IBM TORONTO-4.5 PLANAR Wiring Diagrams
  1. Manuals
  2. Brands
  3. IBM Manuals
  4. Motherboard
  5. TORONTO-4.5 PLANAR
  6. Wiring diagrams
IBM TORONTO-4.5 PLANAR Wiring Diagrams

IBM TORONTO-4.5 PLANAR Wiring Diagrams

Hide thumbs

Advertisement

Quick Links

Download this manual
A
B
C
9
TORONTO-4.5 PLANAR
VER 0.86
8
1. TITLE PAGE
2. EC HISTORY
3. CPU (1/3)
7
4. CPU (2/3)
5. CPU (3/3)
6. DECAP FOR VCCCPU1R2B
7. CAPS FOR VCCCPUCORE
8. GMCH3-M(1/3):HOST I/F
9. GMCH3-M(2/3):MEMORY
6
10. GMCH3-M(3/3):AGP/HUB
11. REF VOL & DECAPS
12. DIMM CARD CONNECTOR
13. CLOCK GEN(C9827)
14. ICH3-M(1/3)
5
15. ICH3-M(2/3)
16. ICH3-M(3/3)
17. HDD I/F CONNECTOR
18. USB I/F
19. FWH,RTC BAT.
20. H8S/2169A
4
21. KEYBOARD , PS/2
22. MISC G/A (PMH-2)
23. POWER ON LOGIC
24. SUPER I/O PC87392
25. SERIAL I/F
3
26. (BLANK)
27. EXT CRT I/F
28. CARD BUS PCI1420GHK(1/2)
29. CARD BUS PCI1420GHK(2/2)
30. CARD BUS POWER CTRL
31. CARD BUS SLOT
2
32. AUDIO CS4299
33. AUDIO MISC
34. AUDIO INT MIC
35. AUDIO CONNECTOR
36. AUDIO EXT MIC I/F
1
37. AUDIO SPK CONN
38. AUDIO HDP AMP AN17000A
39. MINI PCI
40. PCI BUS SWITCH
0
_______
A
B
C
D
E
F
OCT/02/2001
41. DOCKING
42. CLEAN SHEET BAY
43. (BLANK)
44. CDC CONNECTOR
45. THERMAL SENSOR
46. I2CBUS/SMBUS
47. IR MODULE
48. TRISTAR T64C(1/4)
49. TRISTAR T64C(2/4)
50. TRIATAR T64C(3/4)
51. TRIATAR T64C(4/4)
52. (BLANK)
53. (BLANK)
54. TV-OUT
55. (BLANK)
56. LCD I/F CONNECTOR
57. FAN CONTROL
58. I/O SUB CONN,RJ11 CONN
59. DCDC DC-IN AND CHARGER
60. DCDC BATTERY,VCCSW
61. DCDC TRICKLE CHARGER
62. DCDC BATTERY MONITOR
63. DCDC VCC3M/VCC5M(MAX1631)
64. DCDC VCCCPUCORE
65. DCDC VCCCPU1R5B
66. DCDC VCC1R8
67. DCDC KOZAK
68. DCDC VCC3AUX
69. (BLANK)
70. DCDC VID MUX
D
E
F
G
H
J
(SDR)
G
H
J
K
L
M
DATE
EC NO.
OCT/02/01 VER 0.86
Y.I
10/02/01
DESIGNER
CHECKED
APPROVED
CLASS
THIS
DOCUMENT
IS
THE PROPERTY
IBM
ITS
USE IS AUTHORIZED ONLY
RESPONDING TO A REQUEST FOR QUOTATION
OR
FOR
THE PERFORMANCE OF WORK
IBM.
ALL QUESTIONS MUST BE REFERRED
TO THE IBM PURCHASING DEPARTMENT.
K
L
M
N
P
Q
PART NO.
_______
9
DEVELOPMENT NO.
Q/M
/
1
70
8
7
6
5
4
3
2
1
DRAWING:
PART NO.
_______
TITLE
TORONTO-4.5
TITLE PAGE
0
OF
FOR
FOR
N
P
Q

Advertisement

loading

Related Manuals for IBM TORONTO-4.5 PLANAR

Summary of Contents for IBM TORONTO-4.5 PLANAR

  • Page 1 40. PCI BUS SWITCH TITLE TORONTO-4.5 APPROVED CLASS TITLE PAGE THIS DOCUMENT THE PROPERTY USE IS AUTHORIZED ONLY RESPONDING TO A REQUEST FOR QUOTATION _______ THE PERFORMANCE OF WORK IBM. ALL QUESTIONS MUST BE REFERRED TO THE IBM PURCHASING DEPARTMENT.
