- Page 1 INSTALLATION GUIDE FOR ALL CABINETRY...
- Page 2 BEFORE proceeding with installation, please check goods carefully. If goods are incorrect, faulty or damaged, DO NOT proceed with installation and contact Timberline immediately. No claims for damages/defects will be accepted after installation. Ensure Your Wall Is Flat & Plumb Before starting, check that your wall is plumb and flat.
- Page 3 Silver Collection Steel Drawer Adjustment | Up or Down Loosen the centre Turn bottom screw Tighten centre screw. to move drawer screw. front up or down. Steel Drawer Adjustment | Left or Right Loosen two drawer front Slide drawer front left or...
- Page 4 Loosen two bracket screws to Use the back screw for in or out To remove door (if required) right adjustment slide door up or down. Tighten adjustment pull the clip at the back of each screws. hinge. T: 1800 642 162 www.timberline.com.au...
