SERVICE MANUAL
VHF TRANSCEIVER, UHF TRANSCEIVER
RA077<Rev.001>
2019
10
SERVICE MANUAL
B5B-7320-00
NX-1200DV, NX-1200D, NX-1200NV, NX-1200N,
NX-1300DU, NX-1300D, NX-1300NU, NX-1300N
NX-1200, NX-1300 series (Basic model)
COPYRIGHT © 2019 JVCKENWOOD Corporation
This product complies with the RoHS directive for the European market.
This product uses Lead Free solder.
B5B-7320-00
No.RA077<Rev.001>
COPYRIGHT © 2019 JVCKENWOOD Corporation
2019/10

Advertisement

Table of Contents
loading

Related Manuals for Kenwood NX-1200 Series

Summary of Contents for Kenwood NX-1200 Series

  • Page 1 SERVICE MANUAL VHF TRANSCEIVER, UHF TRANSCEIVER RA077<Rev.001> 2019 SERVICE MANUAL B5B-7320-00 NX-1200DV, NX-1200D, NX-1200NV, NX-1200N, NX-1300DU, NX-1300D, NX-1300NU, NX-1300N NX-1200, NX-1300 series (Basic model) COPYRIGHT © 2019 JVCKENWOOD Corporation This product complies with the RoHS directive for the European market. This product uses Lead Free solder.
  • Page 2 NX-1200 Series (K) type ........
  • Page 3 SPECIFICATION NX-1200 series GENERAL Frequency Range 136 ~ 174 MHz Max. Channels per Radio 64 channels Number of Zones 4 zones Max. Channels per Zone 16 channels Channel Spacing Analog 12.5 / 15 / 25*1 / 30*1 kHz Digital 6.25 / 12.5 kHz Power Supply 7.5V DC ±20 %...
  • Page 4 NX-1300 series GENERAL Frequency Range 400 ~ 470 MHz Max. Channels per Radio 64 channels Number of Zones 4 zones Max. Channels per Zone 16 channels Channel Spacing Analog 12.5 / 25*1 kHz Digital 6.25 / 12.5 kHz Power Supply 7.5V DC ±20 % Battery Life with KNB-45L...
  • Page 5 SECTION 1 PRECAUTION This service manual does not describe PRECAUTION. SECTION 2 SPECIFIC SERVICE INSTRUCTIONS SYSTEM SET-UP Merchandise received Type Frequency range (MHz) RF power NX-1200DV K TX/RX 136~174 NX-1200D K TX/RX 136~174 Select the type of transceiver NX-1200NV K NXDN TX/RX 136~174 NX-1200N K...
  • Page 6 When using the KPG-22U, install the supplied CD (with driver software) in the PC. The KPG-22U driver runs under Windows 7, 8.1, 10. The latest version of the USB driver is available for download from the following URL: https://www.kenwood.com/usb-com/ (This URL may change without notice.) 1-6 (No.RA077<Rev.001>)
  • Page 7 2.2.3.4 Programming software KPG-D6/D6N description • If the Disable Reading Key Data is enabled through The FPU is the programming software for the transceiver the FPU. supplied on a CD. d) Source transceiver and Target transceiver must have This software runs under Windows 7, 8.1, 10. same model name data if they using the Clone The data can be input to or read from the transceiver and edited function.
  • Page 8 2.3.1 Overview The NX-1200 series is a VHF Analog FM & Digital Portable transceiver designed to operate in the frequency range of 136 to 174MHz. The unit consists of a transceiver IC, a transmitter, a digital control unit, and a power supply circuit.
  • Page 9 The oscillation frequency is adjusted TCXO directly by controlled the D/A converter (IC604). 2.3.5.2 • NX-1200 series There is one VCO contain TX VCO and RX VCO. The VCO (Q4) generates the carrier for the transmitter and the receiver. The VCO oscillation frequency range is 272 to 348MHz.
  • Page 10 2.3.5.3 PLL (IC2) compares the difference in phases of the VCO oscillation signal and the TCXO (X1) reference frequency. And it returns the difference voltage to the VCO CP terminal and realizes the "Phase Locked Loop". This allows the VCO oscillation frequency to accurately match (lock) the desired frequency.