  • Page 2 CHECKED CHANGED BY TR4P047. TITLE TORONTO-4.5 APPROVED CLASS EC HISTORY THIS DOCUMENT THE PROPERTY USE IS AUTHORIZED ONLY RESPONDING TO A REQUEST FOR QUOTATION _______ THE PERFORMANCE OF WORK IBM. ALL QUESTIONS MUST BE REFERRED TO THE IBM PURCHASING DEPARTMENT.
  • Page 3 CPU (1/3) CLASS NO_ASM 1005 NEAR CPU 1608 THIS DOCUMENT THE PROPERTY NO_ASM 1005 USE IS AUTHORIZED ONLY RESPONDING TO A REQUEST FOR QUOTATION _______ THE PERFORMANCE OF WORK IBM. ALL QUESTIONS MUST BE REFERRED TO THE IBM PURCHASING DEPARTMENT.
  • Page 4 APPROVED ITP_TDO -ITP_FSPREQ CPU (2/3) CLASS -ITP_TRST -ITP_FSPRDY THIS DOCUMENT THE PROPERTY USE IS AUTHORIZED ONLY ITP_TMS -ITP_DBRESET RESPONDING TO A REQUEST FOR QUOTATION _______ THE PERFORMANCE OF WORK IBM. ALL QUESTIONS MUST BE REFERRED TO THE IBM PURCHASING DEPARTMENT.
  • Page 5 10/02/01 DESIGNER _______ CHECKED TITLE TORONTO-4.5 APPROVED CPU (3/3) CLASS THIS DOCUMENT THE PROPERTY USE IS AUTHORIZED ONLY RESPONDING TO A REQUEST FOR QUOTATION _______ THE PERFORMANCE OF WORK IBM. ALL QUESTIONS MUST BE REFERRED TO THE IBM PURCHASING DEPARTMENT.
  • Page 6 DESIGNER _______ CHECKED TITLE TORONTO-4.5 APPROVED DECAP FOR VCCCPU1R5B CLASS THIS DOCUMENT THE PROPERTY USE IS AUTHORIZED ONLY RESPONDING TO A REQUEST FOR QUOTATION _______ THE PERFORMANCE OF WORK IBM. ALL QUESTIONS MUST BE REFERRED TO THE IBM PURCHASING DEPARTMENT.
  • Page 7 DESIGNER _______ CHECKED TITLE TORONTO-4.5 APPROVED CAPS FOR VCCCPUCORE CLASS THIS DOCUMENT THE PROPERTY USE IS AUTHORIZED ONLY RESPONDING TO A REQUEST FOR QUOTATION _______ THE PERFORMANCE OF WORK IBM. ALL QUESTIONS MUST BE REFERRED TO THE IBM PURCHASING DEPARTMENT.
  • Page 8 10/02/01 DESIGNER _______ CHECKED TITLE TORONTO-4.5 APPROVED GMCH3-M(1/3):HOST I/F CLASS THIS DOCUMENT THE PROPERTY USE IS AUTHORIZED ONLY RESPONDING TO A REQUEST FOR QUOTATION _______ THE PERFORMANCE OF WORK IBM. ALL QUESTIONS MUST BE REFERRED TO THE IBM PURCHASING DEPARTMENT.
  • Page 9 10/02/01 DESIGNER _______ CHECKED TITLE TORONTO-4.5 APPROVED CLASS THIS DOCUMENT THE PROPERTY GMCH3-M(2/3):MEMORY I/F USE IS AUTHORIZED ONLY RESPONDING TO A REQUEST FOR QUOTATION _______ THE PERFORMANCE OF WORK IBM. ALL QUESTIONS MUST BE REFERRED TO THE IBM PURCHASING DEPARTMENT.
  • Page 10 REFSET HUB_STB 14.7N<> HLSTRB# -HUB_STB GMCH3(3/3):AGP/HUB I/F CLASS 14.7N<> VHUB_REF_0R9 THIS DOCUMENT THE PROPERTY USE IS AUTHORIZED ONLY RESPONDING TO A REQUEST FOR QUOTATION _______ THE PERFORMANCE OF WORK IBM. ALL QUESTIONS MUST BE REFERRED TO THE IBM PURCHASING DEPARTMENT.
