- Page 1 Quick Installation Guide DIR-620S Wireless N300 Router with 3G/LTE Support and USB Port...
-
Page 2: Before You Begin
If any of the items are missing, please contact your reseller. The “User Manual” and “Quick Installation Guide” documents are available on D-Link website (see www.dlink.ru). Using a power supply with a different voltage rating than the one included will cause damage and void the warranty for this product. -
Page 3: Default Settings
Router DIR-620S with default settings cannot connect to the Internet. To get started, please set your own password for access to the web- based interface and change the WLAN name (SSID); then, if needed,... -
Page 4: System Requirements And Equipment
DIR-620S Quick Installation Guide System Requirements and Equipment A computer with any operating system that supports a web browser. • A web browser to access the web-based interface of the router: • ◦ Apple Safari 8 and later ◦ Google Chrome 48 and later ◦... -
Page 5: Pc With Ethernet Adapter
DIR-620S Quick Installation Guide CONNECTING TO PC PC with Ethernet Adapter 1. Connect an Ethernet cable between any of LAN ports located on the back panel of the router and the Ethernet port of your PC. 2. To connect via USB modem: connect your USB modem to the USB port located on the back panel of the router. - Page 6 DIR-620S Quick Installation Guide Obtaining Address Automatically (OS Windows 7) 1. Click the Start button and proceed to the Control Panel window. 2. Select the Network and Sharing Center section. (If the Control Panel has the category view (the Category value is selected from the View by...
- Page 7 DIR-620S Quick Installation Guide 6. Make sure that the Obtain an IP address automatically and Obtain DNS server address automatically choices of the radio buttons are selected. Click the OK button. 7. Click the OK button in the connection properties window.
-
Page 8: Pc With Wi-Fi Adapter
DIR-620S Quick Installation Guide PC with Wi-Fi Adapter 1. To connect via USB modem: connect your USB modem to the USB port located on the back panel of the router. In some cases you will need to reboot the router after connection of the USB modem. - Page 9 DIR-620S Quick Installation Guide Obtaining Address Automatically Connecting to Wireless Network (OS Windows 7) 1. Click the Start button and proceed to the Control Panel window. 2. Select the Network and Sharing Center section. (If the Control Panel has the category view (the Category value is selected from the View by...
- Page 10 DIR-620S Quick Installation Guide 6. Make sure that the Obtain an IP address automatically and Obtain DNS server address automatically choices of the radio buttons are selected. Click the OK button. 7. Click the OK button in the connection properties window.
- Page 11 DIR-620S Quick Installation Guide 9. In the opened window, in the list of available wireless networks, select the wireless network DIR-620 and click the Connect button. 10. In the opened window, enter the network key (see WPS PIN on the barcode label on the bottom panel of the device) in the Security key field and click the OK button.
-
Page 12: Configuring Router
DIR-620S Quick Installation Guide CONFIGURING ROUTER Connecting to Web-based Interface Start a web browser. In the address bar of the web browser, enter the domain name of the router (by default, dlinkrouter.local) with a dot at the end and press the Enter key. Also you can enter the IP address of the device (by default, 192.168.0.1). - Page 13 DIR-620S Quick Installation Guide If you configured the device previously, after access to the web-based interface the login page opens. Enter the username (admin) in the Username field and the password you specified in the Password field, then click the LOGIN button.
- Page 14 DIR-620S Quick Installation Guide The Summary page displays general information on the router and its software.
- Page 15 DIR-620S Quick Installation Guide The Home page displays links to the most frequently used pages with device's settings. The web-based interface of the router is bilingual (English/Russian). You can select the needed language upon the initial configuration of the web-based interface of the router or in the System / Configuration section of the menu.
-
Page 16: Initial Configuration Wizard
Click the OK button and wait until the factory default settings are restored. If you perform initial configuration of the router via Wi-Fi connection, please make sure that you are connected to the wireless network of DIR-620S (see the WLAN name (SSID) in the Default Settings section, page 3) and click the NEXT button. - Page 17 DIR-620S Quick Installation Guide 1. Click YES in order to leave the current language of the web-based interface or click NO to select the other language. 2. On the next page, click the CONTINUE button.
