REVERSING THE DOOR

Depending upon the location of the unit, it may be desirable to change
the side on which the door is mounted.
On Combo Models 29A and 29FF (built-in installations only),
changing the door mounting to the left side may interfere
with ice bucket removal. See BUILT-IN INSTALLATION sec-
tion for clearance requirements.
To reverse the door mounting on Models SP18, BI-15, BI-95, BI-98,
15R, 29AD, 29R, Combo 29A, and Combo 29FF, perform the
following:
1. Remove grill (1 screw). See
Figure 13.
2. Remove top hinge from cabinet
(3 screws). See Figure 14.
Hold door to keep it from
falling.
REMOVE SCREW
Figure 13
3. Lift the door off the bottom hinge.
4. Remove bottom hinge from cabinet (2 screws) (see Figure 15).
Remove screws on opposite side of cabinet (see Figure 16). Note
that there may be a nut behind one or both screws on either side.
5. Install hinge on opposite side, bottom of cabinet (see Figure 17).
Replace nut on back side where installed. Align hinge outer edge
with cabinet before tightening screws.
NOTE
UL116
11
Figure 14
UL109