  • Page 11 _______ CHECKED TITLE TORONTO-4.5 APPROVED REF VOL & DECAP CLASS THIS DOCUMENT THE PROPERTY USE IS AUTHORIZED ONLY RESPONDING TO A REQUEST FOR QUOTATION _______ THE PERFORMANCE OF WORK IBM. ALL QUESTIONS MUST BE REFERRED TO THE IBM PURCHASING DEPARTMENT.
  • Page 12 APPROVED 1/16W 1/16W 1005 1005 DIMM CARD CONNECTOR CLASS THIS DOCUMENT THE PROPERTY 144PIN USE IS AUTHORIZED ONLY RESPONDING TO A REQUEST FOR QUOTATION _______ THE PERFORMANCE OF WORK IBM. ALL QUESTIONS MUST BE REFERRED TO THE IBM PURCHASING DEPARTMENT.
  • Page 13 10/02/01 DESIGNER _______ CHECKED TITLE TORONTO-4.5 APPROVED CLOCK GEN(C9827) CLASS THIS DOCUMENT THE PROPERTY USE IS AUTHORIZED ONLY RESPONDING TO A REQUEST FOR QUOTATION _______ THE PERFORMANCE OF WORK IBM. ALL QUESTIONS MUST BE REFERRED TO THE IBM PURCHASING DEPARTMENT.
  • Page 14 ICH3-M (1/3) CLASS 1/16W 1005 THIS DOCUMENT THE PROPERTY NO_ASM USE IS AUTHORIZED ONLY NEAR ICH3 324PIN BGA RESPONDING TO A REQUEST FOR QUOTATION _______ THE PERFORMANCE OF WORK IBM. ALL QUESTIONS MUST BE REFERRED TO THE IBM PURCHASING DEPARTMENT.
  • Page 15 28.6M> 20.7B<> TITLE TORONTO-4.5 VCC3M APPROVED VCC3B ICH3-M (2/3) CLASS THIS DOCUMENT THE PROPERTY USE IS AUTHORIZED ONLY RESPONDING TO A REQUEST FOR QUOTATION _______ THE PERFORMANCE OF WORK IBM. ALL QUESTIONS MUST BE REFERRED TO THE IBM PURCHASING DEPARTMENT.
  • Page 16 10/02/01 DESIGNER _______ CHECKED TITLE TORONTO-4.5 APPROVED ICH3-M (3/3) CLASS THIS DOCUMENT THE PROPERTY USE IS AUTHORIZED ONLY RESPONDING TO A REQUEST FOR QUOTATION _______ THE PERFORMANCE OF WORK IBM. ALL QUESTIONS MUST BE REFERRED TO THE IBM PURCHASING DEPARTMENT.
  • Page 17 DESIGNER _______ CHECKED TITLE TORONTO-4.5 APPROVED HDD I/F CONNECTOR CLASS THIS DOCUMENT THE PROPERTY USE IS AUTHORIZED ONLY RESPONDING TO A REQUEST FOR QUOTATION _______ THE PERFORMANCE OF WORK IBM. ALL QUESTIONS MUST BE REFERRED TO THE IBM PURCHASING DEPARTMENT.
  • Page 18 10/02/01 DESIGNER _______ CHECKED TITLE TORONTO-4.5 APPROVED USB I/F CLASS THIS DOCUMENT THE PROPERTY USE IS AUTHORIZED ONLY RESPONDING TO A REQUEST FOR QUOTATION _______ THE PERFORMANCE OF WORK IBM. ALL QUESTIONS MUST BE REFERRED TO THE IBM PURCHASING DEPARTMENT.
  • Page 19 10/02/01 DESIGNER _______ CHECKED TITLE TORONTO-4.5 APPROVED FWH,RTC BAT. CLASS THIS DOCUMENT THE PROPERTY USE IS AUTHORIZED ONLY RESPONDING TO A REQUEST FOR QUOTATION _______ THE PERFORMANCE OF WORK IBM. ALL QUESTIONS MUST BE REFERRED TO THE IBM PURCHASING DEPARTMENT.
  • Page 20 CHECKED VCC3M TITLE TORONTO-4.5 APPROVED 1/16W H8S/2169A CLASS R595 1608 THIS DOCUMENT THE PROPERTY USE IS AUTHORIZED ONLY RESPONDING TO A REQUEST FOR QUOTATION _______ THE PERFORMANCE OF WORK IBM. ALL QUESTIONS MUST BE REFERRED TO THE IBM PURCHASING DEPARTMENT.
