Kustom PH Series Manual

PH1012
SPECIFICATIONS
Power
Speaker
Tone Stack
Overdrive
Tube Preamp
Effects
Input/Outputs
Dimensions
mm
Inches
Weight
1
1) INPUT: This ¼" jack is for connecting your guitar to the amplifier.
2) GAIN: Adjusts the gain at the input of the amplifier. It is used
in conjunction with the Master Volume (6) to adjust the amount of
distortion and volume of your amp. For cleaner sounds, this control
should be set to lower settings and the Master set higher...for slight
breakup, these controls should be set in their middle ranges.
3) MAX DRIVE: Push this button IN for heavier distortion.
4) BASS: This passive tone control adjusts the low frequencies of
the amplifier. For a tighter low end, use the Bass EQ set to lower
settings. This is particularly helpful when using the amp at very
loud settings. *
5) TREBLE: This passive EQ adjusts the high frequency
equalization of the amplifier. *
Model PH1012
10 Watt
12" 4Ω 12W
Passive
Bass Treble
Yes
No
No
Aux/Headphone
WxDxH
395 x 220 x 360
15-⅝ x 8-⅝ x 13-¼
6.85 Kg
15.1 lbs.
3
2 4
PH
AMPS
PH2012R
PH2012R
20 Watt
12" 6Ω 24W
Passive
Bass Mid Treble
Yes
No
Spring Reverb
Aux/Headphone
WxDxH
395 x 220 x 360
15-⅝ x 8-⅝ x 13-¼
7.4 Kg
16.3 lbs.
5 6
6) MASTER VOLUME: This controls the overall volume of the
amplifier.
7) Line In: This is a 3.5mm stereo line input. It bypasses the
tone controls and feeds straight into the power amplifier. Use
the volume and tone controls on your external device to control
the audio signal.
8) Headphone Jack: This is a 3.5mm stereo output jack. When
used, it turns off the internal speaker.
It combines all inputs from your guitar and Line In for silent
practice.
9) On/Off Power—Provides AC power to the amplifier.
*More About Passive Tone Controls: The PH Amplifiers
use a true vintage-style Passive Tone Stack. This simple yet
highly effective design has become a favorite among guitarists
for decades. The equalization of the amplifier is adjusted as
follows: As the Treble is increased, the Bass automatically
decreases. Conversely, if the Treble is decreased, the Bass
automatically increases in frequency.
PHTUBE12
PHTUBE12
12 Watt
12" 6Ω 24W
Passive
Bass Treble
Yes
One 12AX7
No
Aux/Headphone
WxDxH
395 x 220 x 360
15-⅝ x 8-⅝ x 13-¼
7.6 Kg
16.7 lbs.
7 8
9
