- Page 1 AIR CONDITIONER Wall mounted type DESIGN & TECHNICAL MANUAL INDOOR ASYG09KMCB ASYG12KMCB ASYG14KMCB OUTDOOR AOYG09KMCBN AOYG12KMCBN AOYG14KMCBN DR_AS081EF_01 2018.09.13...
- Page 2 • Product specifications and design are subject to change without notice for future improvement. • For further details, please check with our authorized dealer. Trademarks ™ FGLair is trademark of Fujitsu General Limited in the United States, other countries or both. ™ Google Play is trademark of Google Inc. ®...
-
Page 3: Table Of Contents
CONTENTS Part 1. INDOOR UNIT................1 1. Specifications....................2 2. Dimensions....................3 2-1. Models: ASYG09KMCB, ASYG12KMCB, and ASYG14KMCB........3 3. Wiring diagrams ....................5 3-1. Models: ASYG09KMCB, ASYG12KMCB, and ASYG14KMCB........5 4. Capacity table....................6 4-1. Cooling capacity.......................6 4-2. Heating capacity ......................7 5. Fan performance ...................8 5-1. Air velocity distributions....................8 5-2. - Page 4 CONTENTS (continued) Part 2. OUTDOOR UNIT..............33 1. Specifications....................34 2. Dimensions....................35 2-1. Models: AOYG09KMCBN, AOYG12KMCBN, and AOYG14KMCBN......35 3. Installation space ..................36 3-1. Models: AOYG09KMCBN, AOYG12KMCBN, and AOYG14KMCBN......36 4. Refrigerant circuit ..................39 4-1. Models: AOYG09KMCBN, AOYG12KMCBN, and AOYG14KMCBN......39 5. Wiring diagrams ..................40 5-1.
-
Page 5: Part 1. Indoor Unit
Part 1. INDOOR UNIT WALL MOUNTED TYPE: ASYG09KMCB ASYG12KMCB ASYG14KMCB... -
Page 6: Specifications
1. Specifications Wall mounted Type Inverter heat pump Model name ASYG09KMCB ASYG12KMCB ASYG14KMCB Power supply 230 V ~ 50 Hz Power supply intake Outdoor unit Available voltage range 198—264 V 2.50 3.40 4.20 Rated Btu/h 8,500 11,600 14,300 Cooling 1.00—3.20 1.00—4.15... -
Page 7: Dimensions
2. Dimensions 2-1. Models: ASYG09KMCB, ASYG12KMCB, and ASYG14KMCB Unit: mm (840) Outline of unit for pipe inlet Ø65 - 3 - 2-1. Models: ASYG09KMCB, ASYG12KMCB, and ASYG14KMCB 2. Dimensions... - Page 8 ¢ Installation space requirement Provide sufficient installation space for product safety. Unit: mm Outline of unit 25 or more 52 or more 70 or more 130 or more 1,500 or more - 4 - 2-1. Models: ASYG09KMCB, ASYG12KMCB, and ASYG14KMCB 2. Dimensions...
-
Page 9: Wiring Diagrams
3. Wiring diagrams 3-1. Models: ASYG09KMCB, ASYG12KMCB, and ASYG14KMCB - 5 - 3-1. Models: ASYG09KMCB, ASYG12KMCB, and ASYG14KMCB 3. Wiring diagrams... -
Page 10: Capacity Table
Airflow Rate (AFR): For cooling capacity: Total Capacity (TC), Sensible Heat Capacity (SHC), and Input Power (IP) For heating capacity: Total Capacity (TC) and Input Power (IP) 4-1. Cooling capacity ¢ Model: ASYG09KMCB Indoor temperature °CDB °CWB °CDB... -
Page 11: Heating Capacity
4-2. Heating capacity NOTE: Values mentioned in the table are calculated based on the maximum capacity. ¢ Model: ASYG09KMCB Indoor temperature °CDB °CWB 2.91 1.46 2.84 1.49 2.77 1.52 2.70 1.55 2.63 1.58 3.21 1.58 3.14 1.61 3.06 1.65 2.98 1.68... -
Page 12: Fan Performance
5. Fan performance 5-1. Air velocity distributions ¢ Models: ASYG09KMCB and ASYG12KMCB Fan speed Operation mode Measuring conditions HIGH Unit: m/s Top view Vertical airflow direction louver: Up Horizontal airflow direction louver: Center Unit: m/s Top view Vertical airflow direction louver: Up Horizontal airflow direction louver: Left &... - Page 13 ¢ Model: ASYG14KMCB Fan speed Operation mode Measuring conditions HIGH Unit: m/s Top view Vertical airflow direction louver: Up Horizontal airflow direction louver: Center Unit: m/s Top view Vertical airflow direction louver: Up Horizontal airflow direction louver: Left & Right Unit: m/s Side view Vertical airflow direction louver: Up...
