- Page 1 Si001406EB REMOVAL PROCEDURE S E R V I C E M A N U A L 6.0 kW Class Outdoor Unit Inverter Pair Type...
- Page 2 Service Manual Removal Procedure Outdoor Unit Cooling Only RKH60QRV16 RKH60RRV16 RKP60PRV16 RKP60QRV16 RKPA60QRV16 RKPD60QRV16...
-
Page 3: Table Of Contents
Si001406EB Table of Contents 1. Outer Panels ...................2 2. Outdoor Fan / Fan Motor.................5 3. Electrical Box ..................7 4. PCBs .....................11 5. Thermistor ASSY ..................13 6. Partition Plate / Sound Blankets............15 7. Capillary Tube ..................17 8. Compressor...................19 Note: The illustrations may be slightly different depending on the model. Removal Procedure... -
Page 4: Outer Panels
Outer Panels Si001406EB 1. Outer Panels Warning Be sure to wait for 10 minutes or more after turning off all power supplies before disassembling work. Step Procedure Points Remove the 4 screws, The shape of the discharge Top panel and then the top panel. grille varies depending on the model. - Page 5 Si001406EB Outer Panels Step Procedure Points Unfasten the 2 hooks When reassembling, make and remove the front sure that the 2 hooks are panel. securely fastened. Hook (R20221) Remove the 4 screws For square grille models of the discharge grille. Discharge grille (R22577) Unfasten the 6 hooks...
- Page 6 Outer Panels Si001406EB Step Procedure Points Press the 2 projections For round grille models from the rear side and Rear side rotate the discharge grille. Discharge grille Projection (rear side) (R22383) Unfasten the 6 hooks and remove the discharge grille. Hook Hook (R22384)
-
Page 7: Outdoor Fan / Fan Motor
Si001406EB Outdoor Fan / Fan Motor 2. Outdoor Fan / Fan Motor Warning Be sure to wait for 10 minutes or more after turning off all power supplies before disassembling work. Step Procedure Points Cut the clamp. Clamp (R20655) Disconnect the [S79]: fan motor [S79] connector [S79]. - Page 8 Outdoor Fan / Fan Motor Si001406EB Step Procedure Points Remove the nut, and Nut size: M6 then the outdoor fan. 10 mm (0.39 inch) (R18954) When reassembling, align mark of the outdoor fan with the D-cut section of the motor shaft. Outdoor fan (R20225) Remove the screw of...
-
Page 9: Electrical Box
Si001406EB Electrical Box 3. Electrical Box Warning Be sure to wait for 10 minutes or more after turning off all power supplies before disassembling work. Step Procedure Points Cut the clamp. Clamp (R23685) Disconnect the [S79]: fan motor [S79] connector [S79]. (R20656) Disconnect the [S40]: overload protector... - Page 10 Electrical Box Si001406EB Step Procedure Points Disconnect the [S90]: thermistors [S90] connector [S90]. (R20229) Cut the clamp. Clamp (R20230) Disconnect the relay connector for the compressor. Relay connector (R20231) for compressor Remove the screw on the stop valve cover. Slide the stop valve cover downward and remove it.
- Page 11 Si001406EB Electrical Box Step Procedure Points When reassembling, make sure the 3 hooks are securely fastened. Hook (R20233) Remove the 3 screws, and then the wire fixture. Wire fixture (R18441) 10 Remove the 7 screws on the terminal board and disconnect the connecting wire and the power supply wire.
- Page 12 Electrical Box Si001406EB Step Procedure Points 11 Remove the 2 screws on the right side panel. Right side panel (R20432) Remove the screw on Electrical box the partition plate. Lift up and remove the electrical box. Partition plate (R20657) Removal Procedure...
-
Page 13: Pcbs
Si001406EB PCBs 4. PCBs Warning Be sure to wait for 10 minutes or more after turning off all power supplies before disassembling work. Step Procedure Points Remove the screw and Electrical box cover remove the electrical box cover. (R20658) Disconnect the 3 Earth/ground wire (upper) HN1 (white) connectors from the... - Page 14 PCBs Si001406EB Step Procedure Points Disconnect the relay connector for the fan motor. Relay connector for fan motor (R20239) Remove the 7 screws. (R20240) Remove the main PCB. Main PCB (R20241) Turn over the electrical box. Clamp Pinch the 4 clamps and remove the clamp PCB.
-
Page 15: Thermistor Assy
Si001406EB Thermistor ASSY 5. Thermistor ASSY Warning Be sure to wait for 10 minutes or more after turning off all power supplies before disassembling work. Step Procedure Points Release the outdoor The shape of the protection Outdoor temperature thermistor temperature thermistor. net varies depending on the model. - Page 16 Thermistor ASSY Si001406EB Step Procedure Points Release the discharge Be careful not to lose the Discharge pipe thermistor pipe thermistor. fixture for the thermistor. Remove the thermistor ASSY. Fixture (R20430) (R22575) Thermistor ASSY (R20246) Removal Procedure...
-
Page 17: Partition Plate / Sound Blankets
Si001406EB Partition Plate / Sound Blankets 6. Partition Plate / Sound Blankets Warning Be sure to wait for 10 minutes or more after turning off all power supplies before disassembling work. Step Procedure Points Remove the 2 screws, Since the piping ports are and then the partition torn easily, remove the plate. - Page 18 Partition Plate / Sound Blankets Si001406EB Step Procedure Points Pull out the sound blanket (inner). Sound blanket (inner) (R20567) Pull out the sound When reassembling, mount blanket (bottom). the sound blankets and the partition plate in the following order. (1) Bottom (2) Inner (3) Outer (4) Top...
-
Page 19: Capillary Tube
Si001406EB Capillary Tube 7. Capillary Tube Warning Be sure to wait for 10 minutes or more after turning off all power supplies before disassembling work. Be careful not to get yourself burnt with the pipes and other parts that are heated by the gas brazing machine. - Page 20 Capillary Tube Si001406EB Step Procedure Points Remove the protection Protection bushing bushing. V (yellow) Disconnect the compressor lead wires U (red) and the overload protector. W (blue) Overload protector (R22591) Remove the putties. The position of the putties varies depending on the Heat up the 2 brazed model.
-
Page 21: Compressor
Si001406EB Compressor 8. Compressor Warning Be sure to wait for 10 minutes or more after turning off all power supplies before disassembling work. Be careful not to get yourself burnt with the pipes and other parts that are heated by the gas brazing machine. - Page 22 Compressor Si001406EB Step Procedure Points Remove the protection Protection bushing bushing. V (yellow) Disconnect the compressor lead wires U (red) and the overload protector. W (blue) Overload protector (R22591) Heat up the brazed part Brazed part of the Brazed part of the of the discharge side discharge side pipe suction side pipe...
- Page 23 Revision History Month / Year Version Revised contents 07 / 2014 Si001406E First edition 11 / 2015 Si001406EA Model addition: RKP60QRV16, RKPA60QRV16, RKPD60QRV16 08 / 2016 Si001406EB Model addition: RKH60QRV16, RKH60RRV16...
- Page 24 Improper installation can result in water or refrigerant leakage, electrical shock, fire or explosion. Use only those parts and accessories supplied or specified by Daikin. Ask a qualified installer or contractor to install those parts and accessories. Use of unauthorised parts and accessories or improper installation of parts and accessories can result in water or refrigerant leakage, electrical shock, fire or explosion.
