- Page 1 Professional Mixing Controller OWNER'S MANUAL VESTAX CORPORATION VESTAX America VESTAX ( Europe ) Ltd.
-
Page 2: Important Safety Instructions
CAUTl0N：TO REDUCE THE RlSK OF ELECTRlC SHOCK REFER SERVlCING T0 QUALIFIED SERVlCE PERSONNEL The lighting flash with arrowhead symbol，within an equilateral triangle，is intended to alert the user to the presence of uninsulated“dangerous voltage”within the product's enclosure that may be of sufficient magnitude to consitute a risk of electric shock to persons．... - Page 3 CONGRATULATIONS ！ Thank you for purchasing the VESTAX PMC - 270A，Professional Mixing Controller．As The top of the line, the PMC-270A is a high specification mixer designed to meet the most professional requirements of the Dance Music DJs. Please read this owner's manual carefully before you start to use your mixer, so that you will fully understand all of the special features and enjoy the full use of the product.
-
Page 4: Top Panel
+12dB -12dB +12dB -16dB +16dB -16dB +16dB EFFECT EFFECT POST POST SIGNAL SIGNAL TOP PANEL PROGRAM INPUT SECTION PMC-270A FESSIONAL MIXING CONTROLLER PGM 2 MASTER INPUT PHONO 3 LINE 6 LINE 5 TRIM POWER POWER EFFECT SEND -16dB +16dB RETURN... - Page 5 PROGRAM PROGRAM INPUT SECTION INPUT SECTION 1. INPUT SELECTOR Used to select input (2 line or 1 phono) to be sent to each PGM channel. PGM 1 2. TRIM CONTROL INPUT Adjusts the Input level of each channel. Set INPUT FADER to 7- 8position. adjust PHONO 1 LINE 2 TRIM so that the INPUT LEVEL METER shows about 0dB.
- Page 6 MICROPHONE, SUB INPUT SECTION MICROPHONE, SUB INPUT SECTION 9. LINE INPUT JACK(LINE4) LINE 4 IN 10. MIC INPUT JACK(MIC1,2) 11. MIC LEVEL 12. MIC EQUALIZER(HI,LOW) MIC-1 MIC-2 13. EFFECT SWITCH MIC-1 14. CUE SWITCH MIC-2 MASTER SECTION 15. MASTER OUT LEVEL METER 16.
-
Page 7: Rear Panel
30. OUTPUT JACK(1/4inch PHONE JACK, RCA PIN JACK) Connect to the input of power amplifier. 31. EFFECT SEND JACK Connect the SEND jacks to the input of an external effector unit(Delay,Reverb etc) PMC-270A MADE IN CHINA EFFECT PGM 2 SEND... -
Page 8: Specification
●NOMINAL INPUT LEVEL／IMPEDANCE PHONO −42dB／470k LINE −10dB／47k −42dB／303k EFFECT RCV −10dB／47k ●RATED OUTPUT LEVEL／IMPEDANCE LINE OUT −4dB／10KΩ REC OUT −10dB／10kΩ EFFECT SEND −10dB／10kΩ Vestax Corporation ●FREQUENCY RESPONSE 20Hz∼20kHz (＋0，−3dB) ●S/N RATIO −80dB ●DIMENSION ( WXHXD ) W290mmX H80mm X D380mm ●WEIGHT...
