Tripp Lite SR25UB Specification Sheet

Model #: SR25UB
25U SmartRack Premium Enclosure (includes doors and side panels)
Description
SmartRack enclosures are designed for secure, high density server and networking applications in IT environments. Designed with provisions to
integrate cooling, power distribution and cable management, SmartRack enclosures make ideal homes for mission-critical equipment.
Vendor-neutral square hole/cage nut mounting for guaranteed compatibility with all EIA-310-E compliant 19" equipment. Enclosures ship fully
assembled for rapid deployment and roll into place on heavy-duty casters. Tool-less mounting slots allow quick installation of PDUs and vertical
cable managers. Adjustable mounting rails include an easy-view depth index to eliminate time-consuming measurements. Lightweight modular doors
and side panels provide safe, convenient service access. Integrated baying tabs facilitate combining enclosures in rows for standard data center
baying applications. SmartRack enclosures hold up to 3000 lbs and support cooling, cable management, power distribution and monitoring features
that keep critical servers and network equipment operating nonstop. Perforated doors permit massive front to rear airflow that exceeds servers
manufacturer requirements. Enclosures are fully compatible with hot-aisle / cold-aisle data center configurations.
Features
Ships fully assembled for rapid deployment and roll into place on heavy-duty pre-installed casters
Front and rear sets of equipment mounting rails adjust in 1/4" increments. The easy-view depth index ensures consistent rail placement
without requiring time-consuming measurements
Tool-less accessory mounting rails (2 rails per enclosure) include slots for quick installation of compatible PDUs and vertical cable
managers. Mounting slots are arranged in an industry-standard pattern compatible with a wide variety of accessories. Each rail can
accommodate two vertical PDUs or cable managers side-by-side (four items per enclosure)
Enclosure includes mounting hardware of 50 pieces of M6 cage nuts and 50 pieces of M6 screws
Textured powder coat finish for tough resistance to environmental concerns such as deployment in warehouses
Massive front to rear ventilation capacity. 65+% open space in door perforation pattern meets or exceeds server manufacturer requirements
Maximum usable internal depth of 37 inches/94 cm (front to rear rail)
Weight ratings of 3000 lb stationary and 2250 lb rolling
Front door is locking, reversible and removable
Rear doors are locking and reversible. Split rear door design reduces clearance requirements for service entry allowing the enclosure to be
placed closer to a wall
Locking removable side panels are 'half size' to make them smaller and lighter improving ease of installation and servicing. Side panels are
keyed alike to the front and rear doors
Built in baying tabs allow enclosures to be combined securely in rows. Center-to-center width can be set at 600mm or 24" to match standard
data center floor tiles
Casters are pre-installed and support a rolling load capacity of 2250 lbs, allowing the enclosures to be pre-configured and rolled to the final
installation location. Casters are removable
Leveling feet extend to allow enclosure to be positioned on uneven floors. Levelers are removable
Convenient grounding system. All components are grounded to the enclosure frame which includes multiple connections for facility ground.
Front and rear doors include quick-release ground wires
Highlights
Standard 24" width - ships fully assembled
4 interior vertical posts with non-threaded square hole openings
3000 lb stationary / 2250 lb rolling load capacity
Locking, removable, reversible front and rear doors
Locking, removable side panels
Includes equipment mounting hardware
Meets all enclosure requirements towards PCI DSS (Payment Card Industry
Data Security Standard) compliance
