Content Compliance Information.................. 1 Copyright Information ..................2 Product Registration ..................2 Precautions ...................... 3 System requirement ..................4 Installation instruction Installing drivers (for Windows 98 only) ............5 Connecting and downloading Connecting PC....................7 Removing USB device ..................7 Basic Operation Buttons and functions ..................
Page 3
Play Mode ..................... 14 Contrast ......................15 Backlight ....................... 15 Power set ....................... 16 Record set...................... 16 Language ....................... 17 Exit ........................ 17 Preview......................17 Delete function ....................18 Voice function....................18 About......................19 Exit ........................ 19 A-B Play Mode....................20 Lock function ....................
Compliance Information For U.S.A. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
To meet your future needs, and to receive any additional product information as it becomes available, please register your product on the Internet at: www.viewsonic.com. The ViewSonic Wizard CD-ROM also provides an opportunity for you to print the registration form, which you may mail or fax to ViewSonic. For Your Records...
Congratulations! Thank you for choosing ViewPoP Digital Audio player! Please read this User Guide carefully beforehand to ensure proper using and operation. Precaution To avoid possible traffic accidents To avoid possible damages to the player please do not use the player while walking, keep the player clean and away from places with driving, riding or operate other heat source, direct sunlight, dirts, high humidty...
Note: To avoid program failure when using the player as the removable disk, please follow the proper document management and operation method to save and export documents, and never disconnect the player from PC abruptly during downloading, uploading and formatting. Recommended minimum system requirement Pentium 133MHz or above, at least 64MB RAM Microsoft Window 98, ME, 2000, XP...
Connect the MP3 player to the USB interface of PC, and then insert the CD-ROM came with the system to the CD-ROM drive. Select “ViewSonic” installation folder, and then click “step up .exe”. The following image appears and is ready to install the program. Then, click "Next".
Page 13
After accepting the agreement and selecting the installation directory, the PC will finish the installation automatically. Click "Next" in each step until "Finished" appears. If the USB device can not display as illustrated above, please uninstall the USB driver from the system completely, and then reinstall again. 数码说明书之家—WWW.54GG.COM...
Connecting and downloading Connecting PC Before operation, please verify the player is turned off, and connect the PC and MP3 player using the provided USB cable. Use the USB interface to download MP3 music files from PC to the player. Data transmitting During data transmitting, please do not disconnect the player from PC.
Page 15
Click "OK" button. After the "Safe to Remove Hardware" window appears, the player can now be disconnected from PC safely. Never unplug the USB cable during data transmitting to avoid any failure to the Player; after data transmitting, please do not disconnect the player from PC until "Device now be safely removed"...
Basic Operation Buttons and functions 1) Microphone/ MIC 2) Menu button/ MENU / Last, Fast backward/ Next, Fast forward 3) Volume down/V- 4) Volume up/V+ /pause / Stop 6) USB Port 7) HOLD button 8) Earphone jack Screen instruction 数码说明书之家—WWW.54GG.COM...
Turn on/ off operation From power off mode, you can press the / button 2 seconds, the player will power on with the “ViewSonic” displays. The main menu appears with the "Playing Music" displayed on the screen. Prod the MENU...
How to use the MP3 player Playing MP3 files a) From MP3 standby mode, you can press the button to play MP3, during which you can press the / button pause, and press the button again to resume. Play standby Start Pause b) From play or pause mode, you can press the...
Voice function Playing voice a) From MP3 mode or voice standby mode, press the MENU button 2 seconds, it will enter the main menu. You can push the MENU button to select voice mode, and then press the MENU button to enter the voice play mode, and push the MENU button to select your desired voice file.
c) From voice standby or play mode, you can press the MENU button to select last or next voice file. d) From STOP status, you can push and hold the MENU button to effectively find and play your desired music. e) From Play mode, you can push and hold MENU button to fast backward or forward this music.
Bass Treble Play Mode From MP3 mode or voice standby mode, press the MENU button 2 seconds, it will enter the main menu. You can press the MENU button to select the setting menu, and press again to enter. Then you can press the MENU button to select the play mode, and press the...
Contrast From MP3 mode or voice standby mode, press the MENU button 2 seconds, it will enter the main menu. You can press the MENU button to select the setting menu, and press the button again to enter. Then press the MENU button to select the contrast setting mode, and press again to enter, and then press the...
Power set From MP3 mode or voice standby mode, press the MENU button 2 seconds, it will enter the main menu. You can press the MENU button to select the setting menu, and press again to enter, and then press the MENU button to select powerset mode, and press again to enter, and press the...