  • Page 11 2.3.7 Power Supply Circuit The battery voltage (+B) is provided from battery terminal. The battery voltage passes through the 3.15A fuse (F400), and goes to RF Drive and final amplifier, DC/DC converter (IC407), AF amplifier (IC300 through the 1.0A fuse (F300)), and INT DET IC (IC406). IC406 monitors battery voltage.
  • Page 12 SEMICONDUCTOR DATA Pin No. Name Function 2.4.1 MPU/DSP: 2F405VGT6KHGA (TX-RX unit IC501) 50VC O 5V AVR Control for GPS MIC Pin No. Name Function - No Connection BSHIFT O MPU/DSP Clock frequency Shift O APC Voltage Discharge Switch - No Connection DAC2_CLK O CLK for DAC IC605 - No Connection...
  • Page 13 Pin No. Name Function Ref. No. Part Name Use / Function SRST I SRST for SWD IC602 MIC AMP O SB switch control IC603 AF AMP Filter [AF AMP FIL] FLDM I Force Flash Load Mode IC604,605 IC D/A converter [DAC] /SB_DET I Power Switch detect IC606...
  • Page 14 Ref. No. Part Name Use / Function D200-203 VARIABLE RF BPF control [RF BPF CTL] CAPACITANCE DIODE D300 DIODE LED indicator [IND] D303 DIODE DC switch [DC SW] D304-307 VARISTOR Surge protection [SURGE P] D400 DIODE Reverse current protection D401 DIODE DC switch [DC SW] D402...
  • Page 15 2.6.2 SP/MIC Connector Specification I/O Signal Description Item and Condition Unit Note Name Type PTT/RXD I Digital PTT/RXD input Input Voltage (High) Zin = 47kohm Input Voltage (Low) Internal Pull-up (5V) Baud Rate 0.2304 Mbps MICI I Analog External MIC input Maximum Input 1100 mVrms Zin = 1.8kohm@1kHz...
  • Page 16 SECTION 3 DISASSEMBLY Precautions for Disassembly (6) Remove Speaker Holder Assy from Chassis. Press on the hooking portion of Speaker Holder and 3.1.1 Removing the TX-RX unit and other parts. remove the Speaker Holder Assy from Chassis. (1) Loosen CAP screw and remove the CAP.<1> Note: (2) Remove Volume Knob &...
  • Page 17 (7) Remove PCB screws (x8). (11) Remove Rubber Seal & Holder Assy, Packing from (8) Desolder the ANT Receptacle and Positive Terminal. Chassis. Desolder ANT Receptacle Desolder Packing Positive terminal Rubber Seal Holder (9) Unlock the FPC connector and remove FPC cable from it, Assy then remove the PCB from Chassis.
  • Page 18 Precautions for Reassembly (4) Attaching the Battery Release Lever to the Front Case • Insert one side of the shaft into the hole at the lever fitting (1) Attach Rubber Sheet & Cushion to the chassis. section on the Front Case.<1> Note: Cushion The thin spring should be positioned above the two...
  • Page 19 (5) Assembling the Battery Release Lever (6) Attaching the Positive Terminal to the Chassis • Place the lever <2> onto the stopper <1>. Always attach the positive terminal to the chassis, using • Place the thick spring <3> onto the lever. the following procedures, before attaching the TX-RX unit •...
  • Page 20 SECTION 4 ADJUSTMENT NX-1200 Series (K) type 4.1.1 Test Equipment Required for Alignment Test Equipment Major Specifications 1. Standard Signal Frequency Range 100 to 520MHz Generator (SSG) Modulation Frequency modulation and external modulation Output -127dBm/0.1μV to greater than -47dBm/1mV 2. Power Meter...
  • Page 21 DMR mode signaling NX-1200 Series (K) type 4.1.2 Frequency and Signaling CC 00 Burst CC 00 Burst The transceiver has been adjusted for the frequencies shown in PN9 Continuous Pattern PN9 Continuous Pattern the following table. When required, readjust them following the...
  • Page 22 NX-1200 Series (K) type NX-1200 Series (K) type Adjustment Item Description Adjustment Item Description Maximum Maximum Deviation of Analog (Wide/ Receive Band-Pass Filter is adjusted. Deviation Narrow) is adjusted. Sensitivity The performance of Receive Sensitivity is (Analog Wide/ This item must be adjusted before all improved.
