Olympus SZ2-ILLC Instructions Manual

Coaxial illuminator
Hide thumbs Also See for SZ2-ILLC:

Advertisement

Quick Links

INSTRUCTIONS
SZ2-ILLC
COAXIAL ILLUMINATOR
This instruction manual is for the Olympus SZ2-ILLC Coaxial Illuminator. To ensure the safety, obtain
optimum performance and to familiarize yourself fully with the use of this equipment, we recommend
that you study this manual thoroughly before operating the system.
Retain this instruction manual in an easily accessible place near the work desk for future reference.
A X 6 6 1 7

Advertisement

loading

Related Manuals for Olympus SZ2-ILLC

Summary of Contents for Olympus SZ2-ILLC

  • Page 1 SZ2-ILLC COAXIAL ILLUMINATOR This instruction manual is for the Olympus SZ2-ILLC Coaxial Illuminator. To ensure the safety, obtain optimum performance and to familiarize yourself fully with the use of this equipment, we recommend that you study this manual thoroughly before operating the system.

  • Page 3: Table Of Contents

    SZ2-ILLC CONTENTS IMPORTANT — Be sure to read this chapter for safe use of the equipment. — 1 NOMENCLATURE 2 CONTROLS 3 ASSEMBLY 9-10 4 COAXIAL REFLECTED LIGHT OBSERVATION 5 TROUBLESHOOTING GUIDE...

  • Page 4: Important - Be Sure To Read This Chapter For Safe Use Of The Equipment

    IMPORTANT The coaxial illuminator enables coaxial reflected light observation when it is mounted at the bottom of an SZ2 series microscope. SAFETY PRECAUTIONS This unit can be used in combination with only the SZ2-LGB or LG-PS2 light guide illuminator. For safety, use only one of the lamp bulbs designated in the following table. For details, refer to the “...
  • Page 5 Indicates that the main switch is OFF. Protective grounding, which can be used only by the Olympus service personnel for incorporating grounding in machines. Do not use this grounding for other purpose than the above. (LG-PS2 only) Warnings Warning engravings are placed at parts where special precaution is required when handling and using the unit.
  • Page 6 Getting Ready 1. The coaxial illuminator is a precision instrument. Handle it with care and avoid subjecting it to sudden or severe impact. 2. Do not use the coaxial illuminator where it is subjected to direct sunlight, high temperature and humidity, dust or vibrations. 3.
  • Page 7 # To clean the half mirror inside the coaxial illuminator, simply remove dust and dirt with a blower, etc. If the half mirror is still dirty after blowing, please contact Olympus. 2. Do not attempt to use organic solvents to clean the parts other than the glass components. To clean them, use a lint-free, soft cloth slightly moistened with a diluted neutral detergent.
  • Page 8 Caution If the coaxial illuminator is used in a manner not specified by this manual, the safety of the user may be imperiled. In addition, the equipment may also be damaged. Always use the equipment as outlined in this instruction manual. The following symbols are used to set off text in this instruction manual.

  • Page 9: Nomenclature

    SZ2-ILLC NOMENCLATURE Dual Flexible Light Guide SZ2-LGDF or LG-DF Lightguide Illuminator SZ2-LGB or LG-PS2 SZ2 series microscope body Coaxial Illuminator SZ2-ILLC Standard stand or Arms Used with Microscopes for Equipment Mounting · SZ2-ST · SZ2-STS · SZ2-STB1...

  • Page 10: Controls

    CONTROLS Dual Flexible Light Guide Coaxial Illuminator SZ2-ILLC SZ2-LGDF or LG-DF Mounting adapter Light guide input end Light guide mount port Clamping screw Mount Light guide output end Clamping screw Allen wrench...
  • Page 11 SZ2-ILLC Lightguide Illuminator Light Source SZ2-LGB LG-PS2 ? Refer to the separate instruction manual. } Refer to the separate instruction manual. Lightguide illuminator Light source AC adapter...

  • Page 12: Assembly

    SZ2-LGB when using the SZ2-LGDF or use the LG-PS2 when using the LG-DF. Light Guide SZ2 series body SZ2-LGDF or LG-DF Mounting adapter Light Source LG-PS2 Lightguide Illuminator SZ2-LGB Standard Stand Coaxial Illuminator or Arms Used SZ2-ILLC with Microscopes for Equipment Mounting...
  • Page 13 1. Screw the mount adapter 2 fully into the bottom of the SZ2 series micro- scope body 1 by turning the mount adapter in the direction of the arrow. 2. Loosen the clamping screw 3 of the SZ2-ILLC coaxial illuminator, fit the illuminator into the mount adapter 2 and tighten the clamping screw again.

  • Page 14: Coaxial Reflected Light Observation

    COAXIAL REFLECTED LIGHT OBSERVATION ?The applicable observation magnifications are zoom magnifications of 2X or more when the 10X eyepieces are used. 1. Place a specimen on the stage plate. 2. Set the main switch of the illuminator to ON and adjust the brightness. 3.

  • Page 15: Troubleshooting Guide

    Under certain conditions, performance of the unit may be adversely affected by factors other than defects. If problems occur, please review the following list and take remedial action as needed. If you cannot solve the problem after checking the entire list, please contact Olympus. Problem...
  • Page 16 Shinjuku Monolith, 3-1, Nishi Shinjuku 2-chome, Shinjuku-ku, Tokyo, Japan Wendenstrasse 14-18, 20097 Hamburg, Germany 3500 Corporate Parkway, Center Valley, Pennsylvania 18034-0610, U.S.A. 491B River Valley Road, #12-01/04 Valley Point Office Tower, Singapore 248373 31 Gilby Road, Mount Waverley, VIC., 3149, Melbourne, Australia 5301 Blue Lagoon Drive, Suite 290 Miami, FL 33126, U.S.A.
