- Page 1 INSTRUCTION MANUAL 10L Evaporative Cooler Model: DCEVP10 For domestic household use only.
- Page 2 IMPORTANT THESE INSTRUCTIONS SHOULD BE READ CAREFULLY AND RETAINED FOR FUTURE REFERENCE. Note also the information presented on the appliance CAUTION: FAILURE TO FOLLOW THESE INSTRUCTIONS MAY CAUSE INJURY AND/ OR DAMAGE AND MAY INVALIDATE YOUR WARRANTY Please read the operating instructions carefully before using your evaporative cooler for the first time and keep them in a safe place.
- Page 3 • Never use the mains lead as a carrying strap or pulling lead. • To avoid a fire or electrocution hazard, NEVER put the cord near heat registers, radiator, stoves or heaters. • DO NOT cover cord with carpeting, throw rugs, runners, or similar coverings.
- Page 4 Exposed to the Near water If the power cable weather outdoors wires are frayed or cut Where small children If an extension Where the power may be left unattended lead may become cable may be overloaded damaged On a slope or Where there is risk Where it may be uneven surface...
-
Page 5: Specification
Specification Model no. DCEVP10 Colour White/Black Power supply 220-240V~, 50Hz Rated power Speed settings Modes 3 (natural, normal & sleep) Turbo air speed 8m/s Water tank capacity Remote control Timer 0-15 hours Swing function Y - Auto Controls Button with LED display Max. - Page 6 Parts Display panel Control panel Horizontal louvers Filter Water tank fill opening Water Tank Castors OSC. TIMER PRESET MODE HUM. Remote Ice pack x 2...
-
Page 7: Display And Control Panel
Display & Control Panel Normal Remote Control Fan Speed Increase On/Off Left/right swing Timer TIMER OSC. PRESET Fan Speed Decrease Mode Humidfy MODE HUM. - Page 8 Functions Note: The buzzer will make a long sound when the power supply is first connected and the indicators will flash for 2s. The unit is in ‘standby’ until the ON/ OFF button is pressed. ON/OFF After connecting the cord to a power outlet press the ON/OFF button to turn the unit ON.
- Page 9 Functions HUMIDIFY To activate the HUMIDIFY function, press the HUMIDIFY button once to turn on. Ensure there is enough water in the water tank. The LED indicator light will illuminate once activated. Press this button again to turn off the HUMIDIFY function, and to use as a fan only.
- Page 10 Set Up IMPORTANT: Never remove the water tank or open the cover when the unit is ON and operating! ICE PACKS The unit comes with 2 x ice packs. Ice packs are used to increase the cooling capacity. Please place the ice packs in the freezer before use. It takes about 4 hours to freeze completely - depending on the freezer.
-
Page 11: Operation
Operation 1. Remove the unit from its packaging 2. To begin using the HUMIDFY function, ensure the water tank is filled with water by checking the water level window indicator. 3. For extra cooling power, place the ice pack (supplied) into the unit as described on page 10.. - Page 12 Cleaning Your unit is designed to remove dirt and other atmospheric impurities by drawing air through the air filter. DO NOT block the air filter, as this will impair the efficiency of the unit. Pushing the unit up against a wall or operating it in close proximity to long window drapes will also impair the unit’s air flow and efficiency.
-
Page 13: Maintenance
Warranty Please refer to the warranty card in the box for warranty information. For any troubleshooting advice, please contact the relative Customer Care Centre below. Glen Dimplex Australia Pty Ltd Glen Dimplex New Zealand Ltd 1340 Ferntree Gully Road, 38 Harris Road, East Tamaki,... - Page 14 Supplied by Glen Dimplex Australia 1340 Ferntree Gully Road, Scoresby, Victoria, 3179 © Glen Dimplex Australia. All rights reserved. Material contained in this publication may not be reproduced in whole or in part, without prior permission in writing of Glen Dimplex Australia.