  • Page 21 CHECKED 41.6A< 58.6C<> 20.3E<> TITLE TORONTO-4.5 APPROVED KEYBOARD, PS/2 CLASS THIS DOCUMENT THE PROPERTY USE IS AUTHORIZED ONLY RESPONDING TO A REQUEST FOR QUOTATION _______ THE PERFORMANCE OF WORK IBM. ALL QUESTIONS MUST BE REFERRED TO THE IBM PURCHASING DEPARTMENT.
  • Page 22 0.022UF MISC G/A (PMH-2) CLASS 1005 -MOTEN1 THIS DOCUMENT THE PROPERTY 24.4Q> -H8_ULTRA_ON USE IS AUTHORIZED ONLY 20.7Q> RESPONDING TO A REQUEST FOR QUOTATION _______ THE PERFORMANCE OF WORK IBM. ALL QUESTIONS MUST BE REFERRED TO THE IBM PURCHASING DEPARTMENT.
  • Page 23 DESIGNER _______ CHECKED TITLE TORONTO-4.5 APPROVED POWER ON LOGIC CLASS THIS DOCUMENT THE PROPERTY USE IS AUTHORIZED ONLY RESPONDING TO A REQUEST FOR QUOTATION _______ THE PERFORMANCE OF WORK IBM. ALL QUESTIONS MUST BE REFERRED TO THE IBM PURCHASING DEPARTMENT.
  • Page 24 PLANAR ID 3 THIS DOCUMENT THE PROPERTY USE IS AUTHORIZED ONLY GPIO 13 12 11 10 100PIN PITCH=0.5MM RESPONDING TO A REQUEST FOR QUOTATION _______ THE PERFORMANCE OF WORK IBM. ALL QUESTIONS MUST BE REFERRED TO THE IBM PURCHASING DEPARTMENT.
  • Page 25 10/02/01 DESIGNER _______ CHECKED TITLE TORONTO-4.5 APPROVED SERIAL I/F CLASS THIS DOCUMENT THE PROPERTY USE IS AUTHORIZED ONLY RESPONDING TO A REQUEST FOR QUOTATION _______ THE PERFORMANCE OF WORK IBM. ALL QUESTIONS MUST BE REFERRED TO THE IBM PURCHASING DEPARTMENT.
  • Page 26 10/02/01 DESIGNER _______ CHECKED TITLE TORONTO-4.5 APPROVED PARALLEL PORT CLASS THIS DOCUMENT THE PROPERTY USE IS AUTHORIZED ONLY RESPONDING TO A REQUEST FOR QUOTATION _______ THE PERFORMANCE OF WORK IBM. ALL QUESTIONS MUST BE REFERRED TO THE IBM PURCHASING DEPARTMENT.
  • Page 27 CRT_HSYNC_EXT TITLE TORONTO-4.5 41.4A< 58.5K< APPROVED EXT CRT I/F CLASS THIS DOCUMENT THE PROPERTY USE IS AUTHORIZED ONLY RESPONDING TO A REQUEST FOR QUOTATION _______ THE PERFORMANCE OF WORK IBM. ALL QUESTIONS MUST BE REFERRED TO THE IBM PURCHASING DEPARTMENT.
  • Page 28 DESIGNER _______ CHECKED TITLE TORONTO-4.5 APPROVED CARD BUS PCI1420GHK(1/2) CLASS THIS DOCUMENT THE PROPERTY USE IS AUTHORIZED ONLY RESPONDING TO A REQUEST FOR QUOTATION _______ THE PERFORMANCE OF WORK IBM. ALL QUESTIONS MUST BE REFERRED TO THE IBM PURCHASING DEPARTMENT.
  • Page 29 DESIGNER _______ CHECKED TITLE TORONTO-4.5 APPROVED CARD BUS PCI1420GHK(2/2) CLASS THIS DOCUMENT THE PROPERTY USE IS AUTHORIZED ONLY RESPONDING TO A REQUEST FOR QUOTATION _______ THE PERFORMANCE OF WORK IBM. ALL QUESTIONS MUST BE REFERRED TO THE IBM PURCHASING DEPARTMENT.
  • Page 30 _______ CHECKED TITLE TORONTO-4.5 APPROVED CARD BUS POWER CONTROL CLASS THIS DOCUMENT THE PROPERTY USE IS AUTHORIZED ONLY RESPONDING TO A REQUEST FOR QUOTATION _______ THE PERFORMANCE OF WORK IBM. ALL QUESTIONS MUST BE REFERRED TO THE IBM PURCHASING DEPARTMENT.
