Plug-in hybrid system
1
Charging operation
2
3
The quick guide is not intended as a substitute for your "OWNER'S
MANUAL". We strongly encourage you to review the "OWNER'S MANUAL"
and supplementary manuals so you will have a better understanding of your
vehicle's capabilities and limitations.
Depending on specifications, the vehicle shown in the illustration may differ
from your vehicle in terms of equipment.
RAV4 PRIME_QG_OM42B93U_(U)
Advertisement
Table of Contents
Related Manuals for Toyota RAV4 Prime
Summary of Contents for Toyota RAV4 Prime
- Page 1 Plug-in hybrid system Charging operation Things you must know The quick guide is not intended as a substitute for your “OWNER’S MANUAL”. We strongly encourage you to review the “OWNER’S MANUAL” and supplementary manuals so you will have a better understanding of your vehicle’s capabilities and limitations.
- Page 2 1. Plug-in hybrid system Plug-in hybrid system features The plug-in hybrid system is a system excellent in both econom- ical efficiency of electric vehicles and practicality of hybrid vehi- cles. ● EV driving can be performed using electricity charged from an external power source.
- Page 3 1. Plug-in hybrid system Types of charging methods Charging from an external power source ■ This is a charging method used when charging from an AC outlet (120 V) with the AC charging cable equipped to the vehicle or charging at a public charging station. The charging start time (or departure time) and day can be set to carry out charging using the charging schedule at the desired date and time.
- Page 4 1. Plug-in hybrid system Plug-in hybrid system operation mode ■ EV mode When a sufficient amount of electricity is remaining after charging, EV driving is per- formed using electricity stored in the hybrid battery (traction battery). When in EV mode, the EV drive mode indicator illuminates.
- Page 5 1. Plug-in hybrid system HV mode ■ When in HV mode, the vehicle is driven using both the gaso- line engine and electric motor. • If electricity needed for EV driving in EV mode or AUTO EV/HV mode is not remain- ing, the operation mode will be automatically switched to HV mode.
- Page 6 1. Plug-in hybrid system Plug-in hybrid system operation mode selection switches The plug-in hybrid system operation modes can be switched using the switches. Switching the plug-in hybrid system operation modes ■ Press the AUTO EV/HV mode switch or EV/HV mode selection switch to change modes as the following table shows.
- Page 7 1. Plug-in hybrid system Switching to the hybrid battery (traction battery) charge mode ■ Press and hold the EV/HV mode selection switch. Take your hand off the switch once the hybrid battery charge mode indicator starts to blink. The hybrid battery charge mode indicator illuminates when the switch to hybrid battery (traction battery) charge mode is com-...
- Page 8 1. Plug-in hybrid system ■ Hybrid battery (traction battery) charge mode ● The following may occur to protect the system, etc. • Cannot switch to hybrid battery (traction battery) charge mode or cannot cancel it • Gasoline engine does not start or stops even after switching to hybrid bat- tery (traction battery) charge mode ●...
- Page 9 2. Charging operation Charging equipment Charging equipment and names AC charging inlet Charging port lid AC charging inlet light AC charging cable Charging indicator Charging port AC charging inlet cap RAV4 PRIME_QG_OM42B93U_(U)
- Page 10 2. Charging operation AC charging cable The names of each part of the AC charging cable ■ Charging connector Power indicator Latch release button Charging indicator Plug Error warning indicator Plug-cord CCID (Charging Circuit Inter- rupting Device) RAV4 PRIME_QG_OM42B93U_(U)
- Page 11 2. Charging operation Safety functions ■ The CCID (Charging Circuit Interrupting Device) has the following safety features. ● Electrical leakage detection function If an electrical leakage is detected during charging, the power source will be automatically interrupted, thus preventing fires or electrical shocks caused by electrical leakage.
- Page 12 2. Charging operation WARNING ■ Power sources precautions Observe the following precautions. If you do not follow them, fire, electrical shock or damage may occur, possi- bly resulting in death or serious injury. ● Connect to an AC 120 V outlet (NEMA 5-15R) with a Ground-Fault Circuit- Interrupter (GFCI) and supplied by a circuit breaker per your local code.
- Page 13 2. Charging operation Opening and closing the charging port lid Opening the charging port lid ■ Press the central rear edge of the charging port lid (the loca- tion shown in the illustration) with the doors unlocked. Push and take your hand away to slightly open the charging port lid.
- Page 14 2. Charging operation How to charge Charging precautions This vehicle has been designed to allow charging from an external power source using a AC charging cable for exclusive use with stan- dard household AC outlets. However, the vehicle differs greatly from standard household electri- cal goods in the following ways, and incorrect usage could cause fire or electric shock, possibly leading to death or serious injury.
- Page 15 2. Charging operation Confirm the following before charging Before charging, always check the following items. ● The parking brake is applied. ● Lights such as the headlights, emergency flashers and interior lights etc. are turned off. If these light switches are turned on, then these features will consume electricity, and charging time will increase.
- Page 16 2. Charging operation When charging Prepare the AC charging cable. Insert the AC charging cable into the outlet of the external power source. Make sure to hold the body of the plug and insert it firmly into the out- let. Check that the power indicator on the CCID (Charging Circuit Inter- rupting Device) is illuminated.