-
Page 14: Airflow
5-2. Airflow ¢ Models: ASYG09KMCB and ASYG12KMCB Cooling Fan speed Airflow HIGH QUIET Heating Fan speed Airflow HIGH QUIET - 10 - 5-2. Airflow 5. Fan performance... - Page 15 ¢ Model: ASYG14KMCB Cooling Fan speed Airflow HIGH QUIET Heating Fan speed Airflow HIGH QUIET - 11 - 5-2. Airflow 5. Fan performance...
-
Page 16: Operation Noise (Sound Pressure)
6. Operation noise (sound pressure) 6-1. Noise level curve ¢ Model: ASYG09KMCB Cooling Heating NC-65 NC-65 NC-60 NC-60 NC-55 NC-55 NC-50 NC-50 HIGH HIGH NC-45 NC-45 NC-40 NC-40 NC-35 NC-35 NC-30 NC-30 NC-25 NC-25 NC-20 NC-20 NC-15 NC-15... - Page 17 ¢ Model: ASYG14KMCB Cooling Heating NC-65 NC-65 NC-60 NC-60 NC-55 NC-55 NC-50 NC-50 HIGH HIGH NC-45 NC-45 NC-40 NC-40 NC-35 NC-35 NC-30 NC-30 NC-25 NC-25 NC-20 NC-20 NC-15 NC-15 QUIET QUIET 1,000 2,000 4,000 8,000 1,000 2,000 4,000 8,000 Octave band center frequency, Hz Octave band center frequency, Hz...
-
Page 18: Sound Level Check Point
6-2. Sound level check point Microphone Microphone NOTE: Detailed shape of the actual indoor unit might be slightly different from the one illustrated above. - 14 - 6-2. Sound level check point 6. Operation noise (sound pressure) -
Page 19: Safety Devices
7. Safety devices Model Type of Protection form protection ASYG09KMCB ASYG12KMCB ASYG14KMCB Circuit Current fuse (PCB*) 250 V, 3.15 A protection °C Activate Thermal Fan motor Fan motor stop protector protection 145 ±25°C program Reset Fan motor restart *PCB: Printed Circuit Board - 15 - 7. -
Page 20: External Input And Output
8. External input and output With using external input and output functions, this product can be operated inter-connectedly with an external device. Connector Input Output Remarks CNA01 Control input — See external input/output CNB01 — Operation status output settings for details. CNB02 —... - Page 21 • When function setting is “Forced stop” mode: Input signal Forced stop Command Normal Operation Indoor unit Stop Remote controller Remote control operation invalidity • Optional part: Part name Model name Exterior External input wire External connect kit UTY-XWZXZ5 Communication kit UTY-XCBXZ2 * For operating the external function, the wall mounted type requires the communication kit in addi- tion to the wire (UTY-XWZXZ5).
-
Page 22: External Output
8-2. External output With using external output function, operating status of this product can be transmitted to the exter- nal device, and also, this product can be inter-connected with the external device. ¢ Operation status output Air conditioner operation status signal can be output. •... - Page 23 ¢ Error status output Air conditioner error status signal can be output. • Circuit diagram example: Indoor unit control PCB Communication kit Connected unit Connector DC 24 V Example: Relay unit Example: Display Relay power supply 10 m* Signal Optional parts Locally purchased –...
-
Page 24: Group Connection
9. Group connection Wiring regulation on the remote controllers in the multi split models are reviewed and allowed for group connection. Example of group connection Indoor unit Indoor unit Outdoor unit Outdoor unit *Exterior of each device shown above might be different from the actual one. NOTES: •... -
Page 25: Remote Controller Address Setting Procedure For Wireless Remote Controllers
• Required parts for group connection – Optional part: Indoor unit type Communication kit Wall mounted UTY-XCBXZ2 As for the optional parts, refer to Chapter 13-2. "Others" on page 32. – Service part: Wire with connector (Service part no. 9705932012) Wiring example for multiple remote control or group control: Crimping terminal and its insulation cap (Locally purchased) -
Page 26: Remote Controller
10. Remote controller 10-1. Wireless remote controller ¢ Overview Signal transmitter MODE button FAN button 10°C HEAT button ECONOMY button SWING button OUTDOOR UNIT SET button LOW NOISE button TEMP. button ON TIMER button POWERFUL button OFF TIMER button Start/Stop button TIMER SELECT button RESET button... - Page 27 ¢ Specifications Controller Unit: mm Top view Front view Side view Size (H × W × D) 205 × 61 × 17 Weight 124 (without batteries) Holder Unit: mm 48.5 Ø 3.5 (Hole) Hole 26.2 69.3 Front View Side View Bottom View Size (H ×...
