Chamberlain UL 325 Safety Check Instruction

Swing and Slide Gate Operator UL 325 and
ASTM F2200 Site Planning Safety Checklist
Please Print
Name:
Address:
City/State/ZIP:
Gate Safety Check —
UL 325 Standards
1. Gate Operator is approved to current UL 325 standards (check operator label)
2. Proper gate warning signs attached to both sides of gate area
3. Each entrapment zone protected by 2 safety devices/obstruction tested
Close Side
(circle one) Photo Eye
Open Side
(circle one) Photo Eye
Other Entrapment Areas
UL 325 Installation Class (
circle one)
ASTM F2200 Standards
Gate Construction Evaluation: Gate Constructed with Safety in mind. ASTM F2200 Standards are followed
All Gates
Gates have smooth bottom edges, no protrusions exist
All access controls at least 6 ft. from gate
Barbed tape at least 8 ft. above grade
Barbed wire at least 6 ft. above grade
Separate pedestrian gate – out of reach of a moving gate – vehicular gate is
for automotive traffic only
SWING
Distance from pivot point to column edge is less than 4 in.
Distance from open gate to wall or column greater than 16 in. or secondary
entrapment protection is provided
SLIDE
Roller covers on wheels
Meshing installed up to 6 ft. above grade if pickets spaced equal to or
greater than 2.25 in. apart
Gate does not move on its own if disconnected from operator
Gap between gate and fence post less than 2.25 in.
Positive stops at both fully open and fully closed positions
Receiver guides recessed behind receiver post for receiver guides less than 8 ft.
Gates prevented from falling over if disconnected from supporting hardware
Other:
Please Print
First & Last Name of Dealer:
Name of Dealership:
Dealership Address (Street Address/City/State/Zip):
Dealer Signature:
Customer Signature:
© 2015 LiftMaster All Rights Reserved
845 Larch Ave., Elmhurst, IL 60126
Satisfactory
Simple steps to quickly determine if an End User's gate operator is safe.
Component:
Reversing Edge Inherent Reverse
Reversing Edge Inherent Reverse
I II III
Component:
Phone:
Email:
Result (Circle)
Pass / Fail
Pass / Fail
Pass / Fail
Pass / Fail
Pass / Fail
VI
Result (Circle)
Pass / Fail
Pass / Fail
Pass / Fail
Pass / Fail
Pass / Fail
Pass / Fail
Pass / Fail
Pass / Fail
Pass / Fail
Pass / Fail
Pass / Fail
Pass / Fail
Pass / Fail
Pass / Fail
Pass / Fail
First & Last Name of Installer:
Phone:
Installer Signature:
Needs Repair/Replacement
Comments:
Comments:
