AT&T Digital Life SW-ATT-PAD2W Installation Instructions

Product Description
The AT&T model number SW-ATT-PAD2W is a proprietary 915MHz
wireless keypad that enables control of all system functions. The
keypad also features a built-in sounder that annunciates system
status information, alarms and troubles. They keypad sounds a
predefined "chirp" and "beep" sound when a button is pressed on the
keypad. For example, the system can be configured so that the
keypad chirps when an entry/exit door is opened and closed. The
keypad annunciates different sounds for fire and intrusion alarms.
Installing/Replacing Batteries
The keypad has four (4) AA batteries that provide twenty-four (24)
hour battery backup. The batteries can be replaced by opening the
battery compartment located on the rear of the unit.
Installing the Keypad
Connect the wires from the AC/DC power adapter to the terminals
on the back side of the keypad, as depicted in Figure 40. And install
four AA batteries. Plug the AC/DC power adapter into AC power
outlet. When powered up, it is ready to be discovered.
Figure 40: Keypad Connection to the AC/DC Adapter and
Installation of AA Batteries
Discovering and Registering the Keypad (Digital Life
Direct)
Follow these steps to discover and register the keypad using DLD:
Step 1. Power up the keypad.
Step 2. Access the "Devices" page.
SW‐ATT‐PAD2W RTL 41809
Step 3. Place the DLC in Discovery Mode (Initializing
Process)
Step 4. Enroll the keypad.
Installation Instructions