-
Page 28: Function Settings
11. Function settings To adjust the functions of this product according to the installation environment, various types of function settings are available. NOTE: Incorrect settings can cause a product malfunction. 11-1. Function settings by using remote controller Some function settings can be changed on the remote controller. After confirming the setting proce- dure and the content of each function setting, select appropriate functions for your installation envi- ronment. - Page 29 NOTES: • The air conditioner custom code is set to prior to shipment. • The remote controller resets to custom code when the batteries on the remote controller are replaced. If you use a custom code other than code , reset the custom code after replacing the batteries.
- Page 30 ¢ Contents of function setting Each function setting listed in this section is adjustable in accordance with the installation environ- ment. NOTE: Setting will not be changed if invalid numbers or setting values are selected. Function setting list Function no. Functions Filter sign Room temperature sensor control for cooling...
- Page 31 4) Auto restart Enables or disables automatic restart after a power interruption. Function number Setting value Setting description Factory setting Enable ♦ Disable NOTE: Auto restart is an emergency function such as for power outage etc. Do not attempt to use this function in normal operation.
- Page 32 9) Indoor unit fan control for energy saving for cooling Enables or disables the power-saving function by controlling the indoor unit fan rotation when the outdoor unit is stopped during cooling operation. Function number Setting value Setting description Factory setting Disable Enable ♦...
-
Page 33: 11-2.Custom Code Setting For Wireless Remote Controller
11-2. Custom code setting for wireless remote controller To interconnect the air conditioner and the wireless remote controller, assignment of the custom code for the wireless remote controller is required. NOTE: Air conditioner cannot receive a signal if the air conditioner has not been set for the custom code. -
Page 34: Accessories
Operating manual Cloth tape Operating manual Wall hook bracket (CD-ROM) Installation manual Tapping screw (large) Remote controller Tapping screw (small) Battery Air cleaning filter Remote controller Filter holder holder - 30 - 12-1. Models: ASYG09KMCB, ASYG12KMCB, and ASYG14KMCB 12. Accessories... -
Page 35: Optional Parts
13. Optional parts 13-1. Controllers Exterior Part name Model name Summary Large and full-dot liquid crystal screen, wide and large keys easy to press, user-intuitive arrow key. Wired remote Wire type: Polar 3-wire UTY-RVNYM controller Optional communication kit is necessary for installation. Room temperature can be controlled by detecting the temperature accurately with built-in thermo sensor. -
Page 36: 13-2.Others
13-2. Others Exterior Part name Model name Summary Required when external device is connected. External UTY-XWZXZ5 Optional communication kit is connect kit necessary for installation. Use to connect with optional devices Communication UTY-XCBXZ2 and air conditioner PCB. Remotely manage an air conditioning Wireless LAN UTY-TFNXZ1 system using mobile devices such as... -
Page 37: Part 2. Outdoor Unit
Part 2. OUTDOOR UNIT SINGLE TYPE: AOYG09KMCBN AOYG12KMCBN AOYG14KMCBN... -
Page 38: Specifications
1. Specifications Type Inverter heat pump Model name AOYG09KMCBN AOYG12KMCBN AOYG14KMCBN Power supply 230 V ~ 50 Hz Power supply intake Outdoor unit Available voltage range 198—264 V Starting current Cooling 2,020 2,020 2,020 Airflow rate Heating 1,440 1,620 1,620 Type ×... -
Page 39: Dimensions
2. Dimensions 2-1. Models: AOYG09KMCBN, AOYG12KMCBN, and AOYG14KMCBN Top view Side view Front view Airflow 17.5 hole (10) (10) (10) hole (6x20=120) (6x20=120) ø20 hole 4-ø11.3 mm hole Bottom view - 35 - 2-1. Models: AOYG09KMCBN, AOYG12KMCBN, and AOYG14KMCBN 2. Dimensions... -
Page 40: Installation Space
3. Installation space 3-1. Models: AOYG09KMCBN, AOYG12KMCBN, and AOYG14KMCBN ¢ Space requirement Provide sufficient installation space for product safety. Single outdoor unit installation • When the upper space is open: Unit: mm When there are obstacles at the rear only. When there are obstacles at the rear and sides. - Page 41 Multiple outdoor unit installation • When the upper space is open: Unit: mm When there are obstacles at the rear only. When there are obstacles at the front only. 1,000 or more or more When there are obstacles at the front and rear.
- Page 42 Outdoor unit installation in multi-row Unit: mm Single parallel unit arrangement Multiple parallel unit arrangement 100 or more 200 or more 1,000 or more 2,000 or more 200 or more 400 or more 1,000 or more 500 or more 200 or more NOTES: •...
