Summary of Contents for Sylvania Roadsight Stealth

Page 1 R O A D S I G H T Dash Camera Caméra-témoin de circulation Cámara Delantera...
Page 2 WARNING The Dash Cam must not be fitted in a position which obscures the driver’s view of the road ahead. Depending on the country of use, recordings made with this device may be subject to Data Protection Laws. Ensure these are complied with. If the dash cam is to be used in a commercial environment e.g.
Page 3: Before You Begin
BEFORE YOU BEGIN If you haven’t already downloaded the app, do so now to get the most from your dash camera. Download the app by searching for SYLVANIA CONNECT in the App Store (iPhone) or Google Play (Android). Open the app, follow the setup process shown...
Page 4: Package Contents
PACKAGE CONTENTS Dash Cam Quick Start Guide Magnetic Mount USB Charging Cable Trim Removal Tool Window Sticker SD Card RECORDING GRABANDO NOUS ENREGISTRONS...
Page 5 ATTENTION! Choose the installation location in advance, as the adhesive tape on the mount is of single use. Ensure glass is dirt, dust and grease free. Warm adhesive pad part of mount in hands to ensure strong adhesion to glass. Once mount has been positioned connect dash camera to the magnetic mount.
Page 6 To power the device and charge the battery, use only the power adapter included. Connect the power cable to the mount, and then plug the USB charger into the vehicles 12v power socket. When the vehicle’s engine starts, the device turns on automatically.
Page 7: Installing Microsd Card
INSTALLING microSD CARD Before installing a memory card, make sure the device is turned off. Insert the memory card until it clicks into place. Removing a card: press the card slightly and then remove it from the slot. WARNING! Do not apply excessive force when inserting a memory card to avoid damage to the device.
Page 8: Turning On/Off
TURNING ON / OFF • When the vehicle ignition is turned ON the dash cam turns on automatically. • To turn the device on manually, press the power button. • To turn the device off press and hold the power button for approx. 3 seconds.
Page 9 CONNECTING TO MOBILE Your camera automatically broadcasts a Wi-Fi network. Settings Wi-Fi Open your phone’s Settings. Wi-Fi Tap on Wi-Fi or Connections. CHOOSE A NETWORK... Select the dash camera SAMPLE_NETWORK hotspot and enter the DashcamStealth password “12345678”. SAMPLE_NETWORK You are now connected to SAMPLE_NETWORK your device.
Page 10: Adjusting Viewing Angle
ADJUSTING VIEWING ANGLE ATTENTION! Adjusting the viewing angle can only be done along the vertical axis, so be sure to position the device correctly on the windshield along the horizontal axis as close as possible to the windshield’s center. While pulling or pushing the device in the holder, ensure that the camera captures the image in proportions of 30% sky / 70% road.
Page 11: Recording Modes
RECORDING MODES Select different recording modes from the dropdown menus. DEFAULT ECONOMY RACE- SCENIC COMMUTER SOCIAL LANDSCAPE MEDIA RESOLUTION HIGH HIGH HIGH HIGH HIGH SNAPSHOT HIGH HIGH HIGH HIGH LOOP 3 MIN 3 MIN 5 MIN 5 MIN 3 MIN 3 MIN RECORDING G-SENSOR...
Page 12: Menu Settings
MENU SETTINGS To access the Menu settings, press the “Settings” button on the main menu. Video Quality: Select required option (the highest option provides the optimum viewing performance). Image Resolution: 1-12 Megapixels Loop Recording: 1, 3, or 5 minutes Date Stamp: OFF / ON Record Audio: OFF / ON Parking Monitor: OFF / ON G-sensor: OFF / LOW / MEDIUM / HIGH...
Page 13: Emergency Recording
EMERGENCY RECORDING Emergency recording is to protect the current video ﬁle from being overwritten and deleted. Emergency recording is activated automatically when the G-sensor triggers (sudden acceleration / deceleration), or at point of collision. Emergency recording is locked automatically to avoid erasing during loop recording.
Page 14 RECORDING PLAYBACK To access the playback menu, press the album button on the main screen. Video & Image Menu • Select either Videos or Images tiles to view.
Page 15: Video Menu
VIDEO MENU Short-press each video file once to get into the playback menu. Press and hold each video file for 3 seconds to access the video’s sub-menu. From there, lock, download, share, or delete the selected video.
Page 16: Image Menu
IMAGE MENU Short-press each image file once to get into the playback menu. Press and hold each image file for 3 seconds to access the video’s sub-menu. From there, lock, download, share, or delete the selected image.
Page 17 TIPS MENU To access the Tips Menu, press the “Tips” button on the main menu.
Page 18 FAQs MENU To access the FAQs Menu, press the dropdown menu and select FAQs. Swipe up or down to view all common frequently asked questions.
Page 19 INSTALLATION GUIDE MENU To access the Installation Guide Menu, press the dropdown menu and select Installation Guide. Another dropdown menu will appear. Select the dash cam being used from the dropdown menu.
Page 20: Customer Service Help
CUSTOMER SERVICE HELP Have an issue? Click the question mark in the top left corner of the main menu.
Page 21: Blurred Image
FAILURE TO PHOTOGRAPH/RECORD VIDEO Check if there is enough free space on the micro SD card. RECORDING HAS STOPPED Too many video ﬁles stored. Only use at least class 10 U1 high-speed micro SD cards by proven manufacturers. When you try to view a photo/play a video ﬁle, the “wrong ﬁle” message appears. File writing failure due to micro SD card ﬁle system error.
Page 22 HANG UP (NO IMAGE, NO BUTTON RESPONSE) Press the RESET button to reboot the device.
Page 23: Updating Firmware
UPDATING FIRMWARE Download the ﬁrmware ﬁle at www.sylvania-automotive.com/firmware and extract the ﬁle from the archive. Format the memory card and transfer the extracted ﬁle to the micro SD memory card. Insert the memory card with the downloaded ﬁle into the dash cam slot.
Page 24 FEATURES STEALTH 1440P 140° 128GB 20 HRS Greatest Image Full HD at 30 FPS Field of View Memory Size* Record Quality Time** 1296P 130° 64GB 12 HRS Most Features Full HD at 30 FPS Field of View Memory Size* Record Time** PLUS 1080P 120°...
Page 25: Power Requirements
POWER REQUIREMENTS ATTENTION! Once there is no external power input, the battery cannot support recording for a long time, please make sure power supply is connected when recording . Input voltage: 5VDC, 1.5A Charging input voltage: 12-24VDC Mini USB Connection for Power OPERATING TEMPERATURES (all models) Storage temperature: -4˚...
Page 26 PLEASE RECYCLE YOUR SPENT BATTERIES Batteries should not be disposed of in unsorted municipal waste, but separately collected to facilitate the correct treatment and recycling of the substances they contain. The recycling of batteries ensures the recovery of these valuable materials and prevents any potentially harmful effects upon both the environment and human health.
