-Windows. (Note: "Emergency Passage"...
  • Page 32 Emergency Commands (cont'd) ingly. The Emergency Command will NOT be sent to the Gateway and therefore will NOT be sent to other locks in the system. TIP: Combining Global and Local Features: You can combine the various Global and Local Emergen- cy features to customize your system.

  • Page 33: Bluetooth Support

    Bluetooth Support Overview The J and T "style" ArchiTech series locks contain Bluetooth LE technology that allows for entry via a smartphone application ("app"). The iLock smartphone app works essentially as any other type of proximity credential; simply launch the iLock app and tap the Unlock button to allow entry. For added security, an optional password can be set in the iLock app that would then be required for every unlock request.

  • Page 34: Using The Ilock App

    Using the iLock App iLock App: "Settings" screen iLock App: "Lock Settings" screen (see below) Lock Settings Change Lock Name Lock ID Displays existing Lock Name created in step 5 in (Lock Serial Number): Displays the physical lock's "Enrolling Bluetooth Credentials" above. Upon selection, unique serial number assigned and programmed into the smartphone keyboard will appear allowing changes.
  • Page 35 Using the iLock App (cont'd) Press Unlock to send an unlock request to Red padlock turns green upon unlock (and the selected ArchiTech series lock. The lock remains green / unlocked for the duration of will unlock within a few seconds (this time the programmed Pass Time).

  • Page 36: Wireless Remote Releases

    Wireless Remote Releases Two types of "Wireless Remote Release" devices are compatible with the ArchiTech series door locks: The RR- 1BUTTON Wireless Remote Release Button (see WI1999) and RR-4BKEYFOB Wireless Remote Release Keyfob (see WI2004). Whether the Wireless Remote Release contains a single button (RR-1BUTTON) or four buttons (RR- 4BKEYFOB), each button can be "paired"...

  • Page 37: Low Battery And Battery Replacement

    Low Battery and Battery Replacement Low Battery Warning When a valid proximity credential is presented to the lock and the batteries are weak, a steady tone will sound for the duration of the Pass Time ("Pass Time" is the duration the lock remains unlocked after access is granted). Discard the weak batteries and replace with four (4) AA-size 1.5 volt alkaline batteries.

  • Page 38: Erase All Programming

    Erase All Programming Erase All Programming (Restore the "out of box" factory condition) To return the ArchiTech series lock to its original condition, when the lock and all components were first removed from their factory packaging, proceed as follows for the specific model type in your installation: To erase all programming in the Mortised Networx Control Unit: 1.

  • Page 39: Power Down -- Retain Existing Programming

    Power Down -- Retain Existing Programming Power Down--Retain Existing Programming Use when re-applying power to a lock already in use (you wish to retain the Lock Program), such as when moving an existing lock to a new door or changing the batteries. In this case, the lock is to be dismantled and powered down for an extended period.

  • Page 40: Led And Sounder Indications

    LED and Sounder Indications With a fully charged battery, the LED and sounder provide visual and audible feedback. The LED on the Surface- Mounted Networx Control Unit mimics the LED located on the Proximity Reader. SOUNDER ACTIVITY COMMENTS FLASHES BEEP(S) Lock unlocks for duration of Pass Time ("Pass Access Granted / Wireless Remote 2 Green...

  • Page 41: User Card Record Sheet

    User Card Record Sheet Page # ______ NAME OF DOOR: DEPARTMENT: EMBOSSED NUMBER ON CARD USER NAME (LAST, FIRST) DATE ACTIVATED COMMENTS...

  • Page 42: Glossary

    Glossary an ArchiTech lock, its default settings are per- ACCESS = Entry into a restricted area. manently encoded within the lock's fixed ADMINISTRATIVE USERS = Credential data memory, and when the lock is first started, or added to any of the slots ("User Numbers") when power is removed and re-applied (see numbered 2 through 11).
  • Page 43 Glossary (cont'd) ing, see the "ArchiTech User Number Defini- User 299. A Guard Tour proximity credential is used to log the movement of a security guard tions" table on page 7 and 'Select "Program as he or she makes rounds from one assigned Card Programming"...

  • Page 44: Architech Networx Limited Warranty