-
Page 43: Refrigerant Circuit
4. Refrigerant circuit 4-1. Models: AOYG09KMCBN, AOYG12KMCBN, and AOYG14KMCBN Heat exchanger 3-way ( INDOOR ) valve 2-way Muffler valve Muffler 4-way valve Strainer Expansion valve Heat exchanger Strainer ( OUTDOOR ) Cooling Heating :Thermistor (Discharge temp.) :Thermistor (Outdoor temp.) :Thermistor (Heat exchanger out temp.) :Thermistor (Room temp.) :Thermistor (Pipe temp.) - 39 -... -
Page 44: Wiring Diagrams
5. Wiring diagrams 5-1. Models: AOYG09KMCBN, AOYG12KMCBN, and AOYG14KMCBN - 40 - 5-1. Models: AOYG09KMCBN, AOYG12KMCBN, and AOYG14KMCBN 5. Wiring diagrams... -
Page 45: Capacity Compensation Rate For Pipe Length And Height Difference
6. Capacity compensation rate for pipe length and height difference Height difference H Indoor unit is higher than outdoor unit Indoor unit is lower than outdoor unit Outdoor unit Indoor unit Outdoor unit Indoor unit Connection pipe Connection pipe 6-1. Model: AOYG09KMCBN NOTE: Values mentioned in the table are calculated based on the maximum capacity. -
Page 46: Model: Aoyg12Kmcbn
6-2. Model: AOYG12KMCBN NOTE: Values mentioned in the table are calculated based on the maximum capacity. Pipe length (m) COOLING — — — 0.882 0.880 — — 0.943 0.896 0.894 Indoor unit is higher than outdoor unit *1 — 0.968 0.947 0.900 0.898... -
Page 47: Additional Charge Calculation
7. Additional charge calculation 7-1. Models: AOYG09KMCBN, AOYG12KMCBN, and AOYG14KMCBN Refrigerant type Refrigerant amount ¢ Refrigerant charge Total pipe length 15 or less 20 (Max.) 20 g/m Additional charge - 43 - 7-1. Models: AOYG09KMCBN, AOYG12KMCBN, and AOYG14KMCBN 7. Additional charge calculation... -
Page 48: Airflow
8. Airflow 8-1. Model: AOYG09KMCBN Cooling 2,020 1,189 Heating 1,440 8-2. Model: AOYG12KMCBN Cooling 2,020 1,189 Heating 1,620 8-3. Model: AOYG14KMCBN Cooling 2,020 1,189 Heating 1,620 - 44 - 8-1. Model: AOYG09KMCBN 8. Airflow... -
Page 49: Operation Noise (Sound Pressure)
9. Operation noise (sound pressure) 9-1. Noise level curve ¢ Model: AOYG09KMCBN Cooling Heating NC-65 NC-65 NC-60 NC-60 NC-55 NC-55 NC-50 NC-50 NC-45 NC-45 NC-40 NC-40 NC-35 NC-35 NC-30 NC-30 NC-25 NC-25 NC-20 NC-20 NC-15 NC-15 1,000 2,000 4,000 8,000 1,000... -
Page 50: Sound Level Check Point
¢ Model: AOYG14KMCBN Cooling Heating NC-65 NC-65 NC-60 NC-60 NC-55 NC-55 NC-50 NC-50 NC-45 NC-45 NC-40 NC-40 NC-35 NC-35 NC-30 NC-30 NC-25 NC-25 NC-20 NC-20 NC-15 NC-15 1,000 2,000 4,000 8,000 1,000 2,000 4,000 8,000 Octave band center frequency, Hz Octave band center frequency, Hz 9-2. -
Page 51: Electrical Characteristics
10. Electrical characteristics Model name AOYG09KMCBN AOYG12KMCBN AOYG14KMCBN Voltage 230~ Power supply Frequency Max operating current *1 11.0 11.5 Starting current Circuit breaker current Power cable Wiring Cross-sectional spec. *2 area Connection cable *3 Limited wiring length *1: Maximum operating current is the total current of the indoor unit and the outdoor unit. *2: Selected sample based on Japan Electrotechnical Standards and Codes Committee E0005. -
Page 52: Safety Devices
11. Safety devices Model Type of Protection form protection AOYG09KMCBN AOYG12KMCBN AOYG14KMCBN 250 V, 25 A Current fuse (Main PCB) 250 V, 5 A Circuit protection 250 V, 3.15 A Current fuse (Wire) 250 V, 3.15 A 100 ±15 °C Activate Fan motor stop Fan motor... -
Page 53: Accessories
12. Accessories 12-1. Models: AOYG09KMCBN, AOYG12KMCBN, and AOYG14KMCBN Part name Exterior Q’ty Part name Exterior Q’ty Installation manual - 49 - 12-1. Models: AOYG09KMCBN, AOYG12KMCBN, and AOYG14KMCBN 12. Accessories...
