DCR5000.O/M.QXD 1/28/03 7:21 AM Page 1 QUICK REFERENCE The Quick Reference is given to provide basic operation of the unit. Please completely read the user’s guide to take advantage of all the features this unit has to offer. Set the Radio preset/Set the Disney Alarm type Activate the Sleep function Set the clock and/or the alarm time Turn the Alarm on or off...
Page 3
DCR5000.O/M.QXD 1/28/03 7:21 AM QUICK REFERENCE (CONTINUED) TO LISTEN TO THE RADIO: 1. Press the Radio On/Off button to turn the unit on; the AM or FM indicator will light. 2. Press the AM/FM Band button to select AM or FM. 3.
DCR5000.O/M.QXD 1/28/03 7:21 AM SAFETY PRECAUTIONS DANGEROUS VOLTAGE: The lightning flash with arrowhead symbol, within an equilateral triangle is intended to alert the user to the presence of uninsulated dangerous voltage within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. ATTENTION: The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and...
DCR5000.O/M.QXD 1/28/03 7:21 AM IMPORTANT SAFETY INSTRUCTIONS Before using the unit, be sure to read all operating instructions carefully. Please note that these are general precautions and may not pertain to your unit. For example, this unit may not have the capability to be connected to an outdoor antenna.
Page 6
DCR5000.O/M.QXD 1/28/03 7:21 AM IMPORTANT SAFETY INSTRUCTIONS point where they exit from the appliance. 13. LIGHTNING To protect your product from a lightning storm, or when it is left unattended and unused for long periods of time, unplug it from the wall outlet and disconnect the antenna or cable system.
DCR5000.O/M.QXD 1/28/03 7:21 AM LOCATION OF CONTROLS RIGHT Display Volume Control Tuning Up/Minute Button Display Low/High Button Radio On/Off Button Alarm On/Off Button Display (12/24hr) Switch AM/FM Band Button Radio Preset Up Button 10. Battery Compartment (Bottom of Unit) DISPLAY A.
DCR5000.O/M.QXD 1/28/03 7:21 AM INSTALLATION Unravel the AC cord and connect it to a conveniently located AC outlet having 120V and 60Hz only. The Clock Display will illuminate and “0:00” or “12:00” will blink in the window. NOTE: If the AC plug does not fit into a nonpolarized outlet, do not file or cut the wide blade.
DCR5000.O/M.QXD 1/28/03 7:21 AM OPERATION TO LISTEN TO THE RADIO Press the Radio On/Off button turn the unit on; the AM or FM indicator will light. Press the AM/FM Band button to select AM or FM. Adjust the volume using the Volume control Press the Radio On/Off button turn the unit off.
Page 10
DCR5000.O/M.QXD 1/28/03 7:21 AM OPERATION (CONTINUED) TO RECALL RADIO PRESETS To recall a Radio Preset, press the Radio Preset Up button repeatedly until the desired Radio Preset appears in the display. NOTE: Once a radio frequency is selected, the display will revert to the time display after 10 seconds.
Page 11
DCR5000.O/M.QXD 1/28/03 7:21 AM OPERATION (CONTINUED) TO SET OR RESET THE ALARM TIME With the unit off, press the Clock Set/Alarm Set button twice to set the alarm time; the Alarm On indicator and the display will blink. TO SET THE ALARM TO WAKE TO RADIO Set the alarm time as previously instructed.
DCR5000.O/M.QXD 1/28/03 7:21 AM OPERATION (CONTINUED) TO SET THE ALARM TO WAKE TO DISNEY ALARM MUSIC Set the alarm time as previously instructed. Press the Alarm On/Off button and the Alarm On and Radio (Alarm) indicators will light. NOTE: To avoid having the volume set too low that it cannot be heard when the alarm sounds, this unit will automatically set the volume to a...
DCR5000.O/M.QXD 1/28/03 7:21 AM OPERATION (CONTINUED) TO ACTIVATE THE SLEEP FUNCTION Tune the desired radio station as described on page 8. Press the Sleep button; the Sleep indicator will light and “10” will appear on the clock display, then release the button.
DCR5000.O/M.QXD 1/28/03 7:21 AM TROUBLESHOOTING GUIDE Should this unit exhibit a problem, check the following before seeking service: POSSIBLE SYMPTOM CAUSE GENERAL Power does AC line cord not not come on. plugged in. RADIO No sound. Radio On/Off button was not pressed. Volume control at minimum position.
Page 15
DCR5000.O/M.QXD 1/28/03 7:21 AM Page 14 For additional set-up or operating assistance, please visit our website at www.memorexelectronics.com or contact customer service at 1-877- DISNYCE (1-877-347-6923). Please keep all packaging material for at least 90 days in case you need to return this product to your place of purchase or Memcorp.