  • Page 23 NX-1200 Series (K) type Order Adjustment item Dn (DMR) Adjust item (Analog Wide) (Analog Narrow) (NXDN Narrow) (NXDN Very Narrow) Number Adjustment range DQT Balance Transmitter Section 5, 6 1 ~ 256 Maximum Deviation Transmitter (Analog) Section 7 1 ~ 1024...
  • Page 24 4.1.6 Radio check Section NX-1200 Series (K) type Item Condition Measurement Adjustment Specifications/ Remarks PC test mode Point Method 1. Frequency check 1) Test Channel: 1 f. counter Check 155.099923~ Test Signaling Mode: Analog -ANT 155.100077MHz Signaling: 1 (±0.5ppm@155.1MHz) 2) PTT: Press [Transmit] button.
  • Page 25 4.1.7 Common Section NX-1200 Series (K) type Item Condition Measurement Adjustment Specifications/ Remarks PC tuning mode Point Method 1. Setting 1) BATT terminal voltage:7.5V 2) SSG standard modulation [Wide] MOD:1kHz/DEV:3kHz [Narrow] MOD:1kHz/ DEV:1.5kHz 2. Assist 1) Adj item: [Assist Voltage] [Automatic Adjustment] 2.4~2.6V...
  • Page 26 NX-1200 Series (K) type Item Condition Measurement Adjustment Specifications/Remarks PC tuning mode Point Method 3. Medium 1) Adj item: Power meter 4.0W ±0.5W transmit [Medium Transmit Power] -ANT [<],[>] 2.3A or less power 2) Adj point: 5 points Power supply...
  • Page 27 NX-1200 Series (K) type Item Condition Measurement Adjustment Specifications/Remarks PC tuning mode Point Method 9. Maximum 1) Adj item: Deviation meter Adjust to "4200Hz". 4150~4250Hz deviation [Maximum Deviation (Analog Wide)] -ANT [<],[>] (Analog) 2) Adj point: 5 points Oscilloscope Press [OK] button to store...
  • Page 28 NX-1200 Series (K) type Item Condition Measurement Adjustment Specifications/Remarks PC tuning mode Point Method 13. DTMF 1) Adj item: Deviation meter Write the reference value 2.50kHz±0.05kHz Deviation [DTMF Deviation (Analog Wide)] -ANT [<],[>] "156" for each adjustment 2) Adj point: 5 points Oscilloscope points.
  • Page 29 In the case of the signaling "QT (Analog Wide)", this signaling is composed of three elements [Balance, Maximum Deviation (Analog Wide) and QT Deviation (Analog Wide)]. Please adjust Balance and Maximum Deviation (Analog Wide) before adjusting QT Deviation (Analog Wide). NX-1200 Series (K) type Mode Signaling...
  • Page 30 4.1.9 Receiver Section NX-1200 Series (K) type Item Condition Measurement Adjustment Specifications/ Remarks PC tuning mode Point Method 1. AF level <PC test mode> Volume Turn the Volume knob 0.63V±0.1V setting 1) Test Channel: 1 -ANT to obtain 0.63V AF...
  • Page 31 NX-1200 Series (K) type Item Condition Measurement Adjustment Specifications/ Remarks PC tuning mode Point Method 7. Open 1) Adj item: Input signal from SSG, press [Start] button Squelch (5) [Open Squelch (5) (DMR)] -ANT to adjust, and after that press [OK] button to...
  • Page 32 NX-1300 Series (K4) type 4.2.1 Test Equipment Required for Alignment Test Equipment Major Specifications 1. Standard Signal Frequency Range 100 to 520MHz Generator (SSG) Modulation Frequency modulation and external modulation Output -127dBm/0.1μV to greater than -47dBm/1mV 2. Power Meter Input Impedance 50ohm Operation Frequency 100 to 520MHz...
  • Page 33 DMR mode signaling NX-1300 Series (K4) type 4.2.2 Frequency and Signaling CC 00 Burst CC 00 Burst The transceiver has been adjusted for the frequencies shown in PN9 Continuous Pattern PN9 Continuous Pattern the following table. When required, readjust them following the adjustment procedure to obtain the frequencies you want in CC 00 Burst Maximum Deviation...
