7 APPENDIX B – QUICK REFERENCE GUIDE
REMOTE
CONNECTION SOCKET
ADJUSTMENT SCREW
(RECESSED UNDER
FACE)
STATUS LED
LOW OXYGEN ALARM
LED
CRITICALLY LOW
OXYGEN ALARM LED
SERIAL NUMBER AND
SERVICE LABELS
REPLACE BY DATE
LABEL
SENSOR FILTER
ONE O2 OXYGEN MONITOR ALARM UNITS
www.quantumcryogenics.com
CALIBRATION
BUTTON
AUDIBLE ALARM
CAL HIGH GREEN LED
CAL LOW GREEN LED
LOW BATTERY LED
