Samsung S19A100N Service Manual page 36

Exploded Views and Parts List
Level Loc. Part Code
1 BN91-08045B
.2 PANEL BN07-01062A
1 BN91-08057A
.2 CIS1 0203-001598
.2 EC13 BN39-01476B
1 BN92-09117A
.2 T0527 BH68-00634A
.2 BH68-00658C
.2 BN69-06812A
1 BN92-09120A
.2 S.N.A 0203-001100
.2 6902-000604
.2 6902-000609
.2 AA69-00243G
.2 T0527 BH68-40364A
.2 BH69-00457A
.2 BN63-09729A
.2 BN63-09730A
.2 T0527 BN68-00129A
.2 BN69-00391P
.2 BN69-05269Y
.2 BN69-06684A
1 BN92-09142A
.2 CCM1 BN68-01570A
1 ACCE1 BN92-11134H
.2 P001A BN44-00394K
.2 SB04A BN96-16602D
..3 T0524 6902-000109
..3 BN61-07807A
..3 CCM1 BN63-02183K
..3 BN63-07682C
..3 BN67-00385E
..3 BN68-03650A
.2 SB01A BN96-18682A
..3 T0524 6902-000023
..3 BN61-07622A
...4 BN61-07367B
....5 BN61-02932E
..3 BN68-02466Z
.2 ACCE1 BN96-20384D
6
Description & Specification
ASSY LCD-ETZ;BN07-01062A,18.5
LCD-PANEL;HM185WX1-400,BB18400A,6bit Hi-
ASSY SHIELD;S19A100N
TAPE-FILAMENT;#8915,0.15,12,55000,CLR
LEAD CONNECTOR;SA300,Flat Connector Ass'
ASSY BOX;LS19A100NS/EN
LABEL BOX-00;ALL MODEL,MOJO 90G,80,75,WH
LABEL BOX-00;ALL MODEL,MOJO 90G,WHT,WIND
BOX-02,SET;S19A100,PAPER,SW,A1,YEL,W515,
ASSY P/MATERIAL;S19A100N,W/W
TAPE-OPP MASKING;OPP/W75/CLR,T0.075,W75,
BAG WRAPPING;LDPE,T0.02,W500,L10000,TRP,
BAG ROLL;LDPE,T0.05,W2400,L1000,TRP,30.0
PAD-PLATE;SP43J5,CB,990,990,YEL
LABEL-SUMMARY;G52,G72,ART,100G,WHT,BLK,W
PACKING INNER-00,PAD;COMM,CB,T3.0,1130,1
SHEET-PE/ROLL;HDPE+PE FOAM,0.3,W500,L600
SHEET-PE/ROLL;HDPE+PE FOAM,0.3,W500,L600
LABEL SHIPPING-00;LABEL SHIPPING,ART-PAP
PAD-ANGLE;CB,T4,50,2200,YEL
PALLET-WOOD;S19A314,WOOD,W1070,D1050,H12
CUSHION-SET;S19A100,EPS,EPS,T0.018,WHITE
ASSY LABEL;S19A100N,W/W
LABEL RATING;ALL,SS,PE,T0.05,90,45,Dark
ASSY ACCESSORY;SA100,ND
DC VSS(A);AD-3014B,SB350,14,2.14A,Extern
ASSY STAND P-BASE;SA10/SA100,ABS+PMMA,HB
BAG PE;HDPE,T0.015,W350,L430,TRP,28,2,4.
HOLDER-STAND;SUM24L,SWCH18A
COVER-SHEET;Rhcm,PE Vinyl,T 0.04,250MM,2
COVER-STAND BASE;SA10/SA100,ABS+PMMA,HB,
RUBBER-FOOT;RUBBER-FOOT,SILICONE,ROUND,1
LABEL-STICKER;SA10/SA100,18.5,T0.05,50,2
ASSY STAND P-BODY,SIMPLE;SA10/SA100,HIPS
BAG PE;LDPE,T0.08,W150,L120,TRP,1.650g
STAND-BAR;SA10/SA100,HIPS,BK23,ETCH
STAND-BAR IN;SA10/SA100,HIPS,BK23
BRACKET-STOPPER NUT;ECOFIT 20,M4,D8,L12,
LABEL-STICKER;SA10/SA100,T0.05,50,20,PIN
ASSY ACCESSORY;LS19A100NS/ZN
Copyright© 1995-2012 SAMSUNG. All rights reserved.
Qty. SA/SNA
1 SNA
1 SA
1 SNA
0 SNA
1 SA
1 SNA
1 SNA
1 SNA
2 SNA
1 SNA
1 SNA
2 SNA
0 SNA
1 SNA
1 SNA
1 SNA
1 SNA
1 SNA
1 SNA
1 SNA
1 SNA
1 SNA
1 SNA
1 SNA
1 SNA
1 SA
1 SA
1 SNA
1 SNA
0 SNA
1 SNA
4 SNA
1 SNA
1 SA
1 SNA
1 SNA
1 SNA
1 SNA
1 SNA
1 SNA
