Westinghouse NB-14w2 User Manual

Westinghouse NB-14w2 User Manual

Notebook computer
Hide thumbs Also See for NB-14w2:
Table of Contents

Advertisement

Quick Links

USER'S MANUAL
MANUAL DEL USUARIO
NB-14w2
Notebook Computer

Advertisement

Table of Contents
loading

Related Manuals for Westinghouse NB-14w2

Summary of Contents for Westinghouse NB-14w2

  • Page 1 USER’S MANUAL MANUAL DEL USUARIO NB-14w2 Notebook Computer...
  • Page 2 i -1...
  • Page 3 Notice The information in this user’s manual is subject to change without notice. THE MANUFACTURER OR RESELLER SHALL NOT BE LIABLE FOR ERRORS OR OMISSIONS CONTAINED IN THIS MANUAL AND SHALL NOT BE LIABLE FOR ANY CONSEQUENTIAL DAMAGES, WHICH MAY RESULT FROM THE PERFORMANCE OR USE OF THIS MANUAL.

  • Page 4: Table Of Contents

    TABLE OF CONTENTS PREFACE Symbols and Conventions Protecting Your Computer - Avoid Abusive Handling and Adverse Environment Chapter Summaries GETTING TO KNOW THE BASICS Performance Features (1-2,3) System at a Glance (1-4) Top View (1-4,5) Front View (1-6) Side Views (1-7,8,9) Bottom View (1-10,11) AC Adapter (1-12) LED Status Indicators (1-13)
  • Page 5 BIOS Action Keys (2-3) Modifying the BIOS Settings (2-4) Main Setup (2-4) Info Setup (2-4) Advance Setup (2-5) Security Setup (2-5,6) Power Setup (2-6) Boot Setup (2-7) Exit Setup (2-8) BATTERY POWER & POWER MANAGEMENT The Battery Pack (3-2) Lithium-Ion Battery Technology (3-2) Battery Low-Power Warning (3-3) Installing and Removing the Battery Pack (3-4,5) Charging the Battery and Charging Time (3-5)
  • Page 6 Performance Problems (4-14) Firewire (IEEE1394) and USB2.0 Problems (4-15) Additional Questions (4-16) APPENDIX A Product Specification APPENDIX B Agency Regulatory Notices i -5...

  • Page 7: Using This Manual

    Preface Using This Manual This User’s Manual contains general information about the hardware and software setup, troubleshooting, and technical specifications of the notebook computer. Symbols and Conventions The following conventions and symbols are used in this manual: When keys are to be pressed at the same time, a plus (+) symbol is used.
  • Page 8 Protecting Your Computer - Avoid Abusive Handling and Adverse Environment Follow the advice below will help ensure that you get the most out of your Investment. Your computer will serve you well if you take good care of it. Do not expose the computer to direct sunlight or place it near sources of heat.
  • Page 9 Keep the adapter away from children. The total ampere ratings of the equipment plugged in should not exceed the ampere rating of the cord if you are using an extension cord. The total current rating of all equipment plugged into a single wall outlet should not exceed the fuse rating.

  • Page 10: Chapter Summaries

    Chapter Summaries The following is a summary of the available chapters and appendices in this manual. Chapter 1: Getting to Know the Basics In this chapter, you will learn the basic operations and features of your computer. It gives you a general understanding of the components of your computer.

  • Page 11: Getting To Know The Basics

    ■ Chapter 1 Getting To Know The Basics ▼ GETTING TO KNOW THE BASICS This chapter introduces the features and components of the computer.

  • Page 12: Performance Features

    ■ Chapter 1 Getting To Know The Basics Performance Features High Performance Processor with ATI Radeon Xpress 200M Chipset The notebook PC is equipped with a powerful Mobile Intel Celeron M processor. Together with the ATI chipset and integrated graphic technologies, the system offers very advanced PC performances.
  • Page 13 ■ Chapter 1 Getting To Know The Basics Firewire (IEEE1394 / 1394a) and USB2.0 ports In addition to a full array of built-in I/O por s, the computer offers IEEE1394 for ultra high-speed connection to high bandwidth digital video devices and USB2.0 ports to connect to any USB-based peripheral devices.

