Graco C Series Instructions Manual

Pressure roller with 20” fixed extension
Hide thumbs Also See for C Series:
1
2
3
4
5
6
7
8
Table of Contents

Advertisement

Quick Links

Download this manual
Instructions, Parts
Pressure Roller with
20" Fixed Extension
For use on any Graco high pressure airless gun. For professional use only.
Model 244279, Series C
•
20 in. (50 cm) heavy-duty extension
•
9 in. (23 cm) roller frame
•
1/2 in. (13 mm) nap roller cover
•
45° swivel adapter
3600 psi (24.8 MPa, 248 bar) Maximum Fluid Inlet Pressure*
* The best operating pressure is the lowest pressure that provides
an even paint supply to the roller and typically does not exceed
300 psi (2.1 MPa, 21 bar).
Important Safety Instructions
Read all warnings and instructions in this
manual before using the equipment. Be
familiar with the controls and the proper
usage of the equipment. Save these
instructions.
NOTICE
Never leave water in the pump, gun, or pressure roller.
Doing so could cause corrosion and damage from
freezing. For storage, flush the system with Graco
Pump Armor
or mineral spirits.
TM
309323F
EN

Advertisement

Table of Contents
loading

Related Manuals for Graco C Series

Summary of Contents for Graco C Series

  • Page 1 Instructions, Parts Pressure Roller with 309323F 20” Fixed Extension For use on any Graco high pressure airless gun. For professional use only. Model 244279, Series C • 20 in. (50 cm) heavy-duty extension • 9 in. (23 cm) roller frame •...

  • Page 2: Electrocution Hazard

    Warnings Warnings The following warnings are for the setup, use, grounding, maintenance, and repair of this equipment. The exclamation point symbol alerts you to a general warning and the hazard symbols refer to procedure-specific risks. When these symbols appear in the body of this manual or on warning labels, refer back to these Warnings. Product-specific hazard symbols and warnings not covered in this section may appear throughout the body of this manual where applicable.
  • Page 3 Do not kink or over-bend the hose. • Do not expose the hose to temperatures or to pressures in excess of those specified by Graco. • Do not use the hose as a strength member to pull or lift the equipment.

  • Page 4: Pressure Relief Procedure

    Pressure Relief Procedure Pressure Relief Procedure 5. Engage gun trigger lock, and keep pump prime/spray valve in PRIME position until you paint again. Additional Roller Covers The following pressure roller covers are available at This equipment stays pressurized until pressure is your local distributor: manually relieved.

  • Page 5: Operation

    Operation Operation 1. Follow pump priming instructions using lowest 4. Increase pump pressure only if triggering the gun pressure setting at which pump primes. cannot supply enough paint for your rolling speed. 2. Turn prime/spray valve to SPRAY position. 5. Whenever you stop painting, perform Pressure Relief Procedure, page 4, and elevate roller end of 3.
  • Page 6 If you are going to store the airless equipment for an 107590 ROLLER, cover, 9 in., 1/2 in. (13 extended period of time after flushing with water-base mm) nap fluid, flush again with Graco Pump Armor or mineral 15B065 DIFFUSER spirits/paint thinner. Leave the fluid in the system during storage.

  • Page 7: Graco Standard Warranty

    With the exception of any special, extended, or limited warranty published by Graco, Graco will, for a period of twelve months from the date of sale, repair or replace any part of the equipment determined by Graco to be defective.
  • Page 8 Original instructions. This manual contains English. MM 309323 Graco Headquarters: Minneapolis International Offices: Belgium, China, Japan, Korea GRACO INC. AND SUBSIDIARIES • P.O. BOX 1441 • MINNEAPOLIS MN 55440-1441 • USA Copyright 2001, Graco Inc. All Graco manufacturing locations are registered to ISO 9001. www.graco.com...

This manual is also suitable for:

244279
