You should have received the parts listed below. While we give much attention to out product, unfortunately an occasional error may occur. If a part is missing, do not go back to the store. Call Weber- Stephen Products Customer Service Center toll free 1-800-446-1071 to receive immediate assistance.
Page 4
Install Legs Place washers on leg ends and insert ends into holes in bottom unit. Be careful not to scratch the porcelain finish while installing the legs. Repeat with other leg. Install Leg Lock Position curved end of leg lock at corner of the straight portion of the leg, as shown.
Page 5
Install Burner Tube From the inside, insert burner tube through the large hole in the side of the bottom unit. Line up the other end of the tube with the hole. Insert the 1/2 inch bolt. Add the washer and wing nut. Tighten. Install Regulator Remove the retaining clip from the regulator.
Page 6
Install Igniter Insert the igniter electrode and two 10-24 screws through the igniter bracket and the holes in the bottom unit on the side opposite the regulator. Add washers and wing nuts, making sure that the wing nuts are secured in a vertical position.
Page 7
Install Flavorizer Bar Place the Flavorizer Bar in bottom unit, covering the burner. Install Cooking Grate Set the cooking grate onto the recessed edge of the bottom unit. To Secure for Transport Put the lid on the bottom unit unlock legs and pivot them into the locked position up over the projections on the lid.
To Use Pivot legs under grill and lock legs. The hooks on the inside of the lid allow it to rest on the edge of the bottom unit. Read important DANGERS, WARNINGS and CAUTIONS in Owner’s Guide before operating this barbecue. Connecting the Cylinder 1.
Check for Gas Leaks Do not use an open flame to check for gas leaks. Be sure there are no sparks or open flames in the area while you check for leaks. This will result in a fire or explosion which can cause serious bod- ily injury or death, and damage to property.
Manual Lighting 1. Light a match and hold it in one of the four holes in the bottom of the grill. 2. Push down burner control valve and turn counter-clockwise to HIGH. 3. Check to see if the burner is lit by looking through the viewing hole in the Flavorizer Bar.