  • Page 31 CHECKED -BCD2 TITLE TORONTO-4.5 29.3N< APPROVED CARD BUS SLOT CLASS THIS DOCUMENT THE PROPERTY USE IS AUTHORIZED ONLY RESPONDING TO A REQUEST FOR QUOTATION _______ THE PERFORMANCE OF WORK IBM. ALL QUESTIONS MUST BE REFERRED TO THE IBM PURCHASING DEPARTMENT.
  • Page 32 10/02/01 DESIGNER _______ CHECKED TITLE TORONTO-4.5 APPROVED AUDIO CS4299 CLASS THIS DOCUMENT THE PROPERTY USE IS AUTHORIZED ONLY RESPONDING TO A REQUEST FOR QUOTATION _______ THE PERFORMANCE OF WORK IBM. ALL QUESTIONS MUST BE REFERRED TO THE IBM PURCHASING DEPARTMENT.
  • Page 33 10/02/01 DESIGNER _______ CHECKED TITLE TORONTO-4.5 APPROVED AUDIO MISC CLASS THIS DOCUMENT THE PROPERTY USE IS AUTHORIZED ONLY RESPONDING TO A REQUEST FOR QUOTATION _______ THE PERFORMANCE OF WORK IBM. ALL QUESTIONS MUST BE REFERRED TO THE IBM PURCHASING DEPARTMENT.
  • Page 34 TORONTO-4.5 APPROVED 0.15UF C470 1608 AUDIO INT MIC CLASS THIS DOCUMENT THE PROPERTY AGND USE IS AUTHORIZED ONLY RESPONDING TO A REQUEST FOR QUOTATION _______ THE PERFORMANCE OF WORK IBM. ALL QUESTIONS MUST BE REFERRED TO THE IBM PURCHASING DEPARTMENT.
  • Page 35 TORONTO-4.5 APPROVED AGND AUDIO CONNECTOR CLASS WIDE AND SHORT PATTERN THIS DOCUMENT THE PROPERTY USE IS AUTHORIZED ONLY RESPONDING TO A REQUEST FOR QUOTATION _______ THE PERFORMANCE OF WORK IBM. ALL QUESTIONS MUST BE REFERRED TO THE IBM PURCHASING DEPARTMENT.
  • Page 36 GUARDING WITH AGND TITLE TORONTO-4.5 APPROVED AUDIO EXT MIC I/F CLASS THIS DOCUMENT THE PROPERTY USE IS AUTHORIZED ONLY RESPONDING TO A REQUEST FOR QUOTATION _______ THE PERFORMANCE OF WORK IBM. ALL QUESTIONS MUST BE REFERRED TO THE IBM PURCHASING DEPARTMENT.
  • Page 37 DESIGNER _______ CHECKED TITLE TORONTO-4.5 APPROVED AUDIO SPK CONN CLASS THIS DOCUMENT THE PROPERTY USE IS AUTHORIZED ONLY RESPONDING TO A REQUEST FOR QUOTATION _______ THE PERFORMANCE OF WORK IBM. ALL QUESTIONS MUST BE REFERRED TO THE IBM PURCHASING DEPARTMENT.
  • Page 38 CHECKED AGND TITLE TORONTO-4.5 APPROVED AUDIO HDP AMP AN7515 CLASS THIS DOCUMENT THE PROPERTY USE IS AUTHORIZED ONLY RESPONDING TO A REQUEST FOR QUOTATION _______ THE PERFORMANCE OF WORK IBM. ALL QUESTIONS MUST BE REFERRED TO THE IBM PURCHASING DEPARTMENT.
  • Page 39 AGND AGND AGND MFG2 TITLE TORONTO-4.5 APPROVED MINI PCI CLASS THIS DOCUMENT THE PROPERTY USE IS AUTHORIZED ONLY RESPONDING TO A REQUEST FOR QUOTATION _______ THE PERFORMANCE OF WORK IBM. ALL QUESTIONS MUST BE REFERRED TO THE IBM PURCHASING DEPARTMENT.
  • Page 40 TITLE TORONTO-4.5 22.4N> APPROVED R445 1005 PCI BUS SWITCH CLASS THIS DOCUMENT THE PROPERTY USE IS AUTHORIZED ONLY RESPONDING TO A REQUEST FOR QUOTATION _______ THE PERFORMANCE OF WORK IBM. ALL QUESTIONS MUST BE REFERRED TO THE IBM PURCHASING DEPARTMENT.