  • Page 34 NX-1300 Series (K4) type NX-1300 Series (K4) type Adjustment Item Description Adjustment Item Description Maximum Maximum Deviation of Analog (Wide/ LNA Off AGC Adjust this item to set AGC gain when LNA is Deviation Narrow) is adjusted. Calibration off. (Analog Wide/ This item must be adjusted before all Open Squelch (5) The squelch level at level "5"...
  • Page 35 NX-1300 Series (K4) type Order Adjustment item Dn (DMR) Adjust item (Analog Wide) (Analog Narrow) (NXDN Narrow) (NXDN Very Narrow) Number Adjustment range DQT Balance Transmitter Section 5, 6 1 ~ 256 Maximum Deviation Transmitter (Analog) Section 7 1 ~ 1024 Maximum Deviation Transmitter (NXDN)
  • Page 36 4.2.6 Radio check Section NX-1300 Series (K4) type Item Condition Measurement Adjustment Specifications/ Remarks PC test mode Point Method 1. Frequency check 1) Test Channel: 1 f. counter Check 435.099783~ Test Signaling Mode: Analog -ANT 435.100217MHz Signaling: 1 (±0.5ppm@ 435.1MHz) 2) PTT: Press [Transmit] button.
  • Page 37 4.2.7 Common Section NX-1300 Series (K4) type Item Condition Measurement Adjustment Specifications/ Remarks PC tuning mode Point Method 1. Setting 1) BATT terminal voltage:7.5V 2) SSG standard modulation [Wide] MOD:1kHz/DEV:3kHz [Narrow] MOD:1kHz/ DEV:1.5kHz 2. Assist 1) Adj item: [Assist Voltage] [Automatic Adjustment] 2.4~2.6V Voltage...
  • Page 38 NX-1300 Series (K4) type Item Condition Measurement Adjustment Specifications/Remarks PC tuning mode Point Method 3. Medium 1) Adj item: Power meter 4.0W ±0.5W transmit [Medium Transmit Power] -ANT [<],[>] 2.3A or less power 2) Adj point: 5 points Power supply (Battery [Low], [Low'], [Center], [High'], [High] Ammeter...
  • Page 39 NX-1300 Series (K4) type Item Condition Measurement Adjustment Specifications/Remarks PC tuning mode Point Method 8. Maximum 1) Adj item: Deviation meter Adjust to "1337Hz". 1310~1363Hz Deviation [Maximum Deviation (NXDN Very -ANT [<],[>] (NXDN ) *3 Narrow)] Oscilloscope Press [OK] button to store the 2) Adj point: 5 points adjustment value after all [Low], [Low'], [Center], [High'], [High]...
  • Page 40 NX-1300 Series (K4) type Item Condition Measurement Adjustment Specifications/Remarks PC tuning mode Point Method 12. DQT 1) Adj item: Deviation meter Write the reference 0.75kHz±0.05kHz Deviation [DQT Deviation (Analog Wide)] -ANT [<],[>] value "156" for each 2) Adj point: 5 points Oscilloscope adjustment points.
  • Page 41 NX-1300 Series (K4) type Item Condition Measurement Adjustment Specifications/Remarks PC tuning mode Point Method 15. MSK 1) Adj item: Deviation meter Write the reference 3.00kHz±0.05kHz Deviation [MSK Deviation (Analog Wide)] Power meter [<],[>] value "729" for each 2) Adj point: 5 points -ANT adjustment points.
  • Page 42 4.2.8.1 Necessary Deviation adjustment item for each signaling and mode The following shows the necessary adjustment items for each signaling deviation. Please read the following table like the following example. In the case of the signaling "QT (Analog Wide)", this signaling is composed of three elements [Balance, Maximum Deviation (Analog Wide) and QT Deviation (Analog Wide)].
  • Page 43 4.2.9 Receiver Section NX-1300 Series (K4) type Item Condition Measurement Adjustment Specifications/ Remarks PC tuning mode Point Method 1. AF level <PC test mode> Volume Turn the Volume knob 0.63V±0.1V setting 1) Test Channel: 1 -ANT to obtain 0.63V AF Test Signaling Mode: Analog Signaling: 1 AF VM output.
