2.2.5

WDCSR: Watchdog Timer, Control, and Status Register

A watchdog timer (WDT) with 1ms clock is provided. If this register is not accessed for a period of 32ms, the WDT
counter will reset the MCU. (See Figure 2–3, Reset Diagram). When the IDL bit in PCON is set, the WDT will be
suspended until an interrupt is detected. At this point, the IDL bit will be cleared and the WDT will resume operation.
7 6 5
WDE WDR RSV
R/W R/W R/O
BIT NAME RESET
0 WDT 0
5–1 RSV 0
6 WDR 0
7 WDE 0
2.2.6

PCON: Power Control Register (at SFR 87h)

7 6 5
SMOD RSV RSV
R/W R/O R/O
BIT NAME RESET
0 IDL 0
1 RSV 0
3–2 GF[1:0] 00
6–4 RSV 0
7 SMOD 0

2.3 Buffers + I/O RAM Map

The address range from FD80 to FFFF is reserved for data buffers, setup packet, endpoint descriptor blocks (EDB),
and all I/O. RAM space of 512 bytes [FD80–FF7F] is used for EDB and buffers. The FF80–FFFF range is used for
memory mapped registers (MMR). Table 2–1 represents the internal XDATA space allocation.
2–4
4 3 2
RSV RSV RSV
R/O R/O R/O
MCU must write a 1 to this bit to prevent the WDT from resetting the MCU. If MCU does not write a 1 in a
period of 31ms, the WDT will reset the device. Writing a 0 has no effect on the WDT. (WDT is a 5-bit counter
using 1ms CLK). This bit is read as 0.
Reserved = 0
Watchdog reset indication bit. This bit indicates if the reset occurred due to power-on reset or watchdog
timer reset.
WDR = 0 A power-up or USB reset occurred.
WDR = 1 A watchdog timeout reset occurred. To clear this bit, the MCU must write a 1. Writing a 0 has no
effect.
Watchdog Timer Enable.
WDE = 0 This bit is cleared only on power-up, USB-reset (if enabled) or WDT reset.
WDE = 1 When MCU writes a 1 to this bit the WDT will start running. MCU cannot disable the WDT. Only
power up or USB reset (if enabled) can clear it. When MCU is in idle state (IDL = 1), the WDT is
suspended.
4 3 2
RSV GF1 GF0
R/O R/W R/W
MCU idle mode bit. This bit can be set by MCU and is cleared only by INT1 interrupt.
IDL = 0 MCU is NOT in idle mode. This bit is cleared by INT1 interrupt logic when INT1 is asserted for
at least 400µs.
IDL = 1 MCU is in idle mode and RAM is in low-power mode. The oscillator/APLL is off and the WDT
will be suspended. When in suspend mode, only INT1 can be used to exit from idle mode and
generate an interrupt. INT1 must be asserted for at least 400µs for the interrupt to be
recognized.
Reserved
General-purpose bits. MCU can write and read them.
Reserved
Double baud rate control bit. For more information see UART serial interface in M8052 core specification.
1 0
RSV WDT
R/O W/O
FUNCTION
1 0
RSV IDL
R/O R/W
FUNCTION