  • Page 41 BPWRG_DOCK TITLE TORONTO-4.5 67.2Q> C114 1005 APPROVED DOCKING CLASS AGND THIS DOCUMENT THE PROPERTY USE IS AUTHORIZED ONLY RESPONDING TO A REQUEST FOR QUOTATION _______ THE PERFORMANCE OF WORK IBM. ALL QUESTIONS MUST BE REFERRED TO THE IBM PURCHASING DEPARTMENT.
  • Page 42 SDD<15..0> APPROVED 15.3A> CLEAN SHEET BAY CLASS THIS DOCUMENT THE PROPERTY USE IS AUTHORIZED ONLY ROUTE IN PARALLEL RESPONDING TO A REQUEST FOR QUOTATION _______ THE PERFORMANCE OF WORK IBM. ALL QUESTIONS MUST BE REFERRED TO THE IBM PURCHASING DEPARTMENT.
  • Page 43 PART NO. 10/02/01 DESIGNER _______ CHECKED TITLE TORONTO-4.5 APPROVED CLASS THIS DOCUMENT THE PROPERTY USE IS AUTHORIZED ONLY RESPONDING TO A REQUEST FOR QUOTATION _______ THE PERFORMANCE OF WORK IBM. ALL QUESTIONS MUST BE REFERRED TO THE IBM PURCHASING DEPARTMENT.
  • Page 44 10/02/01 DESIGNER _______ CHECKED TITLE TORONTO-4.5 APPROVED CDC CONNECTOR CLASS THIS DOCUMENT THE PROPERTY USE IS AUTHORIZED ONLY RESPONDING TO A REQUEST FOR QUOTATION _______ THE PERFORMANCE OF WORK IBM. ALL QUESTIONS MUST BE REFERRED TO THE IBM PURCHASING DEPARTMENT.
  • Page 45 10/02/01 DESIGNER _______ CHECKED TITLE TORONTO-4.5 APPROVED THERMAL SENSOR CLASS THIS DOCUMENT THE PROPERTY USE IS AUTHORIZED ONLY RESPONDING TO A REQUEST FOR QUOTATION _______ THE PERFORMANCE OF WORK IBM. ALL QUESTIONS MUST BE REFERRED TO THE IBM PURCHASING DEPARTMENT.
  • Page 46 NO_ASM NO_ASM 1005 I2CBUS/SMBUS CLASS 1/16W 1005 1005 1005 THIS DOCUMENT THE PROPERTY NO_ASM USE IS AUTHORIZED ONLY RESPONDING TO A REQUEST FOR QUOTATION _______ THE PERFORMANCE OF WORK IBM. ALL QUESTIONS MUST BE REFERRED TO THE IBM PURCHASING DEPARTMENT.
  • Page 47 10/02/01 DESIGNER _______ CHECKED TITLE TORONTO-4.5 APPROVED IR MODULE CLASS THIS DOCUMENT THE PROPERTY USE IS AUTHORIZED ONLY RESPONDING TO A REQUEST FOR QUOTATION _______ THE PERFORMANCE OF WORK IBM. ALL QUESTIONS MUST BE REFERRED TO THE IBM PURCHASING DEPARTMENT.
  • Page 48 10/02/01 DESIGNER _______ CHECKED TITLE TORONTO-4.5 APPROVED TRISTAR T64C(1/4) CLASS THIS DOCUMENT THE PROPERTY USE IS AUTHORIZED ONLY RESPONDING TO A REQUEST FOR QUOTATION _______ THE PERFORMANCE OF WORK IBM. ALL QUESTIONS MUST BE REFERRED TO THE IBM PURCHASING DEPARTMENT.
  • Page 49 10/02/01 DESIGNER _______ CHECKED TITLE TORONTO-4.5 APPROVED TRISTAR T64C(2/4) CLASS THIS DOCUMENT THE PROPERTY USE IS AUTHORIZED ONLY RESPONDING TO A REQUEST FOR QUOTATION _______ THE PERFORMANCE OF WORK IBM. ALL QUESTIONS MUST BE REFERRED TO THE IBM PURCHASING DEPARTMENT.
  • Page 50 10/02/01 DESIGNER _______ CHECKED TITLE TORONTO-4.5 APPROVED TRISTAR T64C(3/4) CLASS THIS DOCUMENT THE PROPERTY USE IS AUTHORIZED ONLY RESPONDING TO A REQUEST FOR QUOTATION _______ THE PERFORMANCE OF WORK IBM. ALL QUESTIONS MUST BE REFERRED TO THE IBM PURCHASING DEPARTMENT.