  • Page 44 NX-1300 Series (K4) type Item Condition Measurement Adjustment Specifications/ Remarks PC tuning mode Point Method 7. Open 1) Adj item: Input signal from SSG, press [Start] button Squelch (5) [Open Squelch (5) (DMR)] -ANT to adjust, and after that press [OK] button to (DMR) 2) Adj point: 5 points Distortion meter...
  • Page 45 SECTION 5 TROUBLESHOOTING Failure diagnosis of the VCO section 5.1.1 Overview The VCO circuit is mounted inside a BLS. BLS stands for "Board Level Shield". This BLS has no lid and provides high shielding performance. Because BLS is not removable from circuit board by hand solder, the components inside the BLS is unable to solder.
  • Page 46 0.01u 100p 24 23 22 21 20 19 NX-1300 0.01u 100p VCO circuit inside a BLS 100p TEST4 PLL IC RFINP 100p TEST1 RFINN [within the bold line square] AK1543 0.22u VREF2 VCO BUFFER DATA DVSS 2SC5108FT/Y/ 0.22u 3.0p RK74HA1J101J *C54 *C56 *C72...
  • Page 47 5.1.6 Inspection Procedure Assist Auto tune ●Check VCO output level - Remove R59 and C42 - Remove R9. for NX-1200. - Solder the following capacitor on the - There is problem with circuit No Signal Short Circuit - Remove L21 and C42 position ($C89).
  • Page 48 Operating Method of Enforced Firmware Overwriting (5) Upon startup of FLDM loader, Red LED blinking. Mode (6) Start Updater for NX-1000 Series, select the COM port number and speed, and then click the "Write" button. Enforced firmware overwriting mode is a mode to forcibly Note: overwrite the transceiver firmware when the transceiver cannot High speed is for KPG-22U, for other cable please...
  • Page 49 KPG-D6/ KPG-D6N. Note: • When a new printed circuit board is used, the KENWOOD ESN changes, as does the Transceiver Information display of the KPG-D6/ KPG-D6N, but this does not have any effect on the operation of the transceiver.
  • Page 50 MEMO...
  • Page 51 PRECAUTIONS ON SCHEMATIC DIAGRAMS * Due to the improvement in performance, some part numbers shown in the circuit diagrams may not agree with those indicated in the Parts List. * The parts numbers, values and rated voltage etc. in the Schematic Diagrams are for reference only.
  • Page 52 PRINTED CIRCUIT BOARD TX-RX UNIT (XC1-295K-01 (NX-1200 Series)) --- Component side view/Side A (J7C-0289-00) --- C302 R301 C304 XC1-295 R302 C300 R545 J7C-0289-00 C318 C316 Q103 C400 F400 R115 C104 C303 R111 Q202 C403 R142 D105 CN300 IC400 C406 TL201...
  • Page 53 TX-RX UNIT (XC1-295K-01 (NX-1200 Series)) --- Foil side view/Side B (J7C-0289-00) --- S302 S303 C175 R152 C421 S301 S302 D402 S303 C529 IC100 L119 C517 IC502 R415 L500 R503 R501 C525 C409 L404 C511 R227 R526 C508 C423 S301 R522...
  • Page 54 A-1C ADDRESS TABLE OF BOARD PARTS Side Y axis Each address may have an address error by one X axis interval. REF.NO. LOCATION REF.NO. LOCATION REF.NO. LOCATION REF.NO. LOCATION REF.NO. LOCATION REF.NO. LOCATION REF.NO. LOCATION REF.NO. LOCATION REF.NO. LOCATION REF.NO. LOCATION REF.NO. LOCATION REF.NO. LOCATION B- 2A B- 2A R223...
  • Page 55 TX-RX UNIT (XC1-296K-01 (NX-1300 Series)) --- Component side view/Side A (J7C-0290-00) --- C302 R301 C304 R302 XC1-296 C300 C318 J7C-0290-00 C316 Q103 F400 C400 R115 C104 C303 R111 Q202 C403 R142 D105 IC400 CN300 C406 TL201 CN401 R543 R402 Q400 R542 R315 R314...
