DSC WS4920 Installation Instructions Manual

V1.0
Hide thumbs Also See for WS4920:
Table of Contents

Advertisement

Quick Links

WS4920 v1.0
Installation Instructions, Instructions d'installation, Instrucciones de
Instalación, Instruções de Instalação, Istruzioni di installazione
NOTE: Use these instructions in conjunction with the installation manual of the alarm panel with which this
equipment is intended to be used.
WARNING: READ and SAVE These Instructions! Follow All WARNINGS AND INSTRUCTIONS specified
within this document and/or on the equipment.

Advertisement

Table of Contents
loading

Related Manuals for DSC WS4920

Summary of Contents for DSC WS4920

  • Page 1 WS4920 v1.0 Installation Instructions, Instructions d’installation, Instrucciones de Instalación, Instruções de Instalação, Istruzioni di installazione NOTE: Use these instructions in conjunction with the installation manual of the alarm panel with which this equipment is intended to be used. WARNING: READ and SAVE These Instructions! Follow All WARNINGS AND INSTRUCTIONS specified...
  • Page 2 SAFETY INSTRUCTIONS for WS4920 WIRELESS REPEATER IMPORTANT: This equipment, WS4920 WIRELESS REPEATER 1.0, shall be installed and used within an environment that provides the pollution degree max 2 and overvoltages category II NON HAZARDOUS LOCATIONS, indoor only. The equipment is FIXED and DIRECT PLUG IN powered from the mains;...
  • Page 3 Table of Contents/ Table des matières/ Índice/ Indice dei contenuti Installation Instructions.....................2 Instructions d’installation ..................10 Instrucciones de Instalación..................22 Instruções de Instalação ..................34 Istruzioni di installazione..................46 The WS4920 is compatible with the following DSC wireless devices: Door/ Window Contact Alarm Panel Wireless Receiver WS4945 PC1616/PC1832/PC1864...

  • Page 4: Specifications

    WS4945CB , WLS912L-433, WS4939. The repeater shall be used in conjunction with Wireless Repeater Model RF5132-433 and Alarm Control Panel models: PC1864, PC1832 or PC1616. WS4920 is UL listed for Residential Fire, Residential Burglary and Commercial Burglary applications in accordance with the following standards: •...

  • Page 5: Controls And Indicators

    Each enrolled WS4920 occupies a zone slot. The WS4920 does not increase the number of supported wireless zones. This is determined by the control panel’s wireless receiver. Only zones requiring repeat functionality need to be enrolled on the WS4920. Ensure these zones are enrolled on both the WS4920 and the receiver/control panel.

  • Page 6: Step 2: Connecting Power

    • Ideal location is mid-way between the wireless transmitter and receiver. The minimum distance between the WS4920 and the receiver should be no less than 1 meter (3.28 feet) Do not permanently mount the WS4920 until it has been placement tested. Temporarily mount the unit using tape or other non-permanent, non-marking method.
  • Page 7 Connector Terminals To connect the AC adaptor: 1. Run AC wire through channel on back of WS4920 and pass through hole in enclosure. Figure 5: Wire Routing 2. Connect AC wires to terminals on PC board (see Figure 4). 3. Route wire around retaining bracket to secure.

  • Page 8: Step 5: Placement Testing The Ws4920

    WS4920. The “Mode Exited” (3 beeps) tone sounds. Step 4: Enrolling the WS4920 with the Alarm Panel The WS4920 has a six-digit electronic serial number (ESN) that must be input to the alarm panel during enrollment. To quick enroll the WS4920 (available on selected alarm panels): 1.

  • Page 9: Step 6: Quick Enroll/Placement Testing Devices

    Step 6: Quick Enroll/Placement Testing Devices Up to 164 1-way wireless devices can be enrolled on the WS4920. During the first 4 hours of power up, the WS4920 can be placed into Enroll/Placement Test modes. After the 4 hour time-out, access to these modes is denied and the unit must be powered up again to enter Enroll/Placement mode.

  • Page 10: Step 7: Mounting The Ws4920

    • If “Bad Zone Placement” (3 loud beeps) tone sounds, reposition device and trip zone again. Continue until “Good Zone Placement” tone (1 beep) sounds. 3. To exit, press Programming button again for 1 second or place cover back on the WS4920. “Mode Exited” (3 beeps) tone sounds.
