PCI2303
User's Manual
Beijing ART Technology Development Co., Ltd.

Advertisement

Table of Contents
loading

Summary of Contents for Art PCI2303

  • Page 1 PCI2303 User’s Manual Beijing ART Technology Development Co., Ltd.

  • Page 2: Table Of Contents

    Chapter 4 Address Assignment............................8 Chapter 5 Notes and Warranty Policy..........................9 5.1 Notes ..................................9 5.2 Warranty Policy ..............................9 Products Rapid Installation and Self-check........................10 Rapid Installation ..............................10 Self-check................................. 10 Delete Wrong Installation............................10 BUY ONLINE at art-control.com/englishs or CALL 64861583(CN)

  • Page 3: Chapter 1 Overview

    PCI2303 Data Acquisition Chapter 1 Overview ART PCI2303 is based on PCI bus. It can be directly inserted into IBM-PC/AT or a computer which is compatible with PCI2303. PCI2303 is a PCI bus, 4-channel isolated high-speed 16-bit universal D / A conversion board, which provides 4-channel voltage output or current output.

  • Page 4: Chapter 2 Components Layout Diagram And A Brief Description

    CN1: analog signal output connector 2.2 Jumper Output range selected. XF15 XF16 Channel 0 XF13 XF14 XF10 Channel 1 XF19 XF20 XF11 Channel 2 XF17 XF18 XF12 Channel 3 0~5V 0~10V ±5V(default) ±10V 0~10mA 4~20mA BUY ONLINE at art-control.com/englishs or CALL 64861583(CN)

  • Page 5: Potentiometer

    RP4: channel 1 analog output gain adjustment potentiometer RP5: channel 2 analog output zero-point adjustment potentiometer RP6: channel 2 analog output gain adjustment potentiometer RP7: channel 3 analog output zero-point adjustment potentiometer RP8: channel 3 analog output gain adjustment potentiometer BUY ONLINE at art-control.com/englishs or CALL 64861583(CN)

  • Page 6: Chapter 3 Signal Connectors

    VEE0~VEE2: External power supply input AGND: Analog ground. VDD: Internal +16V power supply, external user max can use 100mA. VSS: Internal -15V power supply, external user max can use 100mA. 3.2 Voltage Output BUY ONLINE at art-control.com/englishs or CALL 64861583(CN)

  • Page 7: Current Output

    VOUT is D/A’s voltage output, RS=250Ωor 125Ω. RL≤1KΩ. When RL<400Ω (4~20mA range) or RL<800Ω (0~10mA range), internal VDD power supply can be used. Connect the second and the third pin of XF21, the output voltage is 0V when power-on. BUY ONLINE at art-control.com/englishs or CALL 64861583(CN)

  • Page 8: Chapter 4 Address Assignment

    Output enabled： 1: Off, all the voltage output is h igh resistance (>1M)(default) 0: On, outputs are normal “Read” data format when offset address is 4: D32~D1 Invalid Read back output enabled status BUY ONLINE at art-control.com/englishs or CALL 64861583(CN)

  • Page 9: Chapter 5 Notes And Warranty Policy

    ART, we will provide good after-sale service and solve the problem as quickly as we can. When using PCI2303, in order to prevent the IC (chip) from electrostatic harm, please do not touch IC (chip) in the front panel of PCI2303 module.

  • Page 10: Products Rapid Installation And Self-Check

    At this moment, there should be installation information of the installed device in the Device Manager (when the device does not work, you can check this item.). Open "Start -> Programs -> ART Demonstration Monitoring and Control System -> Corresponding Board -> Advanced Testing Presentation System", the program is a standard testing procedure.
