Summary of Contents for Sanyo LMU-TK29C1
- Page 1 Industrial LCD Monitor LMU-TK29C1 User's Guide...
-
Page 2: Table Of Contents
Table of contents Precautions Precautions ....................2 Placement precautions • Avoid placing the unit in humid or dusty places, or where it will be exposed Before First Use to excessive heat (direct sunlight, heaters, etc.) Names and Functions................3-4 • Do not step on or set anything on the AC power cord. DAMAGE TO THE Check Accessories ................. -
Page 3: Before First Use
Before First Use Names and Functions Front View Rear View Display Screen R/Cr B/Cb BNC Connector HD/C SYNC AC-OUT Ventilators OSD Switch OSD is displayed vertically(PORTRAIT) or horizontally (LANDSCAPE). NOTE Ventilators ¡ When you move the LCD monitor, please unplug AC cables connected to AC-IN AC-IN and/or AC-OUT, and disconnect the cables connected to the external equipments. -
Page 4: Outer Dimension
Before First Use Outer Dimension 8-M5 (Depth: Min.12mm/Max.20mm) Mounting Area Mounting Area Ventilators R/Cr Ventilators POWER B/Cb HD/CSYNC AC-OUT AC-IN Ventilators OSD SW Ventilators When you install the LCD Monitor, please BRIGHTNESS VIDEO take care the following: S-VIDEO • Use the M6 screws only for installation. External Control •... -
Page 5: Installation
Before First Use Installation Connect the Computers Caution Before doing anything, make sure the Power Switch on the monitor and a computer are ¡Do not plug the External OSD Control Box into the computer's USB port, as this may turned off. cause malfunction of the computer. - Page 6 Before First Use Installation How to secure the monitor on a wall BNC Connector Note: The following figure is only recommended. Vertical Component Video Cable (not included) M5 bolt (8 places) S-Video R/Cr Connector B/Cb HD/C SYNC External Depth: Min. 12mm Max.
-
Page 7: Lcd Monitor Instructions
Before First Use LCD Monitor Instructions Installation Adjusting the Screen This LCD monitor decodes the signal from a computer Change PORTRAIT and LANDSCAPE automatically, and displays the image on a screen in It is possible to change a direction of OSD(On Screen Display) menu. Refer to next accordance with the preset mode. -
Page 8: Adjustment Items
LCD Monitor Instructions Adjustment Items Pip(picture in picture) Menu Adjustment Items for Composite Video, S-Video and (refer to page 24-29) Component Video screen SIZE ‥‥‥‥‥‥‥‥‥‥‥‥Select the size of pip POS ‥‥‥‥‥‥‥‥‥‥‥‥Select the position of pip Picture Menu (refer to page 37-42) SOURCE ‥‥‥‥‥‥‥‥‥‥Change the input signal BRIGHTNESS ‥‥‥‥‥‥‥‥Adjust the brightness for video screen BRIGHTNESS ‥‥‥‥‥‥‥‥Adjust the brightness of pip... -
Page 9: Adjustment Procedure
LCD Monitor Instructions Mode Adjustment Procedure You can change or indicate the signal input type following the steps. Before Adjustment Change or indicate the input signal The signal timing for a computer which this LCD monitor supports is listed in "Table of Preset Data"... -
Page 10: Adjustment For Computer Screen
LCD Monitor Instructions Adjustment for computer screen Adjustment Procedure (Picture Menu) Manual Adjustment Select the item to be adjusted on the Main Menu If you wish to adjust the screen finely or in case the result adjusted by Auto Adjust (see Select the item to be adjusted by moving the cursor on the Main menu with the page 33) sequence is not sufficient enough, adjust the screen manually. - Page 11 LCD Monitor Instructions Adjustment for computer screen Adjustment Procedure (Picture Menu) Select [contrast] on the Sub menu and press the [ENTER] button. Adjust the vertical position (Analog mode only) The selected item of [contrast] turns blue. Select [picture] on the Main menu and press the [ENTER] button. Use the [ ] and/or [ ] button to adjust.
-
Page 12: Advanced Menu
LCD Monitor Instructions Adjustment for computer screen Adjustment Procedure (Picture Menu) (Advanced Menu) Use the [ ] and/or [ ] button to adjust. Adjust the frequency (Analog mode only) When pressing the [ ] button, the scaling can be selected according to the Select [picture] on the Main menu and press the [ENTER] button. -
Page 13: Picture In Picture Menu
LCD Monitor Instructions Adjustment for computer screen Adjustment Procedure (Advanced Menu) (Pip Menu) When pressing the [ ] button, the color temperature can be selected according Press the [ENTER] button, and then press the [ ] button. to the order [Neutral] / [Cold] / [user] / [Warm] / [Neutral] in sequence. You can see the cursor moving to [user green]. - Page 14 LCD Monitor Instructions Adjustment for computer screen Adjustment Procedure (Pip Menu) Use the [ ] and/or [ ] button to select the size. Change the input signal When pressing the [ ] button, the size of pip can be selected according to Select [pip] on the Main menu and press the [ENTER] button.
- Page 15 LCD Monitor Instructions Adjustment for computer screen Adjustment Procedure (Pip Menu) size small medium large Use the [ ] and/or [ ] button to adjust. (Interval: 0~100) picture By pressing the [ ] button, the contrast (difference between bright and dark) advanced source auto...