Language From MP3 mode or voice standby mode, press the MENU button 2 seconds, it will enter the main menu. You can push the MENU button to select the setting menu, and then press MENU button to enter the setting menu, then press the MENU button to select language setting and press again to enter.
Delete function From MP3 mode or voice standby mode, you can press the MENU button 2 seconds to enter the main menu, and then press the MENU button to select and enter the delete mode, and then press the MENU button to select the music to be deleted, and press the / button to confirm delete, after which you can press the MENU button to exit...
Recording Pause Stop About From MP3 mode or voice standby mode, press the MENU button 2 seconds, it will enter the main menu. You can push the MENU button to enter the "About" menu, and press MENU button to select "About" menu. You can view the total memory and free memory of this system, and then press the / button to return to the current mode.
A-B Play Mode From MP3 or voice play mode: a) Press MENU button to select start point A; a) Press MENU button to select end point B, MP3 will play between A-B. a) Press MENU C button again to cancel setting and resume playing MP3 or voice. Lock function Under any mode, you can push the HOLD switch in the direction of arrow, a lock icon will appear on the LCD, and all the buttons will be nonfunctional;...
Plug the Player into the USB interface of PC, relative icons appears on the LCD screen. The LCD screen may display relative icon during data transmitting. For software upgrading and formatting the removable disk, please refer to the website of ViewSonic. Folder function From MP3 mode or voice standby mode, you can push the MENU...
Troubleshooting Symptom Causes Solution No display after pressing the power The battery is out of power. Please charge in time or replace battery. button 1. Volume is too low, or without music in the player, or battery No sound during 1.
Page 30
The MP3 files currently are compressed with different compress individually rate and format, while this Player compressed Download the standard MP3 files again. supports the standard compressed MP3 files can MP3 only, please do not adopts layer not be played one or two compression.
電磁相容資訊 美國符合 本設備已通過測試,並符合 FCC 規則第 15 部分 B 級數位裝置的限制。這些限制旨在提供合理的保 護,以防在一般住宅環境繁造成有害干擾。本設備會產生、使用和發射無線電頻率能量,因此若沒 有依照指示安裝及使用,可能會對無線電通訊產生有害的干擾。然而,並不保證在特定安裝方式下 不會產生干擾。如果本設備對無線電或電視收訊產生有害干擾,( 可透過開、關設備判定),建議使 用者嘗試以下方法消除干擾: 重新調整或放置接收天線。 增加設備與無線接收設備的距離。 將本設備連接到與接收器不同的電源插座上。 請向經銷商或具有經驗的無線電/ 電視技術人員請求幫助。 加拿大符合 此項B級數位設備符合加拿大干擾源設備規範的所有要求。 Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada. 歐洲國家符合- CE 合格 本裝置符合依 92/31/EEC 及 93/68/EEC 第 5 條有關 「電磁相容性」 修訂的 EEC 指令 89/336/EEC,以及依...
安裝說明 爲 Windows 98 安裝驅動程式。(在 Windows ME 及以上版本不需要安裝驅動程式) 將 MP3 隨身聽與電腦的 USB 連接埠連接,將附贈的光碟放入 CD-ROM。 選擇“ViewSonic”安裝檔案,點擊“step up .exe”。電腦將出現以下圖片。並準備 安裝程式。點擊“下一步”。 数码说明书之家—WWW.54GG.COM...
Page 37
同意條約並選擇安裝路徑後,電腦將自動完成安裝程式。點擊“下一步”直到電腦 顯示“安裝完成”。 如果 USB 驅動器沒有按照上面所說的方式顯示,請移除所安裝的 USB 驅 動,重新安裝。 数码说明书之家—WWW.54GG.COM...
語音模式設定 播放語音 a) 在 MP3 播放模式或語音待機模式下,按下 MENU 鍵 2 秒進入主功能表設置,推動 MENU 鍵選擇語音模式,按下 MENU 鍵進入語音播放模式,推動 MENU 鍵 選擇您想播放的語音繁件。按 / 開始語音播放,再次按下 / 鍵將暫停播放,第 三次按下 / 鍵將繼續播放。再次按 MENU 鍵 2 秒返回主功能表設置。 語音播放待機 開始播放語音 b) 語音播放模式的選項有:正常模式、單曲循環、全部循環、隨機循環、全部隨機循 環。 正常模式 單曲循環 全部循環 隨機播放 隨機循環 c) 語音待機或播放模式下,按 MENU 鍵來選擇上一個或下一個語音繁件。 d) 在...