  • Page 14: System At A Glance

    ■ Chapter 1 Getting To Know The Basics System At A Glance Top View 1. LCD Display The panel is where the system content is displayed. 2. LED Status Indicator The LED Status indicators reveal the status of the system power state, battery-charging state, Instant-On/Suspend state, and the WLAN switch enabling and disabling.
  • Page 15 ■ Chapter 1 Getting To Know The Basics 3. Keyboard The keyboard is used to enter data. (See Keyboard Section for details.) 4. Touch Pad The touch pad is a built-in pointing device with functions similar to a mouse. 5. Built-in Microphone The built-in microphone records sound.

  • Page 16: Front View

    ■ Chapter 1 Getting To Know The Basics Front View Warning: Do not place any heavy objects on the top of notebook. This may damage the display 1. Wireless On/Off Switch Use the Switch to disable or enable the Wireless function. When Wireless LAN function is enabled, the indicator shows steady blue light.

  • Page 17: Side Views

    ■ Chapter 1 Getting To Know The Basics Side Views Warning: Do not place any heavy objects on the top of notebook. This may damage the display 1. Optical Drive and Disk Eject Button and Manual Eject Key Hole If your computer comes with the Combo drive, DVD-Dual, or Super-Multi drive, you may save data onto a CD-R / CD-RW or DVD RW disc.
  • Page 18 ■ Chapter 1 Getting To Know The Basics 4. Modem Port This is where you plug the phone jack (RJ-11) for fax/modem functions. 5. Kensington Lock Key Hole A Kensington-type security lock latches to this keyhole for anti-theft purpose. 6. USB2.0 Port (x3) The Universal Serial Bus (USB2.0-compliant) port allows you to connect a wide variety of devices to your computer at a rate of up to 480 Mbps.
  • Page 19 ■ Chapter 1 Getting To Know The Basics 12. Ethernet / LAN Port The port connects to a network hub via the RJ-45 cable and also conforms to 10/100Base-TX transmission protocol. 13. Ventilation Grill The fan grill is where air is exchanged to dissipate the internal heat.

  • Page 20: Bottom View

    ■ Chapter 1 Getting To Know The Basics Bottom View 1. Battery Pack and Battery Latch The battery pack is a built-in power source for the notebook. Slide the battery latch to release the battery pack. 2. Ventilation Grill The fan grill is where air is exchanged to dissipate the internal heat.
  • Page 21 ■ Chapter 1 Getting To Know The Basics Warning: Do not block the Fan Grill outlet. Place the machine on hard surface only. The bottom case may get very hot. 3. System Device Cover The system’s processor with cooler assembly, Wireless LAN module, HDD, and DDR memory module are located under the case cover.

  • Page 22: Ac Adapter

    ■ Chapter 1 Getting To Know The Basics AC Adapter DC-out Connector The DC-out connector docks to the power jack (DC-in) on the computer. 2. Adapter The adapter converts alternating current into constant DC voltage for the computer. 3. AC Plug The AC plug connects to the AC wall outlet.

  • Page 23: Led Status Indicators

    ■ Chapter 1 Getting To Know The Basics LED Status Indicator The LED Status Indicator displays the operating status of your notebook. When a certain function is enabled, an LED will light up. The following section describes its indication. System & Power Status Indicators LED Graphic Indication Symbol...

  • Page 24: Osd Status Indicators

    ■ Chapter 1 Getting To Know The Basics OSD Status Indicator The On-screen Status Display Indicator displays the operating status of your notebook. When a certain function is enabled, the symbol will show up on windows. The following section describes its indication. OSD Status Indicators Action Fn + F3: Audio Mute...

  • Page 25: Keyboard Features

    ■ Chapter 1 Getting To Know The Basics Keyboard Features Function Keys (Quick Keys) Graphic Action Symbol Fn + F1 Fn + F3 Fn + F4 Fn + F5 Fn + F6 Fn + F7 Fn + F8 Fn+Num Lk Enables the embedded keypad Caps Lock Fn + Scr Lk Press the Fn+Scr Lk key and System Control...

