Service Quick Guide
Service Quick Guide
Indesit Basic Range Big Digit Interface washing machine
Models Covered:
Arcadia washing machine: "IWA..., IWB..., IWC..."
Interface:
Function Buttons
1
ON/OFF button
2
PROGRAM knob
3
WASH OPTION buttons and LEDs
Demo Mode:
Not present in this model
Autotest function:
Start with the appliance off and the program knob set to the top position (at 12 o'clock).
1.
Switch on the appliance and turn the knob clockwise by one position. Switch off the appliance and
turn the knob to the original position
2.
Switch on the appliance and turn the knob clockwise by two positions. Switch off the appliance and
turn the knob to the original position
3.
Switch on the appliance and turn the program knob counter-clockwise by one position then press the
Start button.
1/2
SQG_WM_34_IT
Indesit Company, Service Department
1
2
4
START/PAUSE button and LED
5
BIG DIGIT display
3
3
5
3
4
