Summary of Contents for Denon PMA-A110
- Page 1 Read PMA-A110 first Quick start guide...
-
Page 2: Before You Begin
Welcome Before You Begin What’s In the Box Thank you for choosing a Denon amplifier. This guide provides step-by-step instructions for setting up your amplifier. Quick Start Guide Power cord Remote control unit Safety Instructions (RC-1237) Warranty (for North R03/AAA batteries... -
Page 3: Required For Setup
Required for Setup CD player Speaker systems Speaker cables Optional Computer USB cable These drawings are for illustrative purposes only and may not represent the actual product(s). - Page 4 Install batteries in the remote control unit Install batteries in the remote control unit Connect the speakers to PMA-A110 Connect the CD player to PMA-A110 Plug the power cord into a power outlet Batteries Begin CD playback Listen to computer audio via USB-DAC...
- Page 5 Connect the speakers to PMA-A110 Connecting the speaker cables Peel off about 3/8 inch (10 mm) of sheathing from the tip of the speaker cable, then either twist the core wire tightly or apply solder to it. Turn the speaker terminal counterclockwise to loosen it.
- Page 6 Connect the CD player to PMA-A110 Your CD player AUDIO...
-
Page 7: Plug The Power Cord Into A Power Outlet
Plug the power cord into a power outlet Connect to household power outlet (AC 120 V, 60 Hz) Power cord (supplied) - Page 8 Begin CD playback Press the power operation button. Play the CD player. Turn VOLUME on the main unit to adjust the volume to the lowest level before turning on the power. Set the input source to “CD”. Adjust the volume. “CD”...
- Page 9 Unzip the downloaded fi le, and double-click the exe fi le. Please see the FAQ at www.denon.com if you experience any issues getting audio to play from your computer through the PMA-A110. You may also want to check the support pages for audio player application.
- Page 10 Connect to PC or Mac Listen to audio from PC or Mac Power on. Type A Computer on which Press INPUT SELECT to switch the the driver software input source to “USB-DAC”. and audio player software are installed USB 2.0 cable Set the audio signal destination to this unit on the computer.
- Page 11 • It is recommended that “2 channel, 32 bit, 192000 Hz (Studio Select “PMA-A110” and click “Properties”. Quality)” is selected. • The PMA-A110 Properties window is displayed. Click “Apply”. Click “Test”. • Check that audio from this unit is output from the PC.
- Page 12 • The “Audio Devices” window is displayed. Check that “Use this device for sound output” is checked in “PMA-A110”. • If a diff erent device is checked, select and “Secondary click” on “PMA-A110”, and then select “Use this device for sound output”. PMA-A110 PMA-A110...
- Page 13 JRiver Media Center or Audirvana. Online Manual NOTE Additional settings to output audio to the PMA-A110 may have to be selected in your advanced audio player application. Please refer to the user’s manual for your application. • For more information, visit www.denon.com...
- Page 14 Printed in Japan 5411 11853 00AD © 2020 Sound United. All Rights Reserved.