  • Page 26: Windows Keys

    ■ Chapter 1 Getting To Know The Basics Windows Keys Your keyboard also has two Windows keys: 1. Start Key This key allows you to pull up the Windows Start Menu at the bottom of the taskbar. 2. Application Menu Key This key brings up the popup menu for the application, similar to a click of the right mouse button.

  • Page 27: Touch Pad

    ■ Chapter 1 Getting To Know The Basics Touch Pad The built-in touch pad, which is a PS/2-compatible pointing device, senses movement on its surface. As you move your fingertip on the surface of the pad, the cursor responds accordingly. The following items teach you how to use the touch pad: 1.

  • Page 28: Graphic Subsystem

    ■ Chapter 1 Getting To Know The Basics Graphic Subsystem Your computer uses a high performance 14.1-inch active matrix TFT panel with high resolution and multi-million colors for comfortable viewing. The ATI Radeon Xpress 200M integrated video graphics accelerator, which is Microsoft DirectX 9 compatible, performs graphic rendering at a lighting-fast speed.

  • Page 29: Opening And Closing The Display Panel

    ■ Chapter 1 Getting To Know The Basics Opening and Closing the Display Panel To open the display, lift up the lid. Then tilt it to a comfortable viewing position. The LCD panel has a maximum opening of 135 degrees. Do not push it down forcibly. To close the display cover, fold it down gently.

  • Page 30: Audio Subsystem

    ■ Chapter 1 Getting To Know The Basics Audio Subsystem Your computer’s audio subsystem is Sound Blaster Pro-compatible. Adjusting the Volume Manually To increase the volume, press Fn+F5. To decrease the volume, press Fn+F6. Adjusting the Audio Volume in Windows 1.
  • Page 31 ■ Chapter 1 Getting To Know The Basics Modem Your computer comes with a 56K V.92 internal fax/modem and a phone jack (RJ-11), which is located on the left side of your computer. Use a telephone cable to connect the computer to the telephone wall outlet.
  • Page 32 ■ Chapter 1 Getting To Know The Basics 2. Click on the pull-down menu and select the country where it is applicable. Click on OK to exit. 1-22...
  • Page 33 ■ Chapter 1 Getting To Know The Basics Ethernet Your computer is equipped with a 10/100Base-TX Fast Ethernet network adapter. Connect the active LAN cable to the RJ-45 LAN port located on the left side of the computer. This allows you to access and transmit data in the local area network.

  • Page 34: Bios Setup And Security Feature

    ■ Chapter 2 Bios Setup and Security Feature ▼ BIOS SETUP AND SECURITY FEATURE In this chapter, you will learn how to enter the BIOS Setup Menu and manipulate various hardware control settings. You will also learn how to use the built-in security features.
  • Page 35 ■ Chapter 2 Bios Setup and Security Feature Setup Utility is a hardware configuration program built into your computer’s BIOS (Basic Input/Output System). It runs and maintains a variety of hardware functions. It is a menu-driven software, which allows you to easily configure and change the settings.

  • Page 36: Entering The Bios Setup Screen

    ■ Chapter 2 Bios Setup and Security Feature Entering the BIOS Setup Screen First turn on the power. When the BIOS performs the POST (Power-On Self Test), press F2 key quickly to activate the Pheonix BIOS Setup Utility. Note: You may need to press F2 key fairly quickly. Once the system begins to load Windows, you may have to retry by cycle-power on again Leaving the BIOS Setup Screen When you have finished modifying the BIOS settings, exit the BIOS.

  • Page 37: Modifying The Bios Settings

    ■ Chapter 2 Bios Setup and Security Feature Modifying the BIOS Settings The Phoenix BIOS setup main menu is subdivided into sub-menus. Each menu item is described in this section. Main Setup Under this menu, you may change time/date and view basic processor and system memory information.

