1111 W. 35th Street
Chicago, IL 60609 USA
Customer Support: (773) 869-1234
www.tripplite.com
INTRODUCTION
Tripp Lite External Battery Packs have output voltages of either 36 volts (BP36V14-2U), 48 volts
(BP48V24-2U) or 72 volts (BP72V12-2U) and are designed for use with various Tripp Lite UPS systems
equipped with external battery pack connectors. When used with the appropriate Tripp Lite UPS, they meet
UL standard 1778. The BP48V24-2U may also be suitable for use with 48V DC input telecommunications
equipment.

PACKING LIST

• Battery Pack
• BP48V24-2U only:
Alternate Front Panel
• 4 Mounting Ears
(2 black, 2 grey)
SAFETY
• Use caution when lifting Battery Packs. Because of the considerable weight of all Rackmount
Battery Packs, at least two people should assist in lifting and installing them.
• 36V and 72V Battery Packs and UPS systems use identical power cables and plugs; make
certain that your Battery Packs and UPS use the same DC voltage before connecting them.
• Suggested mounting procedures are for common rack types and may not be appropriate for all rack
configurations. User must determine the fitness of rack- and wallmount hardware and procedures
before mounting.
• When connecting multiple Battery Packs to a single UPS, the Battery Packs should be approximately
the same age.
• It is normal for sparks to occur inside external battery connectors during final battery connection.
• Do not unplug external batteries from the UPS while the UPS is operating on battery power, due to
the possibility of dangerous arcing.
• There are no user-serviceable parts inside the Battery Packs. Do not open the Battery Packs for
any reason.
• Battery Replacement must be performed by factory authorized service personnel. Because batteries
present a risk of electrical shock and burn from high short-circuit current, observe proper precautions.
Unplug the Battery Pack from the UPS before performing battery replacement. Do not short or bridge
battery terminals with any object. Use tools with insulated handles. Remove metal objects such as
watches and rings before working with batteries. Do not open batteries. Replace batteries only with
sealed lead-acid batteries of the same number, type, voltage and amp hour capacity.
• Do not dispose of batteries in a fire. The batteries are recyclable. Proper disposal of batteries is required;
refer to your local codes for disposal requirements. In the USA only, you may call 1-800-SAV-LEAD
(1-800-728-5323) for complete recycling information.
200005167 Rackmount Battery Pack Manual (Revised).p65
External Battery Packs
• 2 Mounting Extensions
• Screws
• Wing Bolts
• Locking Nuts
• Flat Washers
Copyright © 2000 Tripp Lite. All rights reserved.
1
Owner's Manual
BP36V14-2U
BP48V24-2U
BP72V12-2U
ESPAÑOL: p. 6
FRANÇAIS: p. 12
8/15/00, 12:50 PM
1

Advertisement

Table of Contents
loading

Related Manuals for Tripp Lite BP36V14-2U

Summary of Contents for Tripp Lite BP36V14-2U

  • Page 1: Packing List

    Tripp Lite External Battery Packs have output voltages of either 36 volts (BP36V14-2U), 48 volts (BP48V24-2U) or 72 volts (BP72V12-2U) and are designed for use with various Tripp Lite UPS systems equipped with external battery pack connectors. When used with the appropriate Tripp Lite UPS, they meet UL standard 1778.
  • Page 2 Color Selection (BP48V24-2U Only) The BP4824-2U can be configured to match black or grey equipment. To match grey equipment, mount the grey mounting ears in front. To match black equipment, switch the grey front panel on the unit for the black front panel included, and mount the black mounting ears in front.
  • Page 3 SUGGESTED INSTALLATION FOR 2-POST RACK ENCLOSURES 1) On both sides of your Battery Pack, connect one mounting ear (A) with four screws and flat washers (B) to the Battery Pack's middle four mounting holes. The mounting surface of the ear should face the front of the Battery Pack. Have one or more assistants lift the Battery Pack and hold it in position until this step is complete.

  • Page 4: Battery Pack Connection

    UPS at one time. For longer runtime, you may connect two to a single UPS using a 48V Y- Adapter Cable sold separately by Tripp Lite, or use one or more BP48V60-3U Tripp Lite Battery Packs with daisy-chain capability.

  • Page 5: Troubleshooting

    Customers in the United States may obtain service under this Warranty only by delivering or shipping the product (with all shipping or delivery charges prepaid) to: Tripp Lite, 1111 W. 35th Street, Chicago, IL 60609. Seller will pay return shipping charges.

