#90443E
110-120V~60Hz, 12A at 68°F (20ºC)
WEBSITE WHERE IT WAS PURCHASED. PLEASE
303021236526_14.0x21.0cm_90443E_20N-OEM-381_美国规SPA主体说明书
Owner's Manual
Para la instrucción en español,
visite bestwaycorp.com/support
DO NOT RETURN THIS ITEM TO THE STORE OR
VISIT WWW.BESTWAYCORP.COM/SUPPORT
FOR QUESTIONS, OR FOR DEFECTIVE OR
WARRANTY CLAIMS.
303021236526
Advertisement
Table of Contents
Related Manuals for Coleman SaluSpa Havana AirJet 90443E
Summary of Contents for Coleman SaluSpa Havana AirJet 90443E
- Page 1 #90443E 110-120V~60Hz, 12A at 68°F (20ºC) Owner’s Manual Para la instrucción en español, visite bestwaycorp.com/support DO NOT RETURN THIS ITEM TO THE STORE OR WEBSITE WHERE IT WAS PURCHASED. PLEASE VISIT WWW.BESTWAYCORP.COM/SUPPORT FOR QUESTIONS, OR FOR DEFECTIVE OR WARRANTY CLAIMS. 303021236526 303021236526_14.0x21.0cm_90443E_20N-OEM-381_美国规SPA主体说明书...
- Page 2 CONTENTS 1. Warning ........4. Maintenance ......Filter Cartridge Maintenance 2. Installation ......Water Maintenance Air-Valve Adjustment Selected Location Draining the Spa GFCI Test Cleaning the Spa Assembly Deflation 3. Pump Operation ..... Spa Repair Control Panel 5. Troubleshooting ....Alarms WARNING IMPORTANT SAFETY INSTRUCTIONS...
- Page 3 between 100°F (38°C) and 104°F (40°C) are considered safe for a healthy adult. Lower water temperatures are recommended for young children and when spa use exceeds 10 minutes. b) Since excessive water temperatures have a high potential for causing fetal damage during the early months of pregnancy, pregnant or possibly pregnant women should limit spa water temperatures to100°F (38°C).
- Page 4 interference by one or more of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
- Page 5 NOTE: The warning label must be posted near your spa in a readable position during using your spa. 1. Take out the warning label from the accessory kit. 2. Carefully peel the warning label. 3. Affix the warning label. To order the warning label, please contact your local Bestway After Sales Service. IMPORTANT ! To reach 104°F (40°C), the heating duration required is base on the starting water temperature and ambient temperature, the data below is purely for reference.
- Page 6 SPECIFICATIONS 6.5A Increased Heat Approximately Capacity: 2-4 Adults Massaging Turbo Blower: Rate: 2-3ºF/h (1-1.5ºC/h) 11.3A at 110-120V AC, Water Capacity 177 gal. (669 L) Heat Element: Power Rate: 68ºF (20ºC) 12A at 68ºF (20ºC) (80%): Inflated Size: 71in. x 26in. Pump: 0.7A Circulation Working Pressure:...
- Page 7 INSTALLATION Selected Location IMPORTANT: Because of the combined weight of the SaluSpa, water, and users, it is extremely important that the base where the SaluSpa is installed is smooth, flat, level and capable of uniformly supporting the weight for the entire time the SaluSpa is installed (not on the carpet or other similar material).
- Page 8 1. Plug the GFCI into a power outlet, the indicator turns red. 2. Press the test button, the indicator turns off. 3. Press the reset button, the indicator turns red and the spa is ready for use. WARNING: The GFCI plug must be tested before each use to avoid risk of electric shock.
- Page 9 Assembly P6609ASS16 Inflate for 5 min. 3 seconds to unlock. Inflate for 2 min. To stop inflation. 303021236526_14.0x21.0cm_90443E_20N-OEM-381_美国规SPA主体说明书...
- Page 10 Hyperthermia occurs when the internal temperature of the body reaches a level several degrees above the normal body temperature of 37°C (98.6°F). The symptoms of hyperthermia include an increase in the internal temperature of the body, dizziness, lethargy, drowsiness, and fainting. The effects of hyperthermia include failure to perceive heat;...
- Page 11 LCD Display On/Off Button Temperature Adjustment Buttons Heat Button Massage System Button Water Filter Button IMPORTANT: If spa is turned off, the remote control will not work. Insert the spa plug, reset the GFCI, and then use the remote control. When the remote control is activated, the LCD display screen will stay on for about 15 seconds.
- Page 12 Alarms Causes Reasons Solutions The water flow sensors 1. The water flow sensor flags didn’t fall back 1. Unplug the plug gently, strike the side of the pump (but not violently), and work without pressing the into the correct position. plug it back in.
- Page 13 NOTE: We recommend changing your filter cartridges every week or, if the filter cartridges remain soiled and discolored, they should be replaced. Water Maintenance Keeping your spa water clean and chemically balanced is necessary. Simply cleaning the filter cartridge is not enough for proper maintenance, we recommend you use pool chemicals to maintain water chemistry and chlorine or bromine tablets (do not use granules) with the chemical dispenser.
- Page 14 Cleaning the spa Detergent residues and dissolved solids from bathing suits and chemicals may build up on the spa walls. Use soap and water to clean the walls and rinse thoroughly. NOTE: DO NOT use hard brushes or abrasive cleaners. DEFLATION P61726ASS18 P61727ASS18...
- Page 15 Problems Probable Causes Solutions Pump does not operate - Power failure - Check power source - GFCI broken - For assistance, please visit the support section on our website, www.bestwaycorp.com - Temperature set too low - Set to a higher temperature refer tosection pump operation Pump does not - Dirty Filter Cartridge - Clean/replace the filter cartridge referto section filter cartridge...
- Page 16 The product you have purchased comes accompanied by a limited warranty. Bestway stands behind our quality guarantee and ® assures, through a replacement warranty, your product will be free from manufacturer’s defects. The limited warranty is valid as follows: 360 days for the heater pump from the original date of purchase 180 days for the pool liner from the original data of purchase 30 days for hoses, fitting and accessory included in the package from the original date of purchase To enact a warranty claim, please contact your local Bestway...