  • Page 38: Advanced Setup

    ■ Chapter 2 Bios Setup and Security Feature Advanced Setup Item Selections / Description Sub-menu When enabled, this unique feature Execute Disabled protects against certain type of virus that Disable Bit Enabled creates Buffer Overflow problem in the memory subsystem. When Disabled, the system will display Quiet Boot Disabled OEM logo instead of the POST...

  • Page 39: Power Setup

    ■ Chapter 2 Bios Setup and Security Feature provides both a Supervisor and a User password. If you try to activate both passwords, the Supervisor password must be set first. The passwords activate two different levels of protection: 1. System always asks for password every time it is powered on. 2.

  • Page 40: Boot Setup

    ■ Chapter 2 Bios Setup and Security Feature Boot Setup ►Boot Settings Configuration Item Selections / Description Sub-menu When enabled, the system can support Disabled remote wake-up or boot on LAN. Remote Enabled Boot ►Boot Device Priority Item Selections / Description Sub-menu USB Key...

  • Page 41: Exit Setup

    ■ Chapter 2 Bios Setup and Security Feature Exit Setup Item Selections / Description Sub-menu Saves After you have completed the BIOS Changes and settings, select this item to save all Exit settings, exit BIOS Setup utility, and reboot. New system settings will take effect on next power-up.
  • Page 42 ■ Chapter 3 Battery Power & Power Management C H A P T E R ▼ T H R E E BATTERY POWER & POWER MANAGEMENT In this chapter, you will learn the fundamentals of power management and how to use it to achieve longer battery life.

  • Page 43: The Battery Pack

    ■ Chapter 3 Battery Power & Power Management this chapter, you will learn how to operate your notebook on battery power, how to handle and maintain the battery pack, and learn about the system’s power saving features. TFT display, central processor, hard disk drive are the major hardware subsystems that consume the most power.

  • Page 44: Battery Low-Power Warning

    ■ Chapter 3 Battery Power & Power Management Battery Low-Power Warning Low Battery Warning Low battery condition occurs when battery power is reduced to 6%. The green battery status LED indicator blinks and the system beeps once every 16 seconds or so. Very Low Battery Warning Very Low battery condition occurs at 3 % power remaining.

  • Page 45: Installing And Removing The Battery Pack

    ■ Chapter 3 Battery Power & Power Management Installing and Removing the Battery Pack To Remove the Battery Pack: Place the notebook bottom-side up on a flat and secured surface. Push the latch and pull the battery’s hard case away from the notebook.

  • Page 46: To Install The Battery Pack

    ■ Chapter 3 Battery Power & Power Management To Install the Battery Pack: Place the notebook bottom-side up on a flat and secured surface. Carefully insert the battery pack into the battery compartment of the notebook. Charging the Battery and Charging Time To charge the battery, while the battery pack is in the notebook, plug the AC adapter into the notebook and an electrical outlet.

  • Page 47: Checking The Battery Level

    ■ Chapter 3 Battery Power & Power Management Checking the Battery Level You can check the remaining battery power in the Windows battery status indicator, which is located at the lower right-hand corner of the task bar. (If you do not see a battery or AC-in icon on the task tray, go to Power Options Properties box and click on the Advanced tab.

  • Page 48: Using Windows Power Options

    ■ Chapter 3 Battery Power & Power Management Using Windows Power Options Windows Power Management provides basic power saving features. In the Windows Power Options Properties [Start > Settings > Control Panel > Power Options] dialogue box, you may enter time-out values for display and hard disk drive. Windows power manager saves power by turning off hard drive after 1 minute of inactivity, for example.
  • Page 49 ■ Chapter 3 Battery Power & Power Management In this dialog box, you can manually set the LCD and hard drive’s time-out values in the Plugged in column and in the Running on batteries column. Lower time-out values will save more battery power. Note: Also consult Windows user guide for more information on how to use Windows power management functions.