功能設定 音場模式設置 在播放模式或語音待機模式下,按下 MENU 鍵 2 秒進入主功能表,推動 MENU 鍵選擇設定功能表,按下 MENU 鍵進入設定功能表。推動 MENU 鍵選擇音場模式 設定。按下 MENU 鍵進入音效設定模式, 推動 MENU 鍵選擇音場設定模式。可 以選擇的模式有:正常、搖滾、爵士、古典、流行、低音、高音。按下 MENU 鍵儲 存剛選擇的音場模式。按 / 鍵返回當前模式。 正常 搖滾 爵士 古典 流行 低音 高音 播放模式設置 在 MP3 播放模式下,按下 MENU 鍵 2 秒進入主功能表,推動 MENU 鍵選擇設定 功能表,按下...
正常模式 單曲循環 全部循環 隨機播放 隨機循環 對比度設定 在 MP3 播放模式或語音待機模式下,按下 MENU 鍵 2 秒進入主功能表,推動 MENU 鍵選擇設定功能表,按下 MENU 鍵進入設定功能表。推動 MENU 鍵選 擇對比度設定模式,按下 MENU 鍵進入對比度模式,推動 MENU 鍵調節 LCD 對比度。按下 MENU 鍵儲存剛選擇的設定。按 / 鍵返回當前模式。 背光設定 在 MP3 播放模式或語音待機模式下,按下 MENU 鍵 2 秒進入主功能表, 推動 MENU 鍵選擇設定功能表,按下 MENU 鍵進入設定功能表。推動 MENU 鍵選 擇背光設定模式,按下...
自動關機設定 在 MP3 播放模式或語音待機模式下 , 按下 MENU 鍵 2 秒進入主功能表, 推動 MENU 鍵選擇設置功能表,按下 MENU 鍵進入設置功能表。推動 MENU 鍵選擇自動關 機模式,按下 MENU 進入自動關機模式。推動 MENU 鍵選擇自動關機時間。自 動關機時間的選項有: 2 分鐘、10 分鐘、30 分鐘、禁止。按下 MENU 鍵儲存剛剛 選擇的關機時間。按 / 鍵返回當前模式。 錄音頻率設定 在 MP3 播放模式或語音待機模式下 , 按下 MENU 鍵 2 秒進入主功能表, 推動 MENU 鍵選擇設定功能表,按下...
語言設置 在 MP3 播放模式或語音待機模式下,按下 MENU 鍵 2 秒進入主功能表, 推動 MENU 鍵選擇設定功能表,按下 MENU 鍵進入設定功能表,推動 MENU 鍵選擇語言設置,按下 MENU 鍵進入語言設置。語種有:英繁、繁繁簡繁、繁繁繁 繁、法繁、西班牙繁、丹麥繁、德繁、葡萄牙繁、義大利繁、荷蘭繁、芬蘭繁、瑞典 繁、波蘭繁。按下 MENU 鍵儲存剛剛選擇的語言。按 / 鍵返回當前模式。 退出 在 MP3 播放模式或語音待機模式下,選擇退出設置,功能表將返回上一級功能表。 音樂瀏覽 在 MP3 播放模式或語音待機模式下,按下 MENU 鍵 2 秒進入主功能表, 推動 MENU 鍵選擇瀏覽模式,按下 MENU 鍵開始瀏覽音樂。再按下 MENU 鍵 2 秒退出音樂瀏覽。按...
刪除繁件 在 MP3 播放模式或語音待機模式下,按下 MENU 鍵 2 秒進入主功能表,推動 MENU 鍵選擇刪除模式,按下 MENU 鍵進入刪除模式,推動 MENU 選擇要 刪除的音樂繁件,再按 / 鍵確定刪除。按 MENU 鍵退出設定。按 / 鍵返回 當前模式。 屬性爲唯讀的音樂繁件不可刪除! 錄音功能 在 MP3 播放模式或語音待機模式下,按下 MENU 鍵 2 秒進入主功能表,推動 MENU 鍵選擇錄音功能,按下 MENU 鍵進入錄音模式。按下 MENU 開始錄音,再次按下 MENU 鍵暫停錄音,第三次按下 MENU 鍵繼續錄音,再次按 MENU 鍵 2 秒 結束並保存錄音。按...
