MEANS OF REPRESENTATION Symbols used The meaning of specific symbols is described below. Indicates an expected reaction (e.g. of a work step or a function). Indicates an unexpected reaction (e.g. of a work step or a function). Indicates a page reference (more information is provided on the specified page). Indicates information with more details or tips.
Page 5
SETUP Unpacking and setting up the vehicle Package 2 – Remove the box and the plastic packaging. Info An assistant prevents the motorcycle from falling over. To avoid damaging the motorcycle during the setup, leave the protective film on the vehicle until you have finished. –...
Page 6
SETUP Info Position the bleeder screws toward the front. Grooves are milled into the side of the upper end of the fork legs. The second milled groove (from the top) must be flush with the top edge of the upper triple clamp. –...
Page 7
SETUP – Mount the connector retainer and speedometer on the upper triple clamp. Guideline Remaining screws, chassis 10 Nm (7.4 lbf ft) – Position turn signal indicator lamp – Connect all plug-in connectors to the connector retainer. B01991-10 – Remove the fuel tank.
Page 8
– Fill the battery. Info Read the notes in the battery package. – Recharge the battery. ( p. 13) – Unpack and mount the KTM PowerParts included in the delivery (optional). Info Read the accompanying KTM PowerParts fitting instructions.
Page 9
Mount and tighten the rear mirror on both sides. – Position all controls in their exact positions on the handlebar. Tighten all screws. – Refuel. ( p. 18) – Prepare the vehicle according to the specifications in the KTM Dealer.net for han- dover to the customer. B01171-01...
Page 10
SERVICE WORK ON THE CHASSIS Raising the motorcycle with a lift stand Note Danger of damage The parked vehicle can roll away or fall over. – Park the vehicle on a firm and level surface. – Raise the motorcycle at the frame underneath the engine. Lift stand (78929955100) Neither wheel is in contact with the ground.
Page 11
SERVICE WORK ON THE CHASSIS Installing the front wheel Warning Danger of accidents Oil or grease on the brake discs reduces the braking effect. – Always keep the brake discs free of oil and grease. – Clean the brake discs with brake cleaner when necessary. –...
Page 12
SERVICE WORK ON THE CHASSIS Locking the seat – Fold down the seat and push it down. The seat engages with an audible click. – Check that the seat is correctly locked. M00498-01 Removing the fuel tank Danger Fire hazard Fuel is highly flammable. The fuel in the fuel tank expands when warm and can escape if overfilled.
Page 13
SERVICE WORK ON THE CHASSIS – Unplug connector – Pull off engine breather hose M00510-10 – Release hose clamp – Detach the intake flange from the throttle valve body. B01077-10 – Pull up the fuel tank slightly and disconnect the connector for the fuel pump.
Page 14
SERVICE WORK ON THE CHASSIS – Position the fuel tank. – Position the intake flange on the throttle valve body. – Tighten hose clamp B01077-11 – Plug in connector – Position engine breather hose M00510-11 – Mount and tighten screws on both sides.
SERVICE WORK ON THE CHASSIS Main work – Check the throttle cable routing. Both throttle cables must be routed to the throttle valve body side by side behind the handlebars and below the seat fixing. » If the throttle cable is not routed as specified: –...
Page 16
SERVICE WORK ON THE CHASSIS – Switch off all power consumers and switch off the engine. – Remove screw – Remove fastening plate B01102-10 – Remove the battery from the battery compartment. – Disconnect negative cable from the battery. –...
Page 17
SERVICE WORK ON THE CHASSIS 3.11 Removing the battery Warning Risk of injury Battery acid and battery gases cause serious chemical burns. – Keep batteries out of the reach of children. – Wear suitable protective clothing and goggles. – Avoid contact with battery acid and battery gases. –...
Page 18
SERVICE WORK ON THE CHASSIS – Position the battery in the battery compartment. – Attach fastening plate – Mount and tighten screw B01102-11 3.13 Installing the front fender – Position the front fender. Mount and tighten screws Guideline Remaining screws, chassis 10 Nm (7.4 lbf ft)
SERVICE WORK ON THE CHASSIS 3.15 Checking the headlight setting – Position the vehicle upright on a horizontal surface in front of a light wall and make a mark at the height of the center of the low beam headlight. 0 0 A –...
Page 20
SERVICE WORK ON THE CHASSIS Warning Environmental hazard Improper handling of fuel is a danger to the environment. – Do not allow fuel to enter the groundwater, the soil, or the sewage system. Preparatory work – Fold the seat up. ( p.
Page 21
SERVICE WORK ON THE CHASSIS Warning Environmental hazard Improper handling of fuel is a danger to the environment. – Do not allow fuel to enter the groundwater, the soil, or the sewage system. Preparatory work – Switch off the engine. – Fold the seat up.
TECHNICAL DATA Chassis tightening torques – EJOT PT ® Screw for spoiler, front K60x30‑Z 3 Nm (2.2 lbf ft) – Screw for spoiler, top EJOT PT ® K60x20AL 3 Nm (2.2 lbf ft) – Screw, pressure regulator EJOT PT ® K60x25-Z 3 Nm (2.2 lbf ft) –...
Page 23
TECHNICAL DATA – Screw, front wheel spindle M20x1.5 35 Nm (25.8 lbf ft) – Screw, top steering head M20x1.5 12 Nm (8.9 lbf ft)
Page 24
SUBSTANCES Super unleaded (ROZ 95/RON 95/PON 91) Standard/classification – DIN EN 228 (ROZ 95/RON 95/PON 91) Guideline – Only use unleaded super fuel that matches or is equivalent to the specified fuel grade. – Fuel with an ethanol content of up to 10 % (E10 fuel) is safe to use. Info Do not use fuel containing methanol (e.