  • Page 56 TX-RX UNIT (XC1-296K-01 (NX-1300 Series)) --- Foil side view/Side B (J7C-0290-00) --- S302 S303 C175 R152 C421 S301 S302 D402 C529 S303 IC100 C517 IC502 R415 L500 R503 R501 C525 C266 C409 L404 C511 R227 C508 C423 R522 C526 C174 S301 R225 R226...
  • Page 57 A-1C ADDRESS TABLE OF BOARD PARTS Side Y axis Each address may have an address error by one X axis interval. REF.NO. LOCATION REF.NO. LOCATION REF.NO. LOCATION REF.NO. LOCATION REF.NO. LOCATION REF.NO. LOCATION REF.NO. LOCATION REF.NO. LOCATION REF.NO. LOCATION REF.NO. LOCATION REF.NO. LOCATION REF.NO. LOCATION B- 2A B- 2A R230...
  • Page 58 BLOCK DIAGRAM TX-RX UNIT (NX-1200 Series) TX-RX UNIT (XC1-295) IC400 TX/RX VCO TX/RX 50M (5.0V) 5.0V AVR NX-1200DV-K NX-1200D-K 272.00-348.00MHz 136.00-174.00MHz Q400 NX-1200NV-K NX-1200N-K 50T (5.0V) TX/RX PLL_DATA PLL_CLK IC402 PLL_LE 5.0V AVR 50V (5.0V) PLL_LD PLL IC D5,6 D101,102 IC401 X1 16.8MHz...
  • Page 59 TX-RX UNIT (NX-1300 Series) TX-RX UNIT (XC1-296) IC400 TX/RX VCO TX/RX 5.0V AVR 50M (5.0V) NX-1300DU-K4 Q400 NX-1300D-K4 800.00-940.00MHz 400.00-470.00MHz NX-1300NU-K4 50T (5.0V) NX-1300N-K4 TX/RX PLL_DATA PLL_CLK IC402 PLL_LE 5.0V AVR 50V (5.0V) PLL_LD PLL IC D5,6 D7,8 D101,102 IC401 X1 16.8MHz Q100 Q104...
  • Page 60 LEVEL DIAGRAM TX-RX UNIT (NX-1200 Series) ■ Receiver Section RF (Center Frequency) AF (1kHz) -110.0dBm -122.0dBm -121.5dBm -121.0dBm -123.5dBm -119.5dBm 40mVrms 2.02Vp-p C224 D101 IC302 D102 D103 Internal Speaker IC501 C168 D104 C201 C209 Q200 C216 IC200 IC603 C633 AF AMP...
  • Page 61 TX-RX UNIT (NX-1300 Series) ■ Receiver Section RF (Center Frequency) AF (1kHz) -110.0dBm -122.0dBm -121.5dBm -121.0dBm -123.5dBm -119.5dBm 40mVrms 1.95Vp-p C224 D101 IC302 D102 D103 Internal Speaker C168 C209 Q200 C216 IC501 C633 D104 C201 IC200 IC603 AF AMP Transceiver IC MPU/DSP 2.15Vp-p IC300...
  • Page 62 < MEMO > (No.RA077<Rev.001>) 2-12 2-12 (No.RA077<Rev.001>)
  • Page 63 SCHEMATIC DIAGRAM TX-RX UNIT (XC1-295K-01 (NX-1200 Series)) 0.01u 100p 24 23 22 21 20 19 0.01u 100p 100p PVDD CPVDD PLL IC RFINP 100p TEST4 RFINN TEST1 0.22u FINAL AMP VREF2 RK74HA1J101J AK1541 Q107 C148 DVSS 16.8MHz DATA RD07MUS2BT214 L120...
  • Page 64 TX-RX UNIT (XC1-296K-01 (NX-1300 Series)) 0.01u 100p 24 23 22 21 20 19 0.01u 100p 100p PVDD CPVDD PLL IC RFINP 100p TEST4 RFINN FINAL AMP TEST1 VREF2 0.22u AK1543 VCO BUFFER Q107 RK74HA1J101J DVSS DATA RD07MUS2BT514 C164 D101 C168 L117 L118 L119...