  • Page 6: Lista De Empaque

    INTRODUCCION Los Bancos de Baterías Externas Tripp Lite tienen voltajes de entrada de 36 voltios (BP36V14-2U), 48 voltios (BP48V24-2U) ó 72 voltios (BP72V12-2U) y han sido diseñados para usarlos con los diferentes no-breaks Tripp Lite equipados con conectores para bancos de baterías externas. Estas unidades, utilizadas con los no-breaks Tripp Lite adecuados, cumplen con la norma 1778 de UL.
  • Page 7 SELECCION DE COLOR (UNICAMENTE MODELO BP48V24-2U) El modelo BP4824-2U puede ser configurado para coincidir con equipos de color negro o gris. Para equipos de color gris, utilice las orejuelas grises de montaje en el frente. Para equipos de color negro, cambie el panel frontal de la unidad e instale el panel negro incluido y utilice las orejuelas negras de montaje.
  • Page 8 INSTALACION SUGERIDA PARA ENTORNOS DE RACK DE 2 POSTES En ambos lados del Banco de Baterías, conecte una orejuela de montaje (A) con cuatro tornillos y arandelas planas (B) a los hoyos de montaje en la parte media del Banco de Baterías. La superficie de montaje de la orejuela debe colocarse de cara a la parte frontal del Banco de Baterías.
  • Page 9 Bancos de Baterías a un no-break utilizando un adaptador tipo “Y” de 48V (48V Y- Adapter) disponible por separado a través de Tripp Lite, o utilizando uno o más Bancos de Baterías Tripp Lite modelo BP48V60-3U conectados entre sí. Los modelos BP36V14-2U o BP72V12-2U incluyen receptáculos dobles de entrada / salida en sus paneles...

  • Page 10: Mantenimiento

    CompuSupport al (5) 559-3022 antes de enviar el producto. Los clientes residentes en otras ciudades de México pueden visitar la página de Internet PowerZone de Tripp Lite (www.tripplite.com) para obtener una lista de los centros de servicios más cercanos. Los clientes en Canadá pueden obtener servicio de reparación bajo esta garantía únicamente enviando o entregando el producto (con todos los gastos de embarque y entrega pagados con antelación) a uno de los centros autorizados de servicio.

  • Page 11: Liste De Colisage

    INTRODUCTION Les Paquets Externes de Batterie de Tripp Lite ont des tensions de sortie de 36 volts (BP36V14-2U), de 48 volts (BP48V24-2U) ou de 72 volts (BP72V12-2U) et sont conçus pour l’usage avec divers systèmes d’UPS de Tripp Lite équipés de connecteurs de paquet externe de batterie. Lorsqu’utilisés avec l’UPS approprié...
  • Page 12 SELECTION DE COULEUR (BP48V24-2U Seulement) Le BP4824-2U peut être configuré pour apparier le matériel noir ou gris. Pour apparier le matériel gris, montez les oreilles grises de support sur avant. Pour apparier le matériel noir, commutez le panneau avant gris sur l’unité pour le panneau avant noir inclus, et montez les oreilles noires de support sur l’avant. (voir les instructions de support pour le placement exact de l’oreille de montage) INSTALLATION SUGGÉRÉE DE RACKMOUNT POUR INSERTIONS DE 4 MONTANTS...
  • Page 13 INSTALLATION SUGGÉRÉE POUR INSERTIONS DE 2 MONTANTS RACK 1) Sur les deux côtés de votre Paquet de Batterie, reliez une oreille de montage (A) avec quatre vis et à rondelles plates (B) aux quatre inser- tions de support du milieu du Paquet de Batterie.
  • Page 14 UPS en même temps. Pour un plus long délai d’exécution, vous pouvez relier deux à un simple UPS en utilisant un câble de 48V Y-Adapter vendu séparément par Tripp Lite, ou utilisez un ou plusieurs Paquets de Batterie BP48V60-2U de Tripp Lite avec la capacité...

  • Page 15: Dépannage

    Street, Chicago, Illinois 60609, U.S.A. Le vendeur payera les frais de retour d’expédition. Appelez Tripp Lite au (1) 773- 869-1234 avant de renvoyer tout matériel pour la réparation. Les clients au Mexique peuvent obtenir le service sous cette garantie seulement en livrant ou envoyant le produit (tous les frais d’expédition ou d’expédition étant payé...
  • Page 16 93-1592 (20005167) 8/00 200005167 Rackmount Battery Pack Manual (Revised)French.p65 8/15/00, 1:56 PM...
