- Page 1 SolarMount-I™ INSTALLATION MANUAL © 2011 by Unirac, Inc. All rights reserved. Pub 110518-1ii, May 2011 1411 Broadway Boulevard NE Albuquerque, NM 87102-1545 USA A HILTI GROUP COMPANY...
- Page 2 IMPORTANT! Unirac Inc. makes no warranty of any kind with regard Unirac Inc. to this material, including, but not limited to, the Marketing Department implied warranties of merchantability and fitness for a 1411 Broadway Boulevard, NE particular purpose. Albuquerque, NM 87102-1545 The information in this document is subject to change ©...
-
Page 3: Additional Components
COMPONENTS Beam Mid Clamp (1) Stainless steel hex bolt SolarMount-I 1.0 Beam = 1.094” Height (1) Stainless steel flange nut 144” Length (1) Slider SolarMount-I 2.5 Beam = 2.5” Height (1) Mid Clamp 144” and 192” Lengths End Clamp (1) Stainless steel hex bolt (1) Stainless steel flange nut 2 Flange Connection * (1) Slider... -
Page 4: Optional Attachments
OPTIONAL ATTACHMENTS 2-Piece Aluminum Standoff (2) 5/16 x 3-1/2” Zinc Plated Lag Bolt (1) 1 Flange Connection (1) 3/8” x 3/4” Hex Head Bolt (1) 3/8” x 1-3/4” EPDM Washer CreoTecc Tile Hook (Top) (2) 5/16” x 3-1/2” Zinc Plated Lag Bolt (1) 3/8-16 x 3/4”... - Page 5 PLANNING YOUR SOLARMOUNT-I™ INSTALLATION The installation can be laid out with beams parallel to Peak the rafters or perpendicular to the rafters. Note that High-profile SolarMount-I™ Beams make excellent straight edges mode for doing layouts. Center the installation area over the structural members as much as possible.
- Page 6 INSTALLING SOLARMOUNT-I™ Step 1: Attach beam to 2 Flange Connection or 1 Flange Connection NOTE: Always engage the double-wall side before clicking connection into beam. NOTE: Do not use connection if the engagement features on the connection are bent, damaged, or obstructed by debris. Beam NOTE: When installing on pitched roof configurations, locate double-wall section of connection on the downhill side of roof slope.
- Page 7 Step 2: Attach 2 Flange Connection or 1 Flange Connection to rafter NOTE: When using 2 Flange Connection w/Butyl Pad, remove liner before installing screws. Lag Bolt Concealor Screw 2 Flange Connection Option 1 Flange Connection Option Step 3: Install appropriate number of sliders and optional UGC-2 grounding clips Slider UGC-2 (optional)
- Page 8 Step 4A: Install Splices (1) - Use when splicing two beams at a connection. NOTE: Use anti-seize on bolt and tighten nut to 10 foot-pounds. Splice Bar Optional Grounding Clip Step 4B: Install Splices (2) - Place at least one splice to act as a retaining clip over a flange connection for every run of beam.
- Page 9 Step 5: Installing Grounding Lugs Grounding Lug Step 6: Install modules using top mounting hardware NOTE: Use anti-seize on bolt and tighten nut to 10 foot-pounds. Mid Clamp End Clamp Module Module Module...
-
Page 10: Warranty
WARRANTY Warranty Information See http://www.unirac.com for current warranty documents and information. YOUR UNIRAC DISTRIBUTOR SOLIGENT 800-967-6917 www.soligent.net SolarMount-I™ INSTALLATION MANUAL www.unirac.com...
