- Page 3 DIMENSIONS 49.5 Unit : mm Mounting on the EIA Standard 19-inch Rack When mounting on top of another unit, remove the feet at the When the rack-mount fixtures are not required, remove the base of the unit. (These can be removed easily by pulling out screws on the side, and remove the fixtures.
-
Page 4: Overall Block Diagram
BLOCK DIAGRAM OVERALL BLOCK DIAGRAM INPUT 1 CLIP LEVEL POWER AMP OUTPUT 1 PRE AMP – MONO + – BAL/UNBAL INPUT – LEVEL THERMAL SENSOR INPUT 2 CLIP PROTECTION CIRCUITS OPERATION PROTECTION LEVEL POWER AMP OUTPUT 2 PRE AMP – MONO –... -
Page 5: Location And Functions Of Parts
ATT-CH1 ATT-CH2 CLIP CLIP POWER 2CH POWER AMPLIFIER SRP-P50 4CLIP indicators 1 POWER switch and Pilot lamp When pressed, the power turns ON and the pilot lamp lights up. The lamp turns from red to green when the speaker relay operates. -
Page 6: Rear Panel
LOCATION AND FUNCTIONS OF PARTS REAR PANEL 5INPUT terminals 6OPERATION switch UNBALANCED STEREO 0dBs 0dBs (STACKING) MONO UNBAL UNBAL LEVEL LEVEL OPERATION CH2 INPUT CH1 INPUT(MONO) 7INPUT LEVEL selector switches 8BAL/UNBAL selector switches 5 INPUT terminals BAL/UNBAL CH1 INPUT (MONO)/CH2 INPUT Inputs signals to the unit from the mixer, AV equipment, XLR connector Phono jack... - Page 7 9SPEAKER OUTPUT terminals SPEAKERS MONO AC INPUT 7 INPUT LEVEL selector switches 9 Speaker output terminals Switch according to the reference output level of the For connecting speakers. Connect the (+) of the speakers to equipment connected. the red terminal, and the (–) of the speakers to the black 0 dBu : For professional audio equipment, etc.
-
Page 9: Troubleshooting Guide
TROUBLESHOOTING GUIDE The lamp does not light up and no sound is produced even Is the AC power cord disconnected? when the POWER switch is pressed • Are the speakers connected properly? The pilot lamp is ON, but no sound •... - Page 10 Printed in Japan...