  • Page 51 TORONTO-4.5 AVSS_SUB APPROVED AVSS_SUB2 S3_LVDSAVSS 51.7E> VSSSUB TRISTAR T64C(4/4) CLASS THIS DOCUMENT THE PROPERTY USE IS AUTHORIZED ONLY RESPONDING TO A REQUEST FOR QUOTATION _______ THE PERFORMANCE OF WORK IBM. ALL QUESTIONS MUST BE REFERRED TO THE IBM PURCHASING DEPARTMENT.
  • Page 52 PART NO. 10/02/01 DESIGNER _______ CHECKED TITLE TORONTO-4.5 APPROVED CLASS THIS DOCUMENT THE PROPERTY USE IS AUTHORIZED ONLY RESPONDING TO A REQUEST FOR QUOTATION _______ THE PERFORMANCE OF WORK IBM. ALL QUESTIONS MUST BE REFERRED TO THE IBM PURCHASING DEPARTMENT.
  • Page 53 _______ CHECKED TITLE TORONTO-4.5 APPROVED GFX PULLUPS CLASS THIS DOCUMENT THE PROPERTY FOR STRAPPING USE IS AUTHORIZED ONLY RESPONDING TO A REQUEST FOR QUOTATION _______ THE PERFORMANCE OF WORK IBM. ALL QUESTIONS MUST BE REFERRED TO THE IBM PURCHASING DEPARTMENT.
  • Page 54 TV_GND CHECKED 58.5C< TITLE TORONTO-4.5 3216 APPROVED TV OUT CLASS THIS DOCUMENT THE PROPERTY USE IS AUTHORIZED ONLY RESPONDING TO A REQUEST FOR QUOTATION _______ THE PERFORMANCE OF WORK IBM. ALL QUESTIONS MUST BE REFERRED TO THE IBM PURCHASING DEPARTMENT.
  • Page 55 10/02/01 DESIGNER _______ CHECKED TITLE TORONTO-4.5 APPROVED GFX SAA7114 CLASS THIS DOCUMENT THE PROPERTY USE IS AUTHORIZED ONLY RESPONDING TO A REQUEST FOR QUOTATION _______ THE PERFORMANCE OF WORK IBM. ALL QUESTIONS MUST BE REFERRED TO THE IBM PURCHASING DEPARTMENT.
  • Page 56 APPROVED 1/16W 1005 LCD I/F CONNECTOR CLASS 1005 BT_DRV THIS DOCUMENT THE PROPERTY 67.5N> USE IS AUTHORIZED ONLY RESPONDING TO A REQUEST FOR QUOTATION _______ THE PERFORMANCE OF WORK IBM. ALL QUESTIONS MUST BE REFERRED TO THE IBM PURCHASING DEPARTMENT.
  • Page 57 10/02/01 DESIGNER _______ CHECKED TITLE TORONTO-4.5 APPROVED FAN CONTROL CLASS THIS DOCUMENT THE PROPERTY USE IS AUTHORIZED ONLY RESPONDING TO A REQUEST FOR QUOTATION _______ THE PERFORMANCE OF WORK IBM. ALL QUESTIONS MUST BE REFERRED TO THE IBM PURCHASING DEPARTMENT.
  • Page 58 DESIGNER _______ CHECKED TITLE TORONTO-4.5 APPROVED RJ11/RJ45 INTERFACE CONNECTOR CLASS THIS DOCUMENT THE PROPERTY USE IS AUTHORIZED ONLY RESPONDING TO A REQUEST FOR QUOTATION _______ THE PERFORMANCE OF WORK IBM. ALL QUESTIONS MUST BE REFERRED TO THE IBM PURCHASING DEPARTMENT.
  • Page 59 TORONTO-4.5 APPROVED DC/DC IN AND CHAGER CLASS BAT_CRG 22.3N> ANAGND THIS DOCUMENT THE PROPERTY USE IS AUTHORIZED ONLY RESPONDING TO A REQUEST FOR QUOTATION _______ THE PERFORMANCE OF WORK IBM. ALL QUESTIONS MUST BE REFERRED TO THE IBM PURCHASING DEPARTMENT.
  • Page 60 R282 APPROVED 1000PF 3.3M DC/DC BATTERY,VCCSW CLASS 1/16W 1005 1005 THIS DOCUMENT THE PROPERTY USE IS AUTHORIZED ONLY RESPONDING TO A REQUEST FOR QUOTATION _______ THE PERFORMANCE OF WORK IBM. ALL QUESTIONS MUST BE REFERRED TO THE IBM PURCHASING DEPARTMENT.