  • Page 65 * (x_) in a description column shows the number of the used part. - Contents - Exploded view of general assembly and parts list (NX-1200 series) Exploded view of general assembly and parts list (NX-1300 series) Electrical parts list (NX-1200 series)
  • Page 66 Exploded view of general assembly and parts list (NX-1200 series) Block No.M1MM TX-RX UNIT<01> 3-2(No.RA077<Rev.001>)
  • Page 67 General assembly (NX-1200 series) Block No. [M][1][M][M]  Symbol No. Part No. Part Name Description Local A0C-0248-01 P.CABINET ASSY A1A-0131-02 CHASSIS COAT B1B-0174-00 ILL.GUIDE B4D-0065-00 KENWOOD BADGE D1A-0071-00 LEVER D2B-0066-00 SHAFT D32-0441-13 STOPPER E04-0477-15 C.RECEPTACLE-SM E23-1253-24 TERMINAL E23-1395-04 TERMINAL G10-1348-04...
  • Page 68 Exploded view of general assembly and parts list (NX-1300 series) Block No.M2MM TX-RX UNIT<01> 3-4(No.RA077<Rev.001>)
  • Page 69 General assembly (NX-1300 series) Block No. [M][2][M][M]  Symbol No. Part No. Part Name Description Local A0C-0248-01 P.CABINET ASSY A1A-0131-02 CHASSIS COAT B1B-0174-00 ILL.GUIDE B4D-0065-00 KENWOOD BADGE D1A-0071-00 LEVER D2B-0066-00 SHAFT D32-0441-13 STOPPER E04-0477-15 C.RECEPTACLE-SM E23-1253-24 TERMINAL E23-1395-04 TERMINAL G10-1348-04 FIBROUS SHEET...
  • Page 70 Electrical parts list (NX-1200 series) TX-RX UNIT  Symbol No. Part No. Part Name Description Local XC1-295K-01 Q300 LTC014EEBFS8 DIGI TRANSISTOR (NX-1200DV,NX-1200D,NX-1200NV,NX-1200N) Q301 LTC014EEBFS8 DIGI TRANSISTOR Q302 LTC014EEBFS8 DIGI TRANSISTOR Q303 SSM3K324RF Note 1:If changing this IC, please contact our service center.
  • Page 71  Symbol No. Part No. Part Name Description Local  Symbol No. Part No. Part Name Description Local CC73JCH1H101J C CAPACITOR 100pF 50V J C102 CK73JXR1H102K C CAPACITOR 1000pF 50V K CC73JCH1H101J C CAPACITOR 100pF 50V J C103 CK73JXR1C104K C CAPACITOR 0.1uF 16V K CK730PQ1E475K C CAPACITOR 4.7uF 25V K...
  • Page 72  Symbol No. Part No. Part Name Description Local  Symbol No. Part No. Part Name Description Local C216 CC730EE1H102K C CAPACITOR 1000pF 50V K C321 CK73HB1C105K C CAPACITOR 1uF 16V K C217 CK73JXR1H102K C CAPACITOR 1000pF 50V K C322 CK73JXR1H102K C CAPACITOR 1000pF 50V K C218...
  • Page 73  Symbol No. Part No. Part Name Description Local  Symbol No. Part No. Part Name Description Local C522 CK73HB0J225K C CAPACITOR 2.2uF 6.3V K RK73HB1J331J MG RESISTOR 330Ω 1/16W J C523 CK73JXR1H102K C CAPACITOR 1000pF 50V K RK73HB1J100J MG RESISTOR 10Ω...
  • Page 74  Symbol No. Part No. Part Name Description Local  Symbol No. Part No. Part Name Description Local R107 RK73HB1J000J MG RESISTOR 0Ω 1/16W J R234 RK73HH1J822D MG RESISTOR 8.2kΩ 1/16W D R109 RK73HH1J223D MG RESISTOR 22kΩ 1/16W D R235 RK73HH1J103D MG RESISTOR 10kΩ...
  • Page 75  Symbol No. Part No. Part Name Description Local  Symbol No. Part No. Part Name Description Local R501 RK73HB1J000J MG RESISTOR 0Ω 1/16W J R625 RK73HB1J104J MG RESISTOR 100kΩ 1/16W J R502 RK73JB1H101J MG RESISTOR 100Ω 1/20W J R626 RK73HB1J101J MG RESISTOR 100Ω...
