D-Link DCS-8000LH Faq

Mini hd wifi camera
Hide thumbs Also See for DCS-8000LH:
Table of Contents

Advertisement

Quick Links

Download this manual
DCS-8000LH
HW Version
FW Version
App Name
App Version
A1
V1.00.05
Mydlink Lite
V3.8.0

Advertisement

Table of Contents
loading

Related Manuals for D-Link DCS-8000LH

Summary of Contents for D-Link DCS-8000LH

  • Page 1 DCS-8000LH HW Version FW Version App Name App Version V1.00.05 Mydlink Lite V3.8.0...

  • Page 2: Table Of Contents

    Q3: How to setup Sound detection? ..................12 Q4: Does DCS-8000LH support SD Card recording? .............. 15 Q5: How to send Email Notification from DCS-8000LH when Motion is detected? ....17 Q6: How to send Email Notification from DCS-8000LH when Sound is detected? ....20 Q7: How do I access my DCS-8000LH camera remotely?............

  • Page 3: Q1: How To Setup Dcs-8000Lh Using Mydlink Lite App

    Q1: How to setup DCS-8000LH using mydlink Lite App? Step 1: Download the free mydlink Lite app on your smartphone or tablet by scanning the QR code in below or by searching for mydlink Lite in the app store (Apple Store, Google Play, or Window Store) for your device.
  • Page 4 Step 3: Tap Add a New Camera...
  • Page 5 Step 4: To scan a QR code, use the code on the label attached to the bottom of your device. Step 5: Wait until the LED blinks orange, then tap Ready.
  • Page 6 Step 6: Choose a Wi-Fi with a strong signal. Step 7: Set a password to protect your camera. Note: If you forget your password, you must reset the camera. Unfortunately, this process will change your settings back to factory default. To reset the camera, have the camera powered on and use an unfolded paper clip to hold the reset button down for 10 seconds.
  • Page 7 Step 8: Tap YES to add the device to your mydlink account. Step 9: The Remote devices screen will display the device you have registered with your mydlink account. Step 10: Tap the DCS-8200LH camera. The current live view of the camera will be displayed.

  • Page 8: Q2: How To Setup Motion Detection

    Q2: How to setup Motion detection? Motion detection enables the camera to monitor specific areas of your home or office for movement. You can adjust the sensitivity which determines when motion is detected by the camera. When motion is detected, it will trigger to send a notification. Step 1: Tap the DCS-8200LH camera.
  • Page 9 Step 3: Tap Motion Detection. Step 4: Tap the button next to Enable Motion Detection to turn on.
  • Page 10 Step 5: Tap Active Area to select the area you want the camera to detect motion. Step 6: Tap on the area you want the camera to detect motion. Then, select the sensitivity level by moving the slider left or right to the sensitivity percentage you want. The sensitivity setting decides how sensitive the camera will be to motion, where 100% will be the most sensitive setting and 0% will be the least sensitive setting.
  • Page 11 Step 7: Go back to the device list, and tap the icon in the top left corner. Step 8: Tap Push Notification...
  • Page 12 Step 9: Tap the button next to the camera name to enable or disable push notification.

  • Page 13: Q3: How To Setup Sound Detection

    Q3: How to setup Sound detection? Sound detection enables the camera to monitor the environment for loud sounds. You may set the volume threshold between 70 dB and 90 dB. Step 1: Tap the DCS-8200LH camera. Then, tap the camera main feature icon in the top-right corner. Step 2: Tap Settings on the camera main feature menu.
  • Page 14 Step 3: Tap Sound Detection. Then, tap the button next to Enable Sound Detection to turn on. Step 4: Slide the level bar up or down to the sound level you want. Any noise above the threshold you choose will trigger a notification.
  • Page 15 Step 5: Go back to the device list, and tap the icon in the top left corner. Step 6: Tap the button next to the camera name to enable or disable push notification.

  • Page 16: Q4: Does Dcs-8000Lh Support Sd Card Recording

    Q4: Does DCS-8000LH support SD Card recording? No, DCS-8000LH does not support SD Card recording, you can record the video to local device(Mobile Phone or tablet). For iOS Device: Step 1: Go to Live View, press the record icon Step 2: Go to the Album and check the video file in your mobile device.
  • Page 17 For aOS device: Step 1: Go to Live View, press the record icon Step 2: A prompter “Video Saved to Your Device-OK” will automatically display for your reference, if the recording is successful.