  • Page 50: Suspend Mode

    ■ Chapter 3 Battery Power & Power Management Suspend Mode Standby Suspend The system automatically enters this mode after a period of inactivity, which is set in the Power Schemes dialog box. In Standby mode, hardware devices, such as display panel and hard disk, are turned off to conserve energy.
  • Page 51 ■ Chapter 3 Battery Power & Power Management Note: Do not install or remove the memory module when the system is in the suspend mode. Note: Actual dialogue box shown above may appear slightly different. 3-10...

  • Page 52: Power Button Action

    ■ Chapter 3 Battery Power & Power Management Power Button Action The notebook PC’s power button can be set to turn off the system or activate the suspend mode. Go to [Start > Settings > Control Panel > Power Options] and click on the Advanced tab.

  • Page 53: Low Battery Warning

    ■ Chapter 3 Battery Power & Power Management Low Battery Warning You can define when and how the system warns you of its battery-low condition. Go to the Alarms tab in the Power Options Properties box. If you wish to hear audible beeps, click on the Alarm Action button and put a check on Sound Alarm.

  • Page 54: Power Manual Quick Access

    ■ Chapter 3 Battery Power & Power Management Power Menu Quick Access Instead of making specific selections in the Power Options Properties box, you can quickly and easily specify which pre-set power saving function you desire by clicking on the Battery icon at the lower right-hand corner of the task bar.

  • Page 55: Troubleshooting

    ■ Chapter 4 Troubleshooting C H A P T E R ▼ F O U R TROUBLESHOOTING In this chapter, you will learn how to solve common hardware and software problems.
  • Page 56 ■ Chapter 4 Troubleshooting Your computer has been fully tested and complies with the system specifications before shipping. However, incorrect operations and/or mishandling may cause problems. This chapter provides a reference for identifying and correcting common hardware and software problems that you may encounter. When you encounter a problem, you should first try to go through the recommendations in this chapter.
  • Page 57 ■ Chapter 4 Troubleshooting changes you made, try to restore all the settings to factory defaults. Be sure all the device drivers are installed properly. For example, without the audio driver properly installed, the speakers and microphone will not work. If external devices such as USB camera, scanner, and printer do not function correctly when connected to the system, it is usually the device’s own problem.

  • Page 58: Audio Problems

    ■ Chapter 4 Troubleshooting Audio Problems No speaker output - Software volume control is turned down in Microsoft Sound System or is muted. Double-click the speaker icon on the lower right corner of the taskbar to see if the speaker has been muted or turned down all the way. Most audio problems are software-related.

  • Page 59: Hard Disk Problems

    ■ Chapter 4 Troubleshooting Hard Disk Problems The hard disk drive does not work or is not recognizable - The new HDD may need to be partitioned and reformatted. O/S and drivers will need to be re-installed as well. Check the hard disk indicator LED. When you access a file, the LED lamp should light up momentarily.
  • Page 60 ■ Chapter 4 Troubleshooting The hard disk takes longer to read a file - If you have been using the drive for a period, the files may be fragmented. Go to [Start > Programs > Accessories > System Tools > Disk Defragmenter] to perform a disk defragmentation.

  • Page 61: Optical Drive Problems

    ■ Chapter 4 Troubleshooting Optical Drive Problems The optical drive does not work - Try rebooting the system. The disk is damaged or files are not readable. After you have inserted a CD-ROM disk, it may take a moment before you can access its content. The drive dose not read any disks - The CD may not be properly seated in the tray.

  • Page 62: Display Problems

    ■ Chapter 4 Troubleshooting Display Problems The display panel is blank when the system is turned on - Make sure the computer is not in the Standby or Hibernate suspend modes. The display is turned off to conserve energy in these modes. The screen is difficult to read - The display resolution should at least be set to at least1024x768 for optimal viewing.

  • Page 63: Keyboard And Mouse Problems

    ■ Chapter 4 Troubleshooting Keyboard and Mouse Problems The built-in touch pad performs erratically Make sure there is no excess perspiration or humidity on your hand when using the touch pad. Keep the surface of the touch pad clean and dry. Do not rest your palm or wrist on the surface of the touch pad while typing or using the touch pad.