  • Page 76 Electrical parts list (NX-1300 series)  Symbol No. Part No. Part Name Description Local TX-RX UNIT L201 L41-6878-14 CHIP INDUCTOR XC1-296K-01 L202 L41-6878-14 CHIP INDUCTOR (NX-1300DU,NX-1300D,NX-1300NU,NX-1300N) L203 LK73H0AMR27J M.CHIP INDUCTOR L204 L41-6878-14 CHIP INDUCTOR L206 L41-6878-14 CHIP INDUCTOR Note 1:If changing this IC, please contact our L207 LK73H0AMR22J M.CHIP INDUCTOR...
  • Page 77  Symbol No. Part No. Part Name Description Local  Symbol No. Part No. Part Name Description Local Q302 LTC014EEBFS8 DIGI TRANSISTOR CC73JCH1H101J C CAPACITOR 100pF 50V J Q303 SSM3K324RF CC73JCH1H101J C CAPACITOR 100pF 50V J Q304 SSM3K324RF CK73JXR1C104K C CAPACITOR 0.1uF 16V K Q305 LTC014EEBFS8...
  • Page 78  Symbol No. Part No. Part Name Description Local  Symbol No. Part No. Part Name Description Local C104 CK73JXR1H471K C CAPACITOR 470pF 50V K C205 CC730CC1H080B C CAPACITOR 8pF 50V B C105 CC730CC1H080B C CAPACITOR 8pF 50V B C206 CK73JXR1H271K C CAPACITOR 270pF 50V K C106...
  • Page 79  Symbol No. Part No. Part Name Description Local  Symbol No. Part No. Part Name Description Local C315 CK730AY0J226M C CAPACITOR 22uF 6.3V M C512 CK73HXR0J105K C CAPACITOR 1uF 6.3V K C316 CK73JXR1H471K C CAPACITOR 470pF 50V K C513 CK730DX1C103K C CAPACITOR 0.01uF 16V K C317...
  • Page 80  Symbol No. Part No. Part Name Description Local  Symbol No. Part No. Part Name Description Local C643 CK73JXR1C104K C CAPACITOR 0.1uF 16V K RK73HB1J000J MG RESISTOR 0Ω 1/16W J C644 CK73HB1A105K C CAPACITOR 1uF 10V K RK73HB1J000J MG RESISTOR 0Ω...
  • Page 81  Symbol No. Part No. Part Name Description Local  Symbol No. Part No. Part Name Description Local R228 RK73HH1J683D MG RESISTOR 68kΩ 1/16W D R414 RK73HB1J000J MG RESISTOR 0Ω 1/16W J R229 RK73HH1J473D MG RESISTOR 47kΩ 1/16W D R415 RK73FB2B000J MG RESISTOR 0Ω...
  • Page 82  Symbol No. Part No. Part Name Description Local  Symbol No. Part No. Part Name Description Local R621 RK73HB1J101J MG RESISTOR 100Ω 1/16W J R622 RK73HB1J101J MG RESISTOR 100Ω 1/16W J L120 LK73H0AM22NJ M.CHIP INDUCTOR R623 RK73HB1J100J MG RESISTOR 10Ω...
  • Page 83 Packing materials and accessories parts list (NX-1200 series) Block No.M3MM Packing and accessories Block No. [M][3][M][M]  Symbol No. Part No. Part Name Description Local B5A-3224-00 INST.MANUAL E,F,S B0K-0116-00 B0K-0117-00 CAP ASSY 2PIN --------- PACKING FIXTURE --------- PROTECTION BAG RADIO...
  • Page 84 Packing materials and accessories parts list (NX-1300 series) Block No.M4MM Packing and accessories Block No. [M][4][M][M]  Symbol No. Part No. Part Name Description Local B5A-3224-00 INST.MANUAL E,F,S B0K-0116-00 B0K-0117-00 CAP ASSY 2PIN --------- PACKING FIXTURE --------- PROTECTION BAG RADIO --------- PROTECTION BAG HOLDER...
  • Page 85 MEMO...
  • Page 86 JVCKENWOOD Corporation Communications Systems Division (No.RA077<Rev.001>) Printed in Japan...