  • Page 18: Q5: How To Send Email Notification From Dcs-8000Lh When Motion Is Detected

    Q5: How to send Email Notification from DCS-8000LH when Motion is detected? Step 1: Go to mydlink portal www.mydlink.com , sign in to mydlink. Step 2: Select DCS-8000LH device displayed in the device list. Then, click on the Settings tab for your camera.
  • Page 19 Step 3: Check the Enable e-mail notifications box to allow notifications can be sent to your mydlink registered e-mail address. Check the Motion Detection box to enable motion detection. Step 4: Use your mouse to click and drag on the area that you would like to monitor for motion. Then, select the sensitivity level by moving the slider left or right to the sensitivity percentage you want.
  • Page 20 Step 5: Review your settings and click on Back if you need to make some modifications. If settings are correct, click Finish. Step 6: Check the Enable e-mail notifications box to allow notifications be sent to your mydlink registered e- mail address.

  • Page 21: Q6: How To Send Email Notification From Dcs-8000Lh When Sound Is Detected

    Q6: How to send Email Notification from DCS-8000LH when Sound is detected? Step 1: Check the Enable e-mail notifications box to allow notifications be sent to your mydlink registered e- mail address. Check the Sound Detection box to turn sound detection on.
  • Page 22 Step 3: Review your settings and click on Back if you need to make modifications. If settings are correct, click Finish. Step 4: Back to the settings page and remember to click Save, if settings are correct. Note: If you are using G-mail account you should switch to a lower level of security.

  • Page 23: Q7: How Do I Access My Dcs-8000Lh Camera Remotely

    Please go to http://support.dlink.com/ Q8: What can I do if my DCS-8000LH is not working correctly? Reset the camera and run the setup steps again. • To reset the camera, use a paper clip and then press and hold the reset button for 10 seconds and release.

  • Page 24: Q9: Does The Dcs-8000Lh Support Cloud-Based Recordings

    Q9: Does the DCS-8000LH support cloud-based recordings? In the future, you can store some footage online for free, with additional priced tiers for more storage. Q10: Does DCS-8000LH camera work with other smart home devices like alarm, smart plugs using mydlink home App? No, DCS-8000LH does not support any smart home devices with mydlink home app.

  • Page 25: Q12: How To Check The Mac Address Of This Camera

    Q12: How to check the mac address of this camera? Two ways can be used to check the mac address: The MAC Address is listed on the sticker located on the bottom of the camera. You can access to mydlink portal and tab the Settings to find mac address.

  • Page 26: Q13: Why Have I Not Received The Verification E-Mail For My Mydlink Account

    If you still do not receive the e-mail, try using a different e-mail address or e-mail host. Q14: Does DCS-8000LH support Night Vision? Yes, DCS-8000LH has removable IR-cut filter and IR LED which supports 5M distance for low-light environments, even complete darkness.

  • Page 27: Q16: Does Dcs-8000Lh Support Bluetooth? How It Works

    Before updating the firmware, make sure you are near a known Wi-Fi network and remain on the same network for the time it takes to update the firmware. If a D-Link camera firmware update fails due to a broken network connection during the firmware upload or power loss during the firmware upload/installation, it is possible that the network camera will be rendered unusable.
  • Page 28 support. Step1: Launch the mydlink Lite. Tap DCH-8000LH. A prompter “New firmware available” will appear, if a newer version is detected. Tap Upgrade. Step2: The percentage progress of the downloading firmware file will automatically display for your reference.

  • Page 29: Q18: What Mobile App Can Work With Dcs-8000Lh? What Is The System Requirement Of The Mobile App

    Q18: What Mobile app can work with DCS-8000LH? What is the system requirement of the Mobile App? At launch, DCS-8000LH will only work with the mydlink Lite app and will not be compatible with the mydlink Home app. Mydlink Lite app is compatible with iPhone and iPad using iOS 9.0 or higher and Android smartphones and...