  • Page 64: Cmos Battery Problem

    ■ Chapter 4 Troubleshooting CMOS Battery Problem A message “CMOS Checksum Failure” displays during the booting process or the time (clock) resets when booting - Try to reboot the system. If the message “CMOS Checksum Failure” appears during the booting procedure even after rebooting, it may indicate failure of the CMOS battery.

  • Page 65: Memory Problems

    ■ Chapter 4 Troubleshooting Memory Problems The POST does not show an increased memory capacity when you have already installed additional memory - Certain brands of memory module may not be compatible with your system. You should ask your vendor for a list of compatible DIMM.

  • Page 66: Modem Problems

    ■ Chapter 4 Troubleshooting Modem Problems The built-in modem does not respond - Make sure the modem driver is loaded properly. Go to [Start > Settings > Control Panel > Phone and Modem Options] and go to Modems tab. Make sure Motorola SM56 Data Fax Modem is listed.

  • Page 67: Network Adapter / Ethernet Problems

    ■ Chapter 4 Troubleshooting Network Adapter / Ethernet Problems The Ethernet adapter does not work - Go to [Start > Settings > Control Panel > System > Hardware > Device Manager]. Double-click on Network Adapters and check if Realtek RTL8139/810x Family Fast Ethernet NIC appears as one of the adapters.

  • Page 68: Performance Problems

    ■ Chapter 4 Troubleshooting Performance Problems The computer becomes hot - In a 35 C environment, the certain areas of the computer’s back case are expected to reach 50 degrees. Make sure the air vents are not blocked. If the fan does not seem to be working at high temperature (50 degrees Celsius and up), contact the service center.

  • Page 69: Firewire (Ieee1394) And Usb2.0 Problems

    ■ Chapter 4 Troubleshooting Firewire (IEEE1394) and USB2.0 Problems The USB device does not work - Windows NT 4.0 does not support USB protocols Check the settings in the Windows Control Panel. Make sure you have installed the necessary device drivers.

  • Page 70: Additional Questions

    ■ Chapter 4 Troubleshooting Additional Questions See our website at www.westinghousedigital.com. Contact Westinghouse Digital Customer Service at (866) 287-5555 or write us service@westinghousedigital.com. 4-16...

  • Page 71: Product Specification

    ■ Appendix A Product Specification ▼ PRODUCT SPECIFICATION...

  • Page 72: System Memory

    ■ Appendix A Product Specification Processor and Core Logic ▼ Processor Mobile Intel Celeron M Processor (Yonah), up to 1.73GHz, 1MB L2 cache Core Logic ATI RC410MD + ATI SB460 chipset with graphic, audio, modem, and USB2.0 controllers integrated 533MHz Front Side Bus 533 / 667MHz DDR2 interface System Memory ▼...

  • Page 73: Wireless Lan

    ■ Appendix A Product Specification Audio ▼ Chipset ATI SB460 integrated audio controller Audio Codec Realtek Audio Codec Sound DirectSound 3D, EAX 1.0 & 2.0 compatible Capabilities A3D, I3DL2 compatible AC97 V2.3 compatible Azalia compatible 2 Stereo Speakers Modem ▼ Chipset ATI SB460 integrated Modem Controller with MDC card, support 56K MDC Modem Card with Azalia...
  • Page 74 ■ Appendix A Product Specification LAN / Ethernet ▼ Chipset Realtak RTL8100CL Ethernet function for 10/100Base-TX network standards PnP Function Windows XP Plug and Play compatible Flow Control Automatic Jam and auto-negotiation for flow control Speed Auto Negotiation and Parallel detection for automatic Selection speed selection (IEEE 802.3u) Other...

  • Page 75: Card Reader

    ■ Appendix A Product Specification Keyboard & Touch pad ▼ Keyboard 86/87-key QWERTY keyboard with numeric keypad and Windows keys, 19.05mm Pitch Touch pad Built-in Touch Pad ExpressCard (NewCard) & Multiple ▼ Card Reader Chipset 02 Micro 0Z128 (Card Reader) Express Card / Single Slot, 34mm type I supported New Card...