-
Page 18: Selecting Operation Mode
DIR-620S Quick Installation Guide Selecting Operation Mode In order to connect your device to a wired ISP, on the Device mode page, from the Connection method list, select the Wired connection value. Then from the Work mode list select the Router value. In this mode you can... - Page 19 DIR-620S Quick Installation Guide In order to connect your device to a wireless ISP (WISP), on the Device mode page, from the Connection method list, select the Wi-Fi value. Then from the Work mode list select the WISP Repeater value. In this...
- Page 20 DIR-620S Quick Installation Guide Creating 3G/LTE WAN Connection This configuration step is available for the 3G/LTE modem mode. 1. If the PIN code check is enabled for the SIM card inserted into your USB modem, enter the PIN code in the PIN field and click the APPLY button.
-
Page 21: Changing Lan Ipv4 Address
If you want to manually assign the LAN IPv4 address for DIR-620S, do not select the Automatic obtainment of IPv4 address checkbox and fill in the IP address, Subnet mask, Hostname fields and, if needed, the Gateway IP address field. - Page 22 DIR-620S Quick Installation Guide Wi-Fi Client This configuration step is available for the WISP Repeater, Repeater, and Client modes. 1. On the Wi-Fi Сlient page, click the WIRELESS NETWORKS button and select the network to which you want to connect in the opened window.
- Page 23 DIR-620S Quick Installation Guide Configuring Wired WAN Connection This configuration step is available for the Router and WISP Repeater modes. You should configure your WAN connection in accordance with data provided by your Internet service provider (ISP). Make sure that you have obtained all necessary information prior to configuring your connection.
- Page 24 DIR-620S Quick Installation Guide PPPoE, IPv6 PPPoE, PPPoE Dual Stack, PPPoE + Dynamic IP (PPPoE Dual Access): Enter authorization data provided by your ISP (the username (login) in the Username field and the password in the Password field). Click the Show icon ( ) to display the entered password.
- Page 25 DIR-620S Quick Installation Guide PPTP + Dynamic IP or L2TP + Dynamic IP: Enter authorization data provided by your ISP (the username (login) in the Username field and the password in the Password field). Click the Show icon ( ) to display the entered password.
- Page 26 DIR-620S Quick Installation Guide If your ISP uses MAC address binding, select the Clone MAC address of your device checkbox. If the Internet access is provided via a VLAN channel, select the Use VLAN checkbox and fill in the VLAN ID field.
-
Page 27: Configuring Wireless Network
DIR-620S Quick Installation Guide Configuring Wireless Network This configuration step is available for the 3G/LTE modem, Router, Access point, WISP Repeater, and Repeater modes. 1. On the Wireless Network 2.4 GHz page, in the Network name field, specify your own name for the wireless network or leave the value suggested by the router. - Page 28 DIR-620S Quick Installation Guide 5. If you want to create an additional wireless network isolated from your LAN, select the Enable guest network checkbox (available for the 3G/LTE modem, Router, and WISP Repeater modes only). 6. In the Network name field, specify your own name for the guest wireless network or leave the value suggested by the router.
-
Page 29: Configuring Lan Ports For Iptv/Voip
DIR-620S Quick Installation Guide Configuring LAN Ports for IPTV/VoIP This configuration step is available for the Router and WISP Repeater modes. 1. On the IPTV page, select the Is an STB connected to the device checkbox. 2. Select a free LAN port for connecting your set-top box. -
Page 30: Changing Web-Based Interface Password
DIR-620S Quick Installation Guide Changing Web-based Interface Password On this page you should change the default administrator password. To do this, enter a new password in the Admin password and Password confirmation fields. You may set any password except admin. Use digits, Latin letters (uppercase and/or lowercase), and other characters available in the US keyboard layout. -
Page 31: Configuring Local Area Network
DIR-620S Quick Installation Guide Configuring Local Area Network Go to the Connections Setup / LAN page. If needed, change the IPv4 address of the router's LAN interface and the mask of the local subnet. To do this, click the IPv4 tab and specify needed values in the IP address and Mask fields in the Local IP Address section. - Page 32 DIR-620S Quick Installation Guide IPv4 address assignment. By default, the built-in DHCP server of the router assigns IPv4 addresses to the devices of the LAN. If you want to manually assign IPv4 addresses, disable the DHCP server (click the IPv4 tab and select the Disable value from the Mode of dynamic IP address assignment drop-down list in the Dynamic IP Addresses section).