- Page 17 2. Charging operation Remove the charging connec- tor cap and secure it to the cable. Insert the charging connector into the AC charging inlet. Align the guide position on the bot- tom of the charging connector, and push charging connector straight into the AC charging inlet as far as possible.
- Page 18 2. Charging operation ■ During charging ● The charging starting time may differ depending on the state of the vehicle, but this does not indicate a malfunction. ● Cooling fan sounds may be heard from near the rear seat. ● During charging, sounds may be heard from near the hybrid battery (traction battery) in accordance with the operation of the air conditioning system or “Battery Cooler”.
- Page 19 WARNING ■ AC charging inlet Do not disassemble, repair or modify the AC charging inlet. Doing so may lead to unforeseen accidents or serious injury. When the AC charging inlet needs to be repaired, consult your Toyota dealer. RAV4 PRIME_QG_OM42B93U_(U)
- Page 20 2. Charging operation WARNING ■ When charging Observe the following precautions. Failure to do so may cause an unexpected accident, resulting in death or serious injury. ● Connect to a power source suitable for charging. ● Check that the AC charging cable, plug and outlet are free of foreign mat- ter.
- Page 21 ● Do not disassemble, repair or modify the onboard traction battery charger. When the onboard traction battery charger needs to be repaired, consult your Toyota dealer. RAV4 PRIME_QG_OM42B93U_(U)
- Page 22 2. Charging operation NOTICE ■ When using the AC charging cable and related parts To prevent damage to the AC charging cable and related parts, observe the following precautions. ● When interrupting or canceling charging, remove the charging connector before removing the plug. ●...
- Page 23 2. Charging operation NOTICE ■ Using private power generator Do not use private power generators as a power source for charging. Doing so may make charging unstable, the voltage may be insufficient, and the error warning indicator on the CCID (Charging Circuit Interrupting Device) of the AC charging cable may flash.
- Page 24 2. Charging operation Using the charging schedule function Charging schedule function Charging can be carried out at the desired time by registering the charging schedule. When registering the charging schedule, the following settings can be changed. ● Select the charging mode (“Start”/“Departure”) ●...
- Page 25 2. Charging operation Registering the charging schedule ■ Press of the meter control switches to select Press of the meter control switches to select “ Vehicle Settings ”, and then press and hold Press of the meter control switches to select “Charging Settings”, and then press The “Charging Settings”...
- Page 26 2. Charging operation Changing the registered charging schedules ■ The registered charging schedules can be modified or deleted. Perform step of the “Registering charging schedule” procedure and dis- play “Scheduled Events” screen. A list of the registered charging schedule will be displayed. Press of the meter control switches to select the...
- Page 27 2. Charging operation Setting operations on the audio system screen (vehicles with Premium Audio) Setting operations related to the charging schedule are performed on the “Charging Schedule” screen. Displaying the “Charging Schedule” screen ■ Press the “MENU” button, then select “Info” and “Charging Sched- ule”.
- Page 28 2. Charging operation “Climate Prep” When the charging mode is set to “Departure”, the “Climate Prep” is dis- played. To operate the air conditioning system, press the “Climate Prep” button to set the function to on. Each time the button is pressed, the function switches between on and off.
- Page 29 2. Charging operation Charging tips Checking information related to charging Information related to charging is displayed and can be checked on the multi-information display. While charging ■ When any door is opened during charging, the current charging condition and approxi- mate time remaining...
- Page 30 Remove the plug from the outlet before inspecting it. If any abnormalities are found in the AC charging cable as a result of the inspection, immedi- ately stop use and consult your Toyota dealer. ■ Maintaining the AC charging cable When the AC charging cable is dirty, first remove the dirt with a hard, wringed cloth, and then wipe the cable with a dry cloth.
- Page 31 2. Charging operation Using the “My Room Mode” When the AC charging cable is connected to the vehicle, electri- cal components such as the air conditioning system or audio system can be used using the external power source. Starting My Room Mode Connect the AC charging cable to the vehicle and start charging Turn the power switch on during charging The setting screen of My Room Mode is displayed automatically on the...
- Page 32 3. Things you must know Things you must know ■ Regenerative braking In the following situations, kinetic energy is converted to electric energy and deceleration force can be obtained in conjunction with the recharging of the hybrid battery (traction battery). ●...
- Page 33 Do not carry large amounts of water such as water cooler bottles in the vehicle. If water spills onto the DC/DC converter, the converter may be damaged. Have the vehicle inspected by your Toyota dealer. ● A filter is installed to the air intake vent. When the filter remains noticeably dirty even after cleaning the air intake vent, filter cleaning or replacement is recommended.
- Page 34 3. Things you must know NOTICE ■ Notice about fuel ● For plug-in hybrid vehicles, fuel may remain in the tank for a long time and undergo changes in quality depending on the how the vehicle is used. Refuel at least 5.3 gal.(20 L, 4.4 Imp.gal.) of fuel every 12 months (refuel a total of at least 5.3 gal.
- Page 35 3. Things you must know RAV4 PRIME_QG_OM42B93U_(U)
- Page 36 3. Things you must know RAV4 PRIME_QG_OM42B93U_(U)