  • Page 76: Operating System

    ■ Appendix A Product Specification Battery Pack / AC Adapter ▼ Primary Li-ion 6-Cell pack, 10.8V / 11.1V x 4000 mAH or Battery Pack Li-ion 6-Cell pack, 10.8V / 11.1V x 4400 mAH or Li-ion 6-Cell pack, 10.8V / 11.1V x 4800 mAH Low battery state with low battery warning beep Feature Uniwill SmartPower III Power Management...
  • Page 77 ■ Appendix A Product Specification Physical Specification ▼ Dimension 332 (W) x 232 (D) x 23.5~33.8 (H) mm Weight 2.4KG / 5.28lbs (with 14.1” LCD, DVD-ROM Drive and 6-cell battery pack) Environmental Operating Temperature: 5 to 35 Limits Operating Humidity: 20 to 80 percent RH (5 to 35 Storage Temperature: -15 to 50 C (41 to 95 C (-5 to 122...

  • Page 78: Agency Regulatory Notices

    ■ Appendix B Agency Regulatory Notices ▼ AGENCY REGULATORY NOTICES...
  • Page 79 ■ Appendix B Agency Regulatory Notices Federal Communications Commission Notice This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
  • Page 80 ■ Appendix B Agency Regulatory Notices EN55022 : 1998+A1: 2000+A2: 2003, CLASS B EN61000-3-2 : 2000 EN61000-3-3 : 1995+A1: 2001 EN55024 : 1998+A1 : 2001+A1: 2003 IEC61000-4-2: 2001 IEC61000-4-3:2002+A1:2002 IEC61000-4-4:1995+A1:2000+A2:2001 IEC61000-4-5:2001 IEC61000-4-6:2001 IEC61000-4-8:2001 IEC61000-4-11:2001 EN50082 (IEC801-2, IEC801-3, IEC801-4) Electro-magnetic Immunity EN 300 328-2, EN 300 328-1, EN 301 489-1, EN 301 489-17 (ETSI 300 328, ETSI 301 489) Electro-magnetic Compatibility and Radio Spectrum Matter.
  • Page 81 ■ Appendix B Agency Regulatory Notices Attachment Limitations Statement ''Notice: This equipment meets telecommunications network protective, operational and safety requirements as prescribed in the appropriate Terminal Equipment Technical Requirements document(s). This is confirmed by marking the equipment with the Industry Canada certification number.
  • Page 82 ■ Appendix B Agency Regulatory Notices The cord set must have a rated current capacity of at least 10 A. The attachment plug must be an earth-grounding type with a NEMA 5-15P (15A, 125V) or NEMA 6-15P (15 A, 250V) configuration. Japan All components of the cord set (cord, connector, and plug) must bear a `PSE` mark and registration number in accordance with the...
  • Page 83 The cord set must have a current capacity of at least 10 A and a nominal voltage rating of 125 / 250 VAC. CAUTION: MODEL NB-14w2 IS DESIGNED TO USE WITH THE FOLLOWING AC ADAPTER MODEL ONLY Manufacture: LITE-ON ELECTRONICS, INC Model: P PA-1650-02 (65W), PA-1650-01 (65W) Manufacture: LI SHIN INTERNATIONAL ENTERPRISE CORP.
  • Page 84 ■ Appendix B Agency Regulatory Notices only with same or equivalent type recommended by the manufacturer. Discard used batteries according to the manufacturer’s instructions or local laws. VORSICHT! Explisionsgefahr bei unsachgernazen Austausch der Batterie. Ersatz nur durch denselben oder einem vom Hersteller empfohlenem ahnlichen Typ.
  • Page 85 ■ Appendix B Agency Regulatory Notices Discard used batteries according to the manufacturer’s instructions. ATTENTION: Il y a danger d’xplosion s’il y a remplacement incorrect de la batterie. Remplacer uniquement avcc unc batterie du meme type ou d’un type recommande par le constructer. Mettre au rebut les batteries usagees conformement aux instructions du fabricant.
  • Page 86 Westinghouse Digital Electronics SE-UM-1401-0601 Santa Fe Springs, CA...