- Page 33 DIR-620S Quick Installation Guide Configuring Network Printer Make sure that a driver for your printer which will be used as a network printer is installed on your PC. To connect the printer to the router, power off both devices. Connect the printer to the USB port of the router, power on the printer, then power on the router.
- Page 34 DIR-620S Quick Installation Guide In the opened window, click the Add a printer button. Select the Add a local printer value and click the Next button. Select the Create a new port choice of the radio button and then select...
- Page 35 DIR-620S Quick Installation Guide Enter the IP address of the router in the Hostname or IP address field (by default, 192.168.0.1). Deselect the Query the printer and automatically select the driver to use checkbox and, if needed, change the name of the port in the Port name field. Click the Next button.
- Page 36 DIR-620S Quick Installation Guide Select your printer and click the Next button. Select the Use the driver that is currently installed choice of the radio button and click the Next button. Enter a name of the printer (you can specify any name) in the Printer name field and click the Next button.
- Page 37 DIR-620S Quick Installation Guide 16. If you need to print a test page, click the Print a test page button. To finish the printer installation, click the Finish button.
-
Page 38: Specifications
DIR-620S Quick Installation Guide SPECIFICATIONS Hardware Processor · RTL8196D (620MHz) · 64MB, DDR SDRAM · Flash 8MB, SPI · 10/100BASE-TX WAN port Interfaces · 4 10/100BASE-TX LAN ports · USB 2.0 port · POWER LEDs · WLAN · · INTERNET ·... - Page 39 DIR-620S Quick Installation Guide Software · Support of IEEE 802.1X for Internet connection Network functions · DHCP server/relay · Stateful/Stateless mode for IPv6 address assignment, IPv6 prefix delegation · Automatic obtainment of LAN IP address (for access point/repeater/client modes) ·...
- Page 40 Management TELNET/WEB (HTTP/HTTPS) · Bilingual web-based interface for configuration and management (Russian/English) · Support of D-Link Assistant application for Android and iPhone smartphones · Notification on connection problems and auto redirect to settings · Firmware update via web-based interface ·...
- Page 41 DIR-620S Quick Installation Guide Wireless Module Parameters · Support of client mode Advanced functions · WMM (Wi-Fi QoS) · Information on connected Wi-Fi clients · Advanced settings · Smart adjustment of Wi-Fi clients · Guest Wi-Fi / support of MBSSID ·...
- Page 42 DIR-620S Quick Installation Guide Wireless Module Parameters Receiver sensitivity · 802.11b (typical at PER = 8% at room temperature 25 °C) -82dBm at 1Mbps -80dBm at 2Mbps -78dBm at 5.5Mbps -76dBm at 11Mbps · 802.11g (typical at PER = 10% at room temperature 25 °C)
- Page 43 Storage: from 5% to 95% (non-condensing) Supported USB modems · Alcatel X500 · D-Link DWM-152C1 · D-Link DWM-156A6 · D-Link DWM-156A7 · D-Link DWM 156A8 · D-Link DWM-156C1 · D-Link DWM-157B1 · D-Link DWM-157B1 (Velcom) · D-Link DWM-158D1 · D-Link DWR-710 ·...
- Page 44 DIR-620S Quick Installation Guide Supported USB modems · Alcatel IK40V · D-Link DWM-222 · Huawei E3131 · Huawei E3272 · Huawei E3351 · Huawei E3372 · Huawei E367 · Huawei E392 · Megafon M100-1 · Megafon M100-2 · Megafon M100-3 ·...
-
Page 45: Safety Rules And Conditions
DIR-620S Quick Installation Guide SAFETY RULES AND CONDITIONS Please carefully read this section before installation and connection of the device. Make sure that the power adapter and cables are not damaged. The device should be used only as intended in accordance with the documents. -
Page 46: Technical Support
Quick Installation Guide TECHNICAL SUPPORT You can find software updates and user documentation on our website. D-Link provides its customers with free support within the product's warranty period. Customers can contact the technical support group by phone or by e- mail/Internet.