資料夾管理功能 MP3 播放模式或語音模式下,先按 MENU 鍵 2 秒進入主功能表設定,再次按 MENU 鍵進入資料夾功能設置。螢幕會顯示在根目錄的歌曲和資料夾推動 MENU 鍵可以找到你希望聽的歌曲和資料夾。 a) 選擇播放根目錄下歌曲: 推動 MENU 鍵可以找到你希望聽的歌曲。 按 MENU 鍵確認播放,退 回 MP3 播 放 界 面 。 b) 資料夾選擇和播放: 1. 推動 MENU 鍵找到相關繁件夾。按 MENU 進入繁件夾。然後按照 a) 步驟 操作,選擇歌曲。 2. 如果要選擇資料夾裏面的子目錄, 請重新操作 1。 3.
电磁相容信息 美国法律 依 FCC 规则的第十五章,本设备经测试,符合 B 级数码设备的限制标准。这些限制标准用于确认 电气设备不会对居室中安装的其它设备产生有害干扰。本设备会产生、使用和发射射频能量,因此 若没有依照指示安装及使用,可能会对无线电通讯产生有害的干扰。然而,这并不保证该设备在特 定安装过程中不会发生这种干扰。如果该设备对收音机或电视机产生有害的干扰( 这可以通过设备 的开、关来判定),用户可以尝试以下的方法消除干扰: 重新调整或放置接收天线。 增加设备与无线接收设备之间的间距。 将该设备连接到与无线设备不同的另一插座上。 洽询销售商或具有无线电/ 电视经验的技术人员请求帮助。 加拿大法律 此项B级数位设备符合加拿大干扰源设备规范的所有要求。 Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada. 欧洲国家- CE 达标 本装置遵守依 92/31/EEC 及 93/68/EEC 条款 5 有关 「电磁兼容性」 修订的 EEC 指令 89/336/EEC,以及依...
安装说明 为 Windows 98 安装驱动程序。(在 Windows ME 及以上版本不需要安装驱动程序) 将 MP3 播放机与在 PC 机的 USB 口连接,将附赠的光盘放入 CD-ROM。 选择“ViewSonic”安装文件夹,点击“step up .exe”。电脑将出现以下图片。并准备 安装程序。点击“下一步” 。 数码说明书之家—WWW.54GG.COM...
Page 59
同意条约并选择安装路径后,电脑将自动完成安装程序。点击“下一步”直到电脑 显示“安装完成” 。 如果 USB 驱动器没有按照上面所说的方式显示, 请卸载所安装的 USB 驱动, 重新安装。 数码说明书之家—WWW.54GG.COM...
连接与下载 与 PC 机连接 在操作前,请确认播放机电源已关闭,将附赠的 USB 连接线接头插入计算机,另外 一头连接到 MP3 播放机。 MP3 播放器连接到计算机 USB 端口下载 MP3 歌曲到 MP3 播放器。 数据传输中 注:本机最多存储 250 个 MP3 格式文件,最多存储 200 个 VOICE 格式文件。 在拷贝文件时,请不要强制中断本产品与计算机的 USB 连接。如果在档案 传输时,USB 连接被强制中断,当前正在传输的档案可能损坏。 移出 USB 端口装置 用鼠标双击任务栏上的图标安全移除硬件: 在安全移除硬件窗口画面上,选取“USB 大容量储存装置”项,然后点击“stop” 按钮。屏幕出现“ViewPop MP3 Digital Audio Player”窗口,如图所示。 数码说明书之家—WWW.54GG.COM...
Page 61
点击“OK”按钮。当屏幕出现“safe to Remove Hardware”窗口后,就可以从 PC 机 中安全分离。 在与 PC 机有数据传输时,请不要中途拔出 USB 连接线,这样可能会 对播放 机造成不良的后果;须数据传输完毕,PC 机出现“设备可以安全拔 出”,才可以与 PC 机正常分离;在进行 USB 功能操作时,其它按键功能无 效。 如果某些错误操作导致程序丢失或出现 I/O 错误提示, 不能开机,请参考疑难 排解部分。 数码说明书之家—WWW.54GG.COM...
语音模式设置 播放语音 在 MP3 播放模式或语音待机模式下,按下 MENU 键 2 秒进入主菜单设置, a) 推动 MENU 键选择语音模式,按下 MENU 键进入语音播放模式,推动 MENU 键选择您想播放的语音文件。按 / 开始语音播放,再次按下 / 键 将暂停播放,第三次按下 / 键将继续播放。再次按 MENU 键 2 秒返回主菜单 设置。 语音播放待机 开始播放语音 b) 语音播放模式的选项有:正常模式、单曲循环、全部循环、随机、随机循环。 正常模式 单曲循环 全部循环 随机 随机循环 c) 语音待机或播放模式下,按 MENU 键来选择上一个或下一个语音文件。 d) 在...