  • Page 61 DESIGNER _______ CHECKED TITLE TORONTO-4.5 APPROVED DCDC TRICKLE CHARGER CLASS THIS DOCUMENT THE PROPERTY USE IS AUTHORIZED ONLY RESPONDING TO A REQUEST FOR QUOTATION _______ THE PERFORMANCE OF WORK IBM. ALL QUESTIONS MUST BE REFERRED TO THE IBM PURCHASING DEPARTMENT.
  • Page 62 DESIGNER _______ CHECKED TITLE TORONTO-4.5 APPROVED DCDC BATTERY MONITOR CLASS THIS DOCUMENT THE PROPERTY USE IS AUTHORIZED ONLY RESPONDING TO A REQUEST FOR QUOTATION _______ THE PERFORMANCE OF WORK IBM. ALL QUESTIONS MUST BE REFERRED TO THE IBM PURCHASING DEPARTMENT.
  • Page 63 1/16W DC/DC VCC3M/VCC5M 1005 NEAR TO MAX1632 (MAX1631) CLASS 1608 THIS DOCUMENT THE PROPERTY USE IS AUTHORIZED ONLY RESPONDING TO A REQUEST FOR QUOTATION _______ THE PERFORMANCE OF WORK IBM. ALL QUESTIONS MUST BE REFERRED TO THE IBM PURCHASING DEPARTMENT.
  • Page 64 DPRSLPVR _______ 15.4M> CHECKED TITLE TORONTO-4.5 APPROVED DC/DC VCCCPUCORE CLASS THIS DOCUMENT THE PROPERTY USE IS AUTHORIZED ONLY RESPONDING TO A REQUEST FOR QUOTATION _______ THE PERFORMANCE OF WORK IBM. ALL QUESTIONS MUST BE REFERRED TO THE IBM PURCHASING DEPARTMENT.
  • Page 65 10/02/01 DESIGNER _______ CHECKED TITLE TORONTO-4.5 APPROVED DCDC CLASS THIS DOCUMENT THE PROPERTY VCCCPU1R5B USE IS AUTHORIZED ONLY RESPONDING TO A REQUEST FOR QUOTATION _______ THE PERFORMANCE OF WORK IBM. ALL QUESTIONS MUST BE REFERRED TO THE IBM PURCHASING DEPARTMENT.
  • Page 66 1608 1005 _______ CHECKED TITLE TORONTO-4.5 APPROVED DC-DC VCC1R8 CLASS THIS DOCUMENT THE PROPERTY USE IS AUTHORIZED ONLY RESPONDING TO A REQUEST FOR QUOTATION _______ THE PERFORMANCE OF WORK IBM. ALL QUESTIONS MUST BE REFERRED TO THE IBM PURCHASING DEPARTMENT.
  • Page 67 10/02/01 DESIGNER _______ CHECKED TITLE TORONTO-4.5 APPROVED DCDC KOZAK CLASS THIS DOCUMENT THE PROPERTY USE IS AUTHORIZED ONLY RESPONDING TO A REQUEST FOR QUOTATION _______ THE PERFORMANCE OF WORK IBM. ALL QUESTIONS MUST BE REFERRED TO THE IBM PURCHASING DEPARTMENT.
  • Page 68 10/02/01 DESIGNER _______ CHECKED TITLE TORONTO-4.5 APPROVED DCDC VCC3AUX CLASS THIS DOCUMENT THE PROPERTY USE IS AUTHORIZED ONLY RESPONDING TO A REQUEST FOR QUOTATION _______ THE PERFORMANCE OF WORK IBM. ALL QUESTIONS MUST BE REFERRED TO THE IBM PURCHASING DEPARTMENT.
  • Page 69 PART NO. 10/02/01 DESIGNER _______ CHECKED TITLE TORONTO-4.5 APPROVED CLASS THIS DOCUMENT THE PROPERTY USE IS AUTHORIZED ONLY RESPONDING TO A REQUEST FOR QUOTATION _______ THE PERFORMANCE OF WORK IBM. ALL QUESTIONS MUST BE REFERRED TO THE IBM PURCHASING DEPARTMENT.
  • Page 70 DESIGNER _______ CHECKED TITLE TORONTO-4.5 APPROVED DCDC VID MUX CLASS THIS DOCUMENT THE PROPERTY USE IS AUTHORIZED ONLY RESPONDING TO A REQUEST FOR QUOTATION _______ THE PERFORMANCE OF WORK IBM. ALL QUESTIONS MUST BE REFERRED TO THE IBM PURCHASING DEPARTMENT.