-
Page 16: Advanced Picture In Picture Menu
LCD Monitor Instructions Adjustment for computer screen Adjustment Procedure (Pip Menu) (Adv pip Menu) D. Advanced picture in picture Menu size small medium large picture This menu can be used when inputting Composite Video or S-Video signal and also advanced source auto comp... -
Page 17: Options Menu
LCD Monitor Instructions Adjustment for computer screen Adjustment Procedure (Adv pip Menu) (Options Menu) E. Options Menu Use the [ ] and/or [ ] button to adjust. (Interval: 0~100) Press the [ ] button to shift the screen to the bottom. You can change the osd position and language used in osd, adjust the screen by Auto Adjust (Automatic Adjustment) and see the resolution at the time if you select this menu. - Page 18 LCD Monitor Instructions Adjustment for computer screen Adjustment Procedure (Options Menu) Select [language] on the Sub menu and press the [ENTER] button. Display the resolution The selected item of [language] turns blue. Select [options] on the Main menu. Display the current resolution Use the [ ] and/or [ ] button to select the language.
-
Page 19: Utilities Menu
LCD Monitor Instructions Adjustment for computer screen Adjustment Procedure (Utilities Menu) F. Utilities Menu Select [osd background] on the Sub menu and press the [ENTER] button. You can change the osd timeout and background, and also reset the osd setting if you The selected item of [osd background] turns blue. -
Page 20: Picture Menu
LCD Monitor Instructions Adjustment for Composite Video / S-Video / Component Video Adjustment Procedure (Picture Menu) A. Picture Menu Select [contrast] on the Sub menu and press the [ENTER] button. The selected item of [contrast] turns blue. The adjustment of brightness, contrast, horizontal position, vertical position, color, tint, sharpness and scaling for the picture are available. - Page 21 LCD Monitor Instructions Adjustment for Composite Video / S-Video / Component Video Adjustment Procedure (Picture Menu) Use the [ ] and/or [ ] button to adjust. (Interval: 0~100) Adjust the vertical position By pressing the [ ] button, the screen lightens. Select [picture] on the Main menu and press the [ENTER] button.
- Page 22 LCD Monitor Instructions Adjustment for Composite Video / S-Video / Component Video Adjustment Procedure (Picture Menu) Adjust the sharpness Adjust the scaling Select [advanced] on the Main menu and press the [ENTER] button. Select [picture] on the Main menu and press the [ENTER] button. You can see the cursor moving to the Sub menu.
-
Page 23: Advanced Menu
LCD Monitor Instructions Adjustment for Composite Video / S-Video / Component Video Adjustment Procedure (Advanced Menu) B. Advanced Menu Select [advanced] on the Main menu and press the [ENTER] button. You can see the cursor moving to the Sub menu. You can adjust the color temperature for the screen manually if you select this menu. -
Page 24: Video Menu
LCD Monitor Instructions Adjustment for Composite Video / S-Video / Component Video Adjustment Procedure (Video Menu) (Options Menu) C. Video Menu D. Options Menu When video signal is input, you can select the video format (NTSC/PAL/SECAM) You can select the osd position, language used in osd and display the osd version if manually. -
Page 25: Utilities Menu
LCD Monitor Instructions Adjustment for Composite Video / S-Video / Component Video Adjustment Procedure (Options Menu) Adjustment Procedure (Utilities Menu) E. Utilities Menu Select [language] on the Sub menu and press the [ENTER] button. The selected item of [language] turns blue. You can change the osd timeout and background, and also reset the osd setting if you select this menu. -
Page 26: Additional Functions
LCD Monitor Instructions Adjustment Procedure (Utilities Menu) Additional Functions Shortcut Menu Delete the data saved at the current display mode You can shortcut to adjust the brightness and contrast of the whole screen and size of Select [utilities] on the Main menu and press the [ENTER] button. picture in picture. -
Page 27: Power Management System
LCD Monitor Instructions LCD Monitor Instructions Additional Functions Power Management System Adjust the contrast Use the [ENTER] button to select [contrast] menu. This is the function to reduce the monitor's power consumption, when a computer has not been used for long, even when the power to a LCD Monitor is "ON". In order to contrast activate this system, it must be connected and used with a computer that conforms to (Ex.) -
Page 28: Maintenance
Maintenance Troubleshooting Fault Finding Always unplug the AC cable from the outlet before maintenance. Fault Finding Also unplug the signal cables from the computer. Please check the following items before requesting repair. When this LCD monitor still does not work properly after checking in following way, stop using it, turn off the power switch, unplug the power plug from the AC Outlet, and contact the store where it was purchased. -
Page 29: Screen Display
Troubleshooting Specifications Screen Display Table of Preset Data Fifteen signal timing patterns indicated in the tables below are preset when the monitor is Screen Display shipped from the factory. Up to 8 additional timing patterns can also be stored. The timing pattern is automatically determined and displayed according to the synchronous signals of •... -
Page 30: Cable Pin Arrangement
Specifications Cable Pin Arrangement Monitor Specifications Analog Video Input : mini D-Sub (15pin) Liquid Crystal Panel Signal name Signal name Signal name Display Size 29.0'' R GND –– Pixel Configuration 1,280 x 768 G GND DDC data line* Pixel Pitch 0.4935 x 0.4935 m B GND Hor. - Page 31 Class A digital device. The accessories associated with this equipment are as follows: S shielded video cable These accessories are required to be used in order to ensure compliance with FCC rules. SANYO Electric Co., Ltd. 2RS6P10A01700 Printed in Japan...
