ADC OmniReach Indoor Fiber Distribution Terminal Features And Benefits

OmniReach
Indoor Fiber Distribution Terminal

Product Description

ADC's OmniReach™ Indoor Fiber Distribution Terminal (iFDT) provides Multiple Dwelling Unit
(MDU) applications with a compact and secure family of enclosures by connecting fiber cables at
MDUs. The IFDT products utilize a rugged double-hinged design that effectively isolates the splicing
and cable termination in the rear compartment from the jumper interconnection in the front
compartment. Separating the cable splicing and termination into a layered configuration provides
a space efficient and craft friendly interface unit. The layered IFDT staggered interconnection
field provides ease of access to all connections. The IFDT enclosure provides standard SC-APC
connections and parking adapters for locating the connectorized pigtails prior to deployment.

Features and Benefits

• Integrated splice tray offers flexible splice management for individual or mass splicing
• Sealed enclosure protect fibers from dust, water spray, insects and other contaminants
• Dual-hinged design ensures separation of owner/client network segments
• NEMA-12 Rated
• Tested to GR-2898-CORE
• Front and rear layer maximizes wall space utilization for both splicing and interconnect
• Robust steel construction protects fibers against damage and ensures network reliability
• Slotted cable entrance ports allow for rapid cable installation and pass-through capability
• Cable management and routing limits bend radius and adds strain relief
• 216-Tool (can wrench), key lock or padlock offers flexible security options