功能设置 音效模式设置 在播放模式或语音待机模式下,按下 MENU 键 2 秒进入主菜单,推动 MENU 键 选择设置菜单,按下 MENU 键进入设置菜单。推动 MENU 键选择音效模式设置。 按下 MENU 键进入音效设置模式, 推动 MENU 键选择音效设置模式。可以选择 的模式有:正常、摇滚、爵士、古典、流行、低音、高音。按下 MENU 键储存刚选 择的音效模式。按 / 键返回当前模式。 正常 摇滚 爵士 古典 流行 低音 高音 数码说明书之家—WWW.54GG.COM...
播放模式设置 在 MP3 播放模式下,按下 MENU 键 2 秒进入主菜单,推动 MENU 键选择设置菜 单,按下 MENU 键进入设置菜单。推动 MENU 键选择播放模式, 按下 MENU 键进入播放模式选择。推动 MENU 键选择播放模式,播放模式选项有:普通模式、 单曲循环、全部循环、随机循环、全部随机循环。按下 MENU 键储存刚刚选择的播 放模式。按 / 键返回当前模式。 正常模式 单曲循环 全部循环 随机 随机循环 对比度设置 在 MP3 播放模式或语音待机模式下, 按下 MENU 键 2 秒进入主菜单,推动 MENU 键选择设置菜单,按下...
背光设置 在 MP3 播放模式或语音待机模式下,按下 MENU 键 2 秒进入主菜单, 推动 MENU 键选择设置菜单,按下 MENU 键进入设置菜单。推动 MENU 键选择背 光设置模式,按下 MENU 键进入背光设置模式,推动 MENU 键选择背光设 置。背光设置的选项有:5 秒关闭、10 秒关闭、常开、关闭。按下 MENU 键储存刚 选择的设置。按 / 键返回当前模式。 自动关机设置 在 MP3 播放模式或语音待机模式下,按下 MENU 键 2 秒进入主菜单, 推动 MENU 键选择设置菜单,按下 MENU 键进入设置菜单。推动 MENU 键选择自动关机模 式,按下...
录音频率设置 在 MP3 播放模式或语音待机模式下,按下 MENU 键 2 秒进入主菜单, 推动 MENU 键选择设置菜单,按下 MENU 键进入设置菜单。推动 MENU 键选择录音频率设 置。 推动 MENU 键选择录音比特率。 录音频率的选项有: 8000HZ、 16000HZ、 32000HZ、 48000HZ。按下 MENU 键储存刚刚选择的录音频率。按 / 键返回当前模式。 语言设置 在 MP3 播放模式或语音待机模式下,按下 MENU 键 2 秒进入主菜单, 推动 MENU 键选择设置菜单,按下 MENU 键进入设置菜单,推动 MENU 键选择语言设置, 按下...
音乐浏览 在 MP3 播放模式或语音待机模式下,按下 MENU 键 2 秒进入主菜单, 推动 MENU 键选择浏览模式,按下 MENU 键开始浏览音乐。再按下 MENU 键 2 秒退出音乐浏览。按 / 键返回当前模式。 删除单个文件 在 MP3 播放模式或语音待机模式下, 按下 MENU 键 2 秒进入主菜单,推动 MENU 键选择删除模式,按下 MENU 键进入删除模式,推动 MENU 选择要删除的音乐 文件,再按 / 键确定删除。按 MENU 键退出设置。按 / 键返回当前模式。 属性为只读的音乐文件不可删除! 录音功能...
USB 模式 将播放器插到计算机 USB 端口,LCD 屏幕上显示相应图标。 任何时候只有在播放器与计算机之间有文件传输,LCD 屏幕显示相应图标。 软件的升级及可移动磁盘的格式化方法请登录优派公司网站。 文件夹功能 在 MP3 播放模式或语音模式下,先按 MENU 键 2 秒进入主菜单设置,再次按 MENU 键进入文件夹功能设置。屏幕会显示在根目录的歌曲和文件夹推动 MENU 键可以找到你希望听的歌曲和文件夹。 a) 选择播放根目录下歌曲: 推动 MENU 键可以找到你希望听的歌曲。 按 MENU 键确认播放, 按 / 退 回 MP3 播 放 界 面 。 b) 文件夹选择和播放: 1.
Page 76
